W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum

China W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier
W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum supplier

Large Image :  W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum

Product Details:

Place of Origin: CHINA
Brand Name: Emsco, National, Southwest, Gardner Denver
Certification: API
Model Number: FB1600, FC2200,FB1300

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: 1 to 500 usd
Packaging Details: Stuitable to shipment by sea and air
Delivery Time: In stock
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1200 pieces per month
Contact Now
Detailed Product Description
Usage: Oil,Water,drill Rig Power: Electric,diesel
Pressure: High Pressure,Low Pressure Application: Mining,oil
Structure: Piston Pump Fuel: Diesel
Standard Or Nonstandard: Standard Type: Mud Pump
Color: Green Or Per Customer Design Material: Cast Iron/stainless Steel Mud Suction Pump,Chrome Alloy
Warranty: 12 Months Product Name: Mud Pump
Oem: Can Be Accept,Applicable Condition: New

W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum

Premium's zirconia liner offers life time cost savings, significantly longer service, better performance and safer operation than those made of more commonly used alumina ceramic. Premium's zirconia liner is a proprietary Zirconium-based matrix that has significantly improved mechanical characteristics.



◎ Zirconia has three important property advantages compared to alumina.

◎ Zirconia exhibits better impact strength.

◎ Zirconia is harder than alumina.

◎ Zirconia can be honed to finer surface finishes than alumina. Finished to 4 RMS, ◎Zirconia liners - provide a surface finish that's three to four times finer than alumina.



All three of these property advantages translate to lower ownership costs. The improved wear directly extends the service life of the sleeve, while the improved impact strength cuts down on the significant costs of replacing broken liners in the field. The surface finish improvements, meanwhile, have an indirect effect. The finer surface finish means less friction with the elastomer-and-metal pump pistons, which in trun extends piston life and reduces pump-cooling requirements.



◎ HP design with shoulder-on-hull design to prevent sleeve slippage

◎ Reduced liner and piston wear

◎ Rated for all drilling operations up to 7500 PSI

◎ Bore hardness of 92-94 Rockwell

◎ ID tolerances of +.010”/ -.000”

◎ Surface finish of 4 - 8 RMS

◎ Hardness i s HV 0.3 kg/mm – 1100/1200 ( 92 - 94 Rc)

◎ High pressure design to prevent slippage

◎ Liner sizes are available from 4½” to 7” for all popular mud pumps

W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum



Mud Pump Models 4” 4-1/2” 5” 5-1/2” 6” 6-1/2” 7”
Continental Emsco F-800 / 1000 / 05495450 PREM 05495500 PREM 05495550 PREM 05495600 PREM 05495650 PREM 05495700 PREM
Continental Emsco FB-1300 / 1600 05499400 PREM 05499450 PREM 05499500 PREM 05499550 PREM 05499600 PREM 05499650 PREM 05499700 PREM
Continental Emsco FC-2200 / / 05551500 PREM 05551550 PREM 05551600 PREM 05551650 PREM 05551700 PREM
Gardner Denver PAH-275

