MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP

China MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier
MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP supplier

Large Image :  MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP

Product Details:

Place of Origin: CHINA
Brand Name: WEATHERFORD, NATIONAL, BOMCO, GARDNER DENVER
Certification: API
Model Number: MP16, MP5, MP10

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: 40000 USD
Packaging Details: SUITABLE TO SHIPMENT
Delivery Time: IN STOCK
Payment Terms: T/T, L/C
Supply Ability: 50 SETS PER MONTH
Contact Now
Detailed Product Description
Usage: Oil,drill Rig Power: Electric,diesel
Pressure: High Pressure,low Pressure Submersible Mud Pump Sand Dredging Slurry Pump Application: Mining,oil
Structure: Piston Pump Fuel: Diesel,diesel Engine And Hydraulic Motor For Option
Standard Or Nonstandard: Standard Theory: Centrifugal Pump,Reciprocating Pump,Diaphragm Pump
Type: Mud Pump Weight: 100-3700kg
Color: Green Or Per Customer Design Material: Cast Iron/stainless Steel Mud Suction Pump,Chrome Alloy
Warranty: 12 Months Feature: Mud Suction Pump
Product Name: Mud Pump Head: 10m Mud Suction Pump
Oem: Can Be Accept,Applicable

Description F500 F800 F1000 F1300/1600 F1600HL F2200HL
Liner of Crosshead Upper AH0501010402 AH0801010402 AH1001010402 AH1301010402 AH1301010402 AH2202010402
Liner of Crosshead Lower   AH0801010408 AH1001010409 AH1301010412 AH1301010412 AH2202010403
Pin of Crosshead AH0501010404 AH0801010407 AH1001010408 AH1301010410 AH1301010410 AH2202010410
Extension Rod AH0501010410 AH0801010406 AH1001010407 AH1301010409 AH1301010409 AH2202010409
Sub Rod
Crosshead AH0501010401 AH0801010401 AH1001010401 AH1301010401 AH1301010401 AH2202010401
Pinion Shaft AH0501010302 AH0801010302 AH1001010302 AH1601010201 AH1601010201
Wear Ring of Pinion shaft AH0501010303 AH0801010303 AH1001010303 AH1301010303 AH1301010303 AH2202010306
Carrier, Bearing Left AH0501010212 AH0801010213 AH1001010212 AH1601010105 AH1601010105 AH2202010212
Carrier, Bearing Right AH0501010202 AH0801010202 AH1001010202 AH1601010101 AH1601010101 AH2202010202
Connecting Rod AH0501010206 AH0801010206 AH1001010206 AH1601010103 AH1601010103 AH2202010206
Bull Gear AH0501010210 AH0801010210 AH1001010219 AH160101010400 AH160101010400 AH220201021000
Bolt, Main Bearing AH051020207 AH0801020206 AH1001010215 AH1301010215 AH1301010215 AH2202010215
Bearing, Crosshead 5G354920Q 4G254735Q 5G254936Q AH1301010414 AH1301010414
Bearing, Pinion Shanft 4G32828H 4G32836H 4G32840H AH1301010312 AH1301010312 AH2202010315
Bearing, Eccentric 92984QU 928/508QU 929/558.8QU AH160101010700 AH160101010700 AH2202010217
Bearing, Main 3053738U 3053748H 4053156H AH160101010800 AH160101010800 AH2202010218
MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP

Weatherford offers a full line of premium-quality mud pumps based on proven and
simple-to-maintain designs that are accepted around the world. Each pump comes with
exceptional service and support that only a true global provider like Weatherford can
promise. When you factor in our competitive pricing and off-the-shelf availability of pumps
and parts, it’s clear that Weatherford has raised the bar for mud pumps.

Weatherford is building one of the world’s leading reciprocating pump organizations by giving you more pump for your money.

We build in extra-value features that don’t cost extra and give you the lasting value of pump components built for maximum
reliability and service life.

Most importantly, our people bring invaluable experience and dedication to your application. They will help you choose from
our broad range of pumps and accessories and deliver them to you faster than anyone else in the industry.

MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP

MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMPMP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMPMP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMPMP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP

MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP





All our fluid end parts are manufactured to API 7K quality standards.

Parts are available for these popular pump models:

BOMCO/Emsco Mud Pumps:F2200HL, F1600HL, F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,

LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600


Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,


National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,


Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,

Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT



Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200



Russian Mud Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32



WEATHERFORD/Ellis Williams: E-447, E-2200



Drillmec Mud Pump: 9T1000, 12T1600, 7TS600, 7TS500, 9T800



Romania Mud Pump: 3PN-1000, 3PN-1600, 3PN-2000



And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.



MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP



1,Plunger Size 3.38” - 4.00” Valve Part No. P107185 Seat Part No. P107802
Insert Part No. P107186 Spring
2,Plunger Size 4.50” Valve Part No. P107181 Seat Part No. P107180
Insert Part No. P107182 Spring
3,Plunger Size 5.00” - 6.00” Valve Part No. P107188 Seat Part No. P107187
Insert Part No. P107189 Spring4P102382
SPM2000压裂泵的型号及规格
1,Plunger Size 3.75" Plunge Part No 3P103887
2,Plunger Size 4.00" Plunge Part No 3P100339
3,Plunger Size 4.50" Plunge Part No 3P100654
4,Plunger Size" 5.00" Plunge Part No 3P100233
5,Plunger Size" 5.50 Plunge Part No 3P107060
6,Plunger Size" 5.75" Plunge Part No 3P107061
7,Plunger Size 6.00 Plunge Part No 3P107062
SPM压裂泵的型号
TWS 250 Plunger Size 1.75"-3" 3.25"-4"
TWS 400 Plunger Size 2 .50"-3" 3 .50"-4 .50”
TWS 500LW-600 Plunger Size 2 .75" 3"-4 .75"
TWS 600S Plunger Size 2 .50"-3" 3.50"-4 .50"
TWS 900 Plunger Size 3.50"-4"
TWS 1250LW Plunger Size 4"
OPI880 Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0”
TWS1000LW,TWS1300
Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0” 6.5 “ 6.75”
TWS1600 Plunger Size 3.5” 3.75” 4.0” 4.50” 5.0” 5.5” 5.75 “6.0”
TWS1800 Plunger Size 3.5” 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0”
TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
5.50” 5.75” 6.0”
TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5



MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP



Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300
Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600
Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652
Gardner Denver ® Mud Pumps
PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL
Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225
Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T
Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550
Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500
Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600
National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400
National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A
National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160
Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT
Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT
Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B
OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL
Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036
Fluid End Modules



MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP



Description

MP-5

Mud Pump

MP-10

Mud Pump

MP-13

Mud Pump

MP-16

Mud Pump
Liner of Crosshead Upper 1198383 1124876 1134260 1134260
Liner of Crosshead Lower 1198383 1124887 1134268 1134268
Pin of Crosshead 1198389 0908381 908404 908404
Extension Rod 1198419 0908378 908402 908402
Crankshaft 1198311 0908355 0908384 0908384
Crosshead 1198380 0908368 908399 908399
Pinion Shaft 1198346 1124723 1134026 1134026
Wear Ring of Pinion shaft 1198347 1124724 1134027 1134027
Seal, Oil 1198356 1124733 1844173 1844173
Double Oil Seal 1317783 1317770 1133825 1133825
Connecting Rod 1198309 0908362 0908427 0908427
Bull Gear 1198318 0908357 0908408 0908408
Stuffing Box 1198347 1124724 1134263 1134263
Bolt, Main Bearing 1198328 1280235 1133853 1133853
Bearing, Wrist Pin   0908364 908429 908429
Bearing, Pinion Shanft 1198357 0908356 0908397 0908397
Bearing, Eccentric 1198337 1280232 0908442 0908442
Bearing, Main 1198338 1280233 0908425 0908425





MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP



CONTINENTAL EMSCO F-1300, F-1600
FLUID END MODULE & ACCESSORIES

ITEM TSC PART NUMBER BAOJI PART NUMBER DESCRIPTION QTY/PUMP
  TS-6316-0325-00 AH36001-05.01A.00 FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEM 2-24, 26- 29) 3
1 TS-6316-0357-00   FLUID END MODULE STUDDED (INCLUDES ITEM 2-9) 3
2 TS-6316-0356-00   FLUID END MODULE ONLY (UNSTUDED) 3
3 TS-7507-2013-00 T53-3008 STUD, MODULE TO LINER CLAMP 36
4 TS-7601-0610-18 AH36001-05.01A.03 LINER CLAMP STUD NUT 36
5 TS-7507-2201-00 T53-3005 POWER FRAME STUD 18
6 TS-7507-2210-00 T53-3007 STUD, MODULE TO CYLINDER 18
7 TS-7601-0630-17 T57-2011 NUT (FOR ABOVE) 72
8 TS-7507-2108-00 T53-3006 STUD, MODULE TO DISC. MANIFOLD 12
9 TS-7601-0630-24 T57-2009 NUT (FOR ABOVE) 12
10 TSF16-05-04 AH36001-05A.04.00 RETAINER, LOWER VALVE 3
11 TSF16-05-05 AH36001-05A.05.00 LOWER VALVE GUIDE ASSEMBLY 3
12 TSF16-05-07 AH36001-05A.07 ALIGNMENT RING 3
13 TS-6316-0369-00 AH36001-05.08 GASKET, HEAD SEAL (G-801) 3
14 TS-6316-0364-00 AH36001-05A.06.00 PLUG, CYLINDER HEAD 3
15 TS-6316-0361-00 AH36001-05.02 RING, THREADED CYLINDER HEAD 3
16 TS-6316-0362-00 AH36001-05.03 CAP, THREADED CYLINDER HEAD 3
17 TS-6316-0092-00 AH36001-05.13 GASKET, VALVE COVER (G-741) 3
18 TS-7501-0051-00 AH33001-05.15A SCREW, RETAINER (UPPER) 3
19 TS-6397-0603-00 AH33001-05.14 PLATE, RETAINER (UPPER) 12
20 TS-6397-0575-00 AH33001-05.12 GUIDE, UPPER VALVE 3
21 TS-6316-0039-00 AH36001-05.14A COVER, VALVE POT 3
22 TS-6316-0373-00 AH36001-05.15 GASKET, LINER (G-800) 6
23 TS-6316-0365-00 AH36001-05.16A WEAR PLATE 3
24 TS-6316-0366-00 AH36001-05.17 RING, LINER THREADED 3
25 TS-6316-0367-00 AH36001-05.18.00 LINER LOCK 3
26 TS-7602-1600-25 GB3452.1-82"O"ф95×5.3　　 GASKET, DISCHARGE MANIFOLD 3
27 TS-7602-1600-61 GB3452.1-82"O"ф185×7 GASKET, SUCTION MANIFOLD 3
28 TS-F16-05-35 AH36001-05.35B STUD, 12

MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP

NATIONAL 12-P-160
FLUID END MODULE & ACCESSORIES

ITEM PART NUMBER DESCRIPTION QTY/PUMP
    FLUID END MODULE COMPLETE ASSEMBLY
1 TS-1292240 MODULE, STUDDED FLUID END DISCHARGE (INCLUDES ITEM 2-10) 3
2 TS-1292241 DISCHARGE MODULE ONLY 3
3 TS-6300220 NUT, POWER FRAME STUD 24
4 TS-2408029 STUD, POWER FRAME 24
5 TS-6300180 NUT, LINER BUSHING STUD 18
6 TS-2408028 STUD, LINER BUSHING 18
7 TS-6300281 NUT, DISCHARGE TO SUCTION MODULE STUD 18
8 TS-2408033 STUD, DISCHARGE MODULE TO SUCTION MODULE 18
9 TS-6300240 NUT, THREADED RING STUD 36
10 TS-2408027 STUD, THREADED RING 36
11 TS-1292243 MODULE, STUDDED FLUID END SUCTION (INCLUDES ITEM 12,13,14 ) 3
12 TS-1292244 SUCTION MODULE ONLY 3
13 TS-6300240 NUT, THREADED RING STUD 36
14 TS-2408027 STUD, THREADED RING 36
15 TS-1292165 BUSHING, LINER 3
16 TS-1292174 RETAINER, SEAL 6
17 TS-1292172 CAP, VALVE COVER (THREADED) 6
18 TS-1292178 SCREW, ADJUSTING WEDGE 6
19 TS-1292171 WASHER, WEDGE ADJUSTING SCREW 6
20 TS-6300182 NUT, WEDGE ADJUSTING SCREW 6
21 TS-1292176 RING, THREADED 6
22 TS-G1292268 ASSEMBLY, WEDGE (INCLUDES ITEM 18) 6
23 TS-1540127 GASKET, VALVE COVER 6
24 TS-1292140 RETAINER, VALVE GUIDE BUSHING 6
25 TS-1292141 BUSHING, VALVE GUIDE 6
26 TS-6511416 PIN, DOWELL 6
27 TS-1292266 PLATE, WEAR 3
28 TS-1292252 CONNECTOR, DISCHARGE 2
29 TS-700030711 CAPSCREW, DISCHARGE CONNECTOR 16
30 N/A WASHER, LOCK 16
31 TS-1292253 ADAPTER, DISCHARGE CONNECTOR 2
32 TS-2410031433 SEAL, DISCHARGE CONNECTOR TO DISCHARGE ADAPTER 2
33 TS-2410031437 SEAL, DISCHARGE CONNECTOR & DISCHARGE ADAPTER 4
34 TS-1292166 ASSEMBLY, LINER CLAMP 3
35 TS-700049110 CAPSCREW, LINER CLAMP 6
36 TS-6309140 NUT, LINER CAPSCREW 6
37 TS-1292169 PIN, CONNECTOR 3
38 TS-1292168 CONNECTOR, LINER CLAMP 3
39 TS-2408015 STUD, TOP TAPER LOCK (FOR BLIND RING AND WELD NECK FLANGES) 16
40 TS-6300240 NUT, STUD (BLIND RING AND WELD NECK FLANGES)