PA I3940

05519400 PREM

PA 13945

05445450 PREM

PA 13950

05445500 PREM

 / / / /
Gardner Denver PZ-7 PY13940 PY13945

PY13950

05493087 PREM

PY13955

05493085 PREM

PY13960

05493083 PREM

PY13965

05493081PREM

PY13970

05493079 PREM
Gardner Denver PZ-8/9

206PZJ456

05493400 PREM

205PZJ456

05493450 PREM

204PZJ456

05493500 PREM

203PZJ456

05493550 PREM

202PZJ456

05493600 PREM

200PZJ456

05493650 PREM

207PZJ456

05493700 PREM
Gardner Denver PZ-10/11

206PZL456

05496400 PREM

205PZL456

05496450 PREM

204PZL456

05496500 PREM

203PZL456

05496550 PREM

202PZL456

05496600 PREM

201PZL456

05496650 PREM

200PZL456

05496700 PREM
Gardner Denver PZL

206PZL456

05496400 PREM

205PZL456

05496450 PREM

204PZL456

05496500 PREM

203PZL456

05496550 PREM

202PZL456

05496600 PREM

201PZL456

05496650 PREM

200PZL456

05496700 PREM
Gardner Denver PZL-B-7500 PSI / / 05561500HP 05561550HP 05561600HP 05561650HP 05561700HP
Gardner Denver PZL W/SWFE 7500 PSI 05465400HP 05465450HP 05465500HP 05465550HP 05465600HP 05465650HP 05465700HP
Gardner Denver PX-11 7500 PSI / / 05561500HP 05561550HP 05561600HP 05561650HP 05561700HP
Ideco T-500 / 05512450 PREM 05512500 PREM 05512550 PREM 05512600 PREM 05512650 PREM 05512700 PREM
Ideco T-800 / 1000 05502400 PREM 05502450 PREM 05502500 PREM 05502550 PREM 05502600 PREM 05502650 PREM 05502700 PREM
Ideco T-1300 / 1600 / 05507450 PREM 05507500 PREM 05507550 PREM 05507600 PREM 05507650 PREM 05507700 PREM
National 7P-50 05466040 PREM 05466045 PREM 05466050 PREM 05466055 PREM 05466060 PREM / /
National 8-P-80 05464400 PREM 05464450 PREM 05464500 PREM 05464550 PREM 05464600 PREM 05464650 PREM /
National 9-P-100 / 10-P-130 05465400 PREM 05465450 PREM 05465500 PREM 05465550 PREM 05465600 PREM 05465650 PREM /
National 12-P-160 05466400 PREM 05466450 PREM 05466500 PREM 05466550 PREM 05466600 PREM 05466650 PREM 05466700 PREM
National 14-P-220 05545400 PREM 05545450 PREM 05545500 PREM 05545550 PREM 05545600 PREM 05545650 PREM 05545700 PREM
National JWS-165/340 05531400 PREM 05531450 PREM / / / / /
National JWS-400 05524400 PREM 05524450 PREM 05524500 PREM 05524550 PREM 05524600 PREM / /
Oilwell HD-1700-PT / / 05326500 PREM 05326550 PREM 05326600 PREM 05326650 PREM 05326700 PREM
Oilwell A-600-PT 05329400 PREM 05329450 PREM 05329500 PREM 05329550 PREM 05329600 PREM 05329650 PREM 05329700 PREM
Oilwell A-850-PT / A-1100-PT 05330400 PREM 05330450 PREM 05330500 PREM 05330550 PREM 05330600 PREM 05330650 PREM 05330700 PREM
Oilwell A-1400-PT / A-1700-PT 05326400 PREM 05326450 PREM 05326500 PREM 05326550 PREM 05326600 PREM 05326650 PREM 05326700 PREM





W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum



All our fluid end parts are manufactured to API 7K quality standards.



Parts are available for these popular pump models:



BOMCO/Emsco Mud Pumps:F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,



LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600


Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,


National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,


Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,



Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT



Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200



Russian Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32



WEATHERFORD/Ellis Williams: E-447, E-2200



Drillmec: 9T1000, 12T1600, 7TS600, 7TS500, 9T800



Romania: 3PN-1000, 3PN-1600, 3PN-2000



And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.

W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum



No. P/N(HHF-1300/1600) Description Qty
1 11-3131-0201-00 Cover, main bearing 2
  11-3161-0201-00 Cover, main bearing 2
2 11-3131-0202 Sleeve, main bearing (right) 1
  11-3161-0202 Sleeve, main bearing (right) 1
3 11-3161-0203 Gasket 2
4 11-3161-0204 Insider retainer 2
5 11-3131-0205-00 Outside retainer 3
  11-3161-0205-00 Outside retainer 3
6 11-3131-0206 Eccentric strap 3
  11-3161-0206 Eccentric strap 3
7 11-3161-0207 Positioning ring (I) 1
8 11-3161-0208-00 Crankshaft 1
9 11-3161-0209 Positioning ring (II) 1
10 11-3131-0210 Bull gear 1
  11-3161-0210 Bull gear 1
11 11-3131-0211-1 Bolt, 1 1/2-8UN-2A*130 12
  11-3161-0211-2 Bolt, 1 1/2-8UN-2A*170
12 11-3161-0212 Spacer ring 2
13 11-3131-0213 Sleeve, main bearing (left) 1
  11-3161-0213 Sleeve, main bearing (left) 1
14 11-3131-0214 Retainer ring 2
  11-3161-0214 Retainer ring 2
15 11-3161-0215 Baffle 2
16 11-3161-0216 Bolt, main bearing, 3-8UN-3A 4
17 11-3161-0217 Shims As required
18 11-3161-0218 Screw, 5/8-11UNC-2A*120 2
19 11-3161-0219-00 Locking nut, 1 1/2-8UN-2B 12
20 11-3161-0220 Bolt, 5/8-11UNC-2A*40 70
21 11-3161-0227 Bolt, 5/8-11UNC-2A*50 28
22 11-3131-0221-1 Bearing, eccentric strap, 928/660.4QU 3
  11-3161-0221-2 Bearing, eccentric strap, 929/660.4QU
23 11-3131-0222-1 Main bearing, 3G4053160H 2
  11-3161-0222-2 Main bearing, 3G3003760HY
24 B0848-16-32 Flat washer, 16 28
25 11-3161-0224 Locking wire, SZ-1.50 40m
26 11-3161-0225 Locking wire, SZ-3.00 3m
27 11-3161-0226 Sealant 90ml
28 11-3161-0223 Screw, 5/8-11UNC-2A*100 2



W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum



No. P/N(HHF-1300/1600) Description Qty
1 11-3161-0301 Key, 2"*2"*241.3 1
2 11-3131-0302/11-3161-0302 Pinion Shaft 1
3 11-3161-0303 Sleeve, Seal 2
4 11-3161-0304 End Cover 2
5 11-3161-0305 Gasket, End cover 2
6 11-3161-0306 Gasket, Bearing housing 2
7 11-3161-0307 Bearing Housing 2
8 11-3161-0308 Retainer Ring 2
9 11-3161-0309 Gasket, Oil trough 2
10 11-3161-0310-00 Oil trough 2
11 11-3161-0314 Bolt, 1/2-13UNC-2A*35 24
12 11-3161-0315 Bolt, 7/8-9UNC-2A*52 16
13 11-3161-0311 Oil Seal, 9.125"*10.375"*0.625" 2
14 11-3161-0312 Bearing, 4G32844H 2
15 B0093-22-59 Spring Washer, 22 16
16 B0093-14-59 Spring Washer, 14 24
17 11-3161-0313 Flange 1
18 11-3161-0316 Bolt, 5/8-11UNC-2A*50 3
19 B0093-16-59 Spring Washer, 16 3



W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum



No. P/N(HHF-1300/1600) Description Qty
1 11-3161-0401 Crosshead 1
2 11-3161-0402 Slide, Upper 1
3 11-3161-0403-00 Shim 8
4 11-3161-0404 Shim 2
5 11-3161-0405 Stuffing Box 1
6 11-3161-0406 Oil Seal 1
7 B34521-190-355-69 O Ring, 190*3.55G 1
8 11-3161-0407 Oil Seal, 5"*6.25"*0.625" 2
9 11-3161-0408 Gasket 1
10 11-3161-0409 End Cover 1
11 11-3161-0410 Locking Spring 1
12 11-3161-0411 Baffle 1
13 11-3161-0412 Crosshead extension rod 1
14 11-3161-0413 Crosshead Pin 1
15 B34521-125-700-69 O Ring, 125*7.0G 1
16 11-3161-0420 Screw, 3/4-10UNC-2A*65 8
17 11-3161-0414 Gasket 1
18 B34521-160-700-69 O Ring,160*7.0G 1
19 11-3161-0415 Slide, Lower 1
20 11-3161-0416 Crosshead Pin Cap 1
21 11-3161-0417 Crosshead Bearing, 254941QU 1
22 11-3161-0418 Pipe Joint, NPT3/8*50.8 2
23 11-3161-0421 Bolt, 1-8UNC-2A*60 2
24 11-3161-0422 Bolt, 1-8UNC-2A*70 14
25 11-3161-0419 Slide retainer plate 8
26 11-3161-0423 Bolt, 3/8-16UNC-2A×40 4
27 B0093-10-59 Spring Washer, 10 4
28 11-3161-0424 Steel Wire Φ1.6 As required
29 11-3161-0425 Lock-fife 25ml



W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum



No. P/N(HHF-1300/1600) Description Qty
1 11-3161-0501-00 Cylinder assembly 3
2 11-3161-0502 Cylinder Cover, Threaded ring 3
3 11-3161-0503 Cylinder Cover, Threaded ring 3
4 11-3161-0504-00 Spacer assembly 3
5 11-3161-0505-00 Guide, valve lower 3
6 11-3161-0506-00 Plug, cylinder cover 3
7 11-3161-0507 Positioning panel 3
8 11-3161-0508 Seal ring, cylinder cover 3
9 11-3161-0509 Discharge manifold 1
10 11-3161-0510 Valve spring 6
11 B34521-095-530-69 O ring, 95*5.3 G 3
12 11-3161-0511-00 Valve assembly 6
13 11-3161-0512 Seal ring, valve cover 3
14 11-3161-0513 Valve cover 3
15 11-3161-0514 Seal ring, liner 6
16 11-3161-0515 Liner wear ring 3
17 11-3161-0516 Liner retainer ring 3
18 11-3161-0517-00 Liner retainer screw 3
19 11-3161-0518 Piston rod 3
20 11-3161-0519-00 Spraying pipe assembly 1
21 B34521-200-700-69 O ring, 200*7.0 G 3
22 11-3161-0520 Locking Ring, Liner Retainer screw 3
23 11-3161-0521-21 Bi-metal liner 5 3
  11-3161-0521-22 Bi-metal liner 5 1/2
  11-3161-0521-23 Bi-metal liner 6
  11-3161-0521-24 Bi-metal liner 6 1/4
  11-3161-0521-25 Bi-metal liner 6 1/2
  11-3161-0521-26 Bi-metal liner 6 3/4
  11-3161-0521-11 Ordinary liner 5
  11-3161-0521-12 Ordinary liner 5 1/2
  11-3161-0521-13 Ordinary liner 6
  11-3161-0521-14 Ordinary liner 6 1/4
  11-3161-0521-15 Ordinary liner 6 1/2
  11-3161-0521-16 Ordinary liner 6 3/4
  11-3161-0521-17 Ordinary liner 7 3
24 11-3161-0522-00 Clamp assembly, piston rod 3
25 11-3161-0523 Splash Shield, liner 3
26 11-3161-0524-00 Piston 3
27 11-3161-0542 Bolt, 7/8-9UNC-2A*60 18
28 11-3161-0525-00 Suction manifold 1
29 11-3161-0526-00 Shim 4
30 11-3161-0527 Guide, valve (upper) 3
31 11-3161-0528 Stud, 1 1/2-8UN-2A*265 16
32 11-3161-0501-06 Nut, 1 1/2-8UN-2B(SPL) 44
33 11-3161-0529 Baffle 3
34 11-3161-0530 Bolt, 3/8-16UNC-2A*20 12
35 11-3161-0531 Seal ring, piston 3
36 11-3161-0532-00 Nut, piston 3
37 B34521-190-700-69 O ring, 190*7.0 G 3
38 11-3161-0533-00 Suction damper 1
39 B34521-345-700-69 O ring, 345*7.0 G 3
40 11-3161-0534 Suction flange(Ⅰ) 1
41 11-3161-0535 Suction flange(Ⅱ) 1
42 11-3161-0543 Nut, 1 1/16-8UN-2B(SPL) 36
43 11-3161-0544 Bolt 1 1/16-8UN-2A*90 36
44 11-3161-0545 Steel wire, Φ1.60 (L=1830) 1
45 11-3161-0536 Screw plug, NPT1 1/2 1
46 11-3161-0537 Bolt, 1 1/2 12
47 11-3161-0546 Sealant: As required
48 11-3161-0538 Plug, suction let, 12" 1
49 11-3161-0539 Closure plate, discharge let, 5 1/8" 1
50 11-3161-0540 Washer, 39 30
51 11-3161-0541-00 Spring guide 3
R1 11-3161-0501-02 Stud, 1-8UNC(14UNS)-2A*185 36
R2 11-3161-0501-03 Nut, 1-8UNC-2B(SPL) 36
R3 11-3161-0501-04 Stud, 1 1/2-8UN(12UNF)-2A*170 30
R4 11-3161-0501-06 Nut, 1 1/2-8UN-2B(SPL) 60
R5 11-3161-0501-05 Stud, 1 1/2-8UN(12UNF)-2A*120 30
R6 11-3161-0501-07 Stud, 1 1/4-8UN(12UNF)-2A*195 12
R7 11-3161-0501-08 Nut, 1 1/4-8UN-2B(SPL) 12





W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum



Item Description Part No.
  Complete Assembly 8476-A
1 Threaded Flange 4476
2 Screw Gland 4597
3 Plug Assembly w/Guide & Bushing 4676-2A
4 Valve Guide 4776
5 Valve Guide Bushing 4700-I
6 Valve Guide Screw 4016-98
7 Valve Cover Stud w/Nut 4015-54
8 Power End Stud w/Nut 4015-95
9 Liner Retainer Capscrew 4017-65
10 Liner Retainer Flange 6476
11 Liner Retainer Nut 6576
12 Suction Module Stud w/Nut 4018-17
13 Suction Module (Studded) 8476-2
14 Discharge Module (Studded) 8476-1
15 Dowel Pin 8488-5
16 Wear Plate 8476-3
17 Valve Cover Plug Seal P-107
18 Module & Wear Plate Seal 2988
19 Piston Rod 1286-32
20 Sub Rod 1286-1
21 Rod Clamp w/Spray System 1286-CW



W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum





Item Description Part No.
  Complete Assembly 8490-2A
1 Threaded Flange 4475
2 Liner Wear Plate 8490-3
3 Module and Wear Plate Gasket 2988
4 Screw Gland 4575
5 Plug Assembly w/Guide & Bushing 4675-2A
6 Plug Seal P-129
7 Valve Guide 4775-2
8 Valve Guide Bushing 4700-I
9 Valve Guide Stud w/Nut 4016-99
10 Valve Cover Stud w/Nut 4015-2
11 Power End Stud w/Nut 4016-9
12 Liner Retainer Capscrew 4017-36
13 Liner Retainer Flange 6490-3
14 Liner Retainer Pilot Ring 8422-3
15 Liner Retainer Nut 6590-1
16 Suction Module Stud w/Nut 4016-97
17 Suction Module Studded 8490-2
18 Discharge Module Studded 8490-1
19 Dowel Pin 8488-5
20 Discharge Manifold Stud w/Nut 4017-46



W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum









Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300

Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600

Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652

Gardner Denver ® Mud Pumps

PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL

Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225

Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T

Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550

Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500

Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600

National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400

National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A

National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160

Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT

Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT

Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B

OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL

Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036

Fluid End Modules

National® - Oilwell® - Continental Emsco® - Gardner Denver® - Ideco® - Skytop Brewster®

Pulsation Dampener

Hydril Type "K" Pulsation Dampener

Popular Mud Pump Spare Parts

W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum



Mud Pump Manufactures and Models include:

Brewster Mud Pumps

B-550 | B-750 | B-1000 | 1100T | B-1300

Continental Emsco Mud Pumps

FF-FXF | FG-FXG (A thrugh L) | FD-FXX | FC-FXX | FD-FXD | FC-FXD | FY-FXD

Continental Emsco Mud Pumps

GP-GXP | GR-GXP | GP-GXR | GR-GXR |PA-8 | PAH

Continental Emsco Mud Pumps

PJ8 | PZ-7 | PZ-8 | PZ-9 | PZ-10 | PZ-11 | PXL

Ellis Williams (Luko) Mud Pumps

WW-440 | 14W-400 | 15W-600 | 9W-1000

Gaso Mud Pump

1563 | 1740-55 | 1844-60 | 2010-50 | 2200-49 | 2651 | 2652

Gardner Denver Mud Pumps

FF-FXF;FG-FXG;A thru L FD-FXX FC-FXX FD-FXD FC-FXD FY-FXD GP-GXP GR-GXP GP-GXR GR-GXR PA-8 PJ8 PZ-7 PZ-8 PZ-9 PZ-10 PZ-11 PXL



Ideco Mud Pumps

MM-200 | MM-300 | MM-500 | MM-500F | MM-550

Ideco Mud Pumps

MM-550F | MM-700 | MM-700F | T-500

Ideco Mud Pumps

T-800 | T-1000 | T-1300 | T-1600

National Mud Pumps

C-150 | C-250 | C-350 | E-500 | E-700 | G-700 | G-1000



National Mud Pumps

K-280 | K-380 | K-500 | K-500A | K-700A



National Mud Pumps

7P-50 | 8P-80 | 9P-100 | 10P-130 | 12P-160



Oilwell Mud Pumps

6P-HD | 610-P | 212-P | 214-P | 218-P



Oilwell Mud Pumps

350-PT | 560-PT | A-560-PT | 850-PT | A-850-PT | 1100-PT



Oilwell Mud Pumps

A-1100-PT | 1400-PT | A-1400-PT | 1700-PT | A-1700-PT



OPI Mud Pumps

350-D | 700-HDL | 1000-HDL



Wheatley Mud Pumps

1036 | 6070 | 7024 | 7036



Wilson Mud Pumps

600 | 900

W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum



Item Description Part No.
  Complete Assembly 8490-2A
1 Threaded Flange 4475
2 Liner Wear Plate 8490-3
3 Module and Wear Plate Gasket 2988
4 Screw Gland 4575
5 Plug Assembly w/Guide & Bushing 4675-2A
6 Plug Seal P-129
7 Valve Guide 4775-2
8 Valve Guide Bushing 4700-I
9 Valve Guide Stud w/Nut 4016-99
10 Valve Cover Stud w/Nut 4015-2
11 Power End Stud w/Nut 4016-9
12 Liner Retainer Capscrew 4017-36
13 Liner Retainer Flange 6490-3
14 Liner Retainer Pilot Ring 8422-3
15 Liner Retainer Nut 6590-1
16 Suction Module Stud w/Nut 4016-97
17 Suction Module Studded 8490-2
18 Discharge Module Studded 8490-1
19 Dowel Pin 8488-5
20 Discharge Manifold Stud w/Nut 4017-46





W-2214 MUD PUMP, EMSCO FB1600 Mud Pump, FB1300 mud pump, F1000 mud pump, Cameron CMP2200 Mud Pump , FC2200 mud pum





CONTINENTAL EMSCO FC-2200 FLUID END MODULE & ACCESSORIES
ITEM # PART # DESCRIPTION QTY PER PUMP
- 0-6323-0100-20 ASSY, FLUID END COMPLETE (INCLUDES DISCHARGE MANIFOLD) 1
1 0-6323-0108-00 MODULE, DISCHARGE STUDDED 3
2 0-6323-0109-00 MODULE, SUCTION STUDDED 3
3 0-6323-0087-90 RETAINER, THREADED 6
4 0-6323-0086-90 RING, THREADED 6
5 0-6323-0083-00 COVER, VALVE POT 6
6 0-6323-0103-00 GUIDE W/ BUSHING, VALVE 6
7 0-6323-0126-00 HANDLER, VALVE POT 6
8 0-6323-0107-20 COVER, LINER END 3
9 0-6323-0129-00 DISC, BAFFLE 3
10 0-6323-0085-00 MANIFOLD, SUCTION 1
11 0-6316-0105-95 FLANGE, SUCTION 1
12 0-6317-0074-95 FLANGE, BLIND 1
13 0-6323-0084-10 DISCHARGE MANIFOLD, 7500 PSI 1
14 0-6323-0097-90 WEAR PLATE 3
15 0-6323-0096-00 RING, LINER THREAD 3
16 0-6323-0099-00 LINER LOCK 3
17 0-6323-0093-00 RETAINER, VALVE GUIDE 6
18 0-6323-0128-00 SEAL, SUCTION TO DISCHAGE MODULE 3
19 0-6323-0127-00 SEAL, WEAR PLATE & LINER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
20 0-7602-1600-47 O-RING (LINER LOCK RING) 3
21 7817600456 O-RING (SUCTION MANIFOLD) 3
22 0-7602-1600-61 O-RING (SUCTION MANIFOLD TO F.E.) 3
23 0-7602-1600-30 O-RING (DISCHARGE MANIFOLD TO F.E.) 3
24 0-7501-0051-00 SCREW, RETAINER 24
25 7822095 WIRE, SAFETY SST 72
26 0-6323-0101-00 RING, LINER LOCK 3
27 7000534 SCREW, SUCTION FLANGE HEX HD 36
28 0-7601-0630-20 NUT, HEX 1" - 8 36
29 0-6323-0125-00 SEAL, VALVE POT COVER 6
30 0-7601-0333-30 SCREW, SUCTION MANIFOLD TO F.E. 18









Contact Details
Qingdao National Premium Oilwell Machinery Co.,Ltd

Contact Person: Mr. Eric

Tel: 0086-15376875239

Send your inquiry directly to us (0 / 3000)

About Us
Weatherford Mud Pumps
National Mud Pumps
Mud Pump Chrome Liner
Contact Us
Mobile Site
Privacy Policy | China Mud Pump Zirconia Liners Supplier. Copyright © 2019 - 2024 premiummudpump.com. All Rights Reserved. Developed by ECER