16







MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP





NATIONAL FB1300/1600(SW)
FLUID END MODULE & ACCESSORIES

ITEM PART NUMBER DESCRIPTION QTY/PUMP
    FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEM 1-27) 3
1 TS-84901D MODULE, STUDDED DISCHARGE (INCLUDES ITEMS 1, 3-10, 11) 3
2 TS-84902S MODULE, STUDDED SUCTION (INCLUDES ITEMS 2, 12, 13) 3
3 TS-4016-97 STUD, DISCHARGE MODULE TO SUCTION MODULE 18
4 TS-0-7601-0630-17 NUT, DISCHARGE TO SUCTION MODULE STUD 18
5 TS-4015-2 STUD, THREADED RING 36
6 TS-6300200 NUT, THREADED RING STUD 36
7 TS-4016-9 STUD, POWER FRAME 18
8 TS-0-7601-0630-17 NUT, POWER FRAME STUD 18
9 TS-4017-46 STUD, DISCHARGE MANIFOLD 12
10 TS-0-7601-0630-24 NUT, DISCHARGE MANIFOLD STUD 12
11 TS-4017-36 CAPSCREW, LINER RETAINER FLANGE (SOCKET HEAD) 24
12 TS-4015-2 STUD, THREADED RING 36
13 TS-6300200 NUT, THREADED RING STUD 36
14 TS-8488-5 PIN, DOWELL 6
15 TS-2988 SEAL, SUC TO DISCH MOD & WEAR PLATE - RUBBER (SEE DATASHEET FOR ALT MATLS) 6
16 TS-8422-3 RING, LINER RETAINER PILOT 3
17 TS-8490-3 PLATE, LINER WEAR 3
18 TS-6490-3 FLANGE, LINER RETAINER 3
19 TS-6590-1 NUT, LINER LOCK 3
20 TS-P-129 GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
21 TS-4016-99 STUD,VALVE GUIDE 12
22   NUT,STUD VALVE GUIDE 12
23 TS-4700-I BUSHING, VALVE GUIDE 6
24 TS-4775-2R GUIDE, VALVE (INCLUDES ITEM 20) 6
25 TS-4675-2A PLUG, VALVE COVER 6
26 TS-4475 RING, THREADED 6
27 TS-4575 CAP, VALVE COVER (THREADED) 6



MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP



Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300

Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600

Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652

Gardner Denver ® Mud Pumps

PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL

Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225

Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T

Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550

Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500

Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600

National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400

National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A

National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160

Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT

Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT

Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B

OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL

Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036

Fluid End Modules

National® - Oilwell® - Continental Emsco® - Gardner Denver® - Ideco® - Skytop Brewster®

Pulsation Dampener

Hydril Type "K" Pulsation Dampener

Popular Mud Pump Spare Parts





Mud Pump Manufactures and Models include:

Brewster Mud Pumps

B-550 | B-750 | B-1000 | 1100T | B-1300

Continental Emsco Mud Pumps

FF-FXF | FG-FXG (A thrugh L) | FD-FXX | FC-FXX | FD-FXD | FC-FXD | FY-FXD

Continental Emsco Mud Pumps

GP-GXP | GR-GXP | GP-GXR | GR-GXR |PA-8 | PAH

Continental Emsco Mud Pumps

PJ8 | PZ-7 | PZ-8 | PZ-9 | PZ-10 | PZ-11 | PXL

Ellis Williams (Luko) Mud Pumps

WW-440 | 14W-400 | 15W-600 | 9W-1000

Gaso Mud Pump

1563 | 1740-55 | 1844-60 | 2010-50 | 2200-49 | 2651 | 2652

Gardner Denver Mud Pumps

FF-FXF;FG-FXG;A thru L FD-FXX FC-FXX FD-FXD FC-FXD FY-FXD GP-GXP GR-GXP GP-GXR GR-GXR PA-8 PJ8 PZ-7 PZ-8 PZ-9 PZ-10 PZ-11 PXL



Ideco Mud Pumps

MM-200 | MM-300 | MM-500 | MM-500F | MM-550

Ideco Mud Pumps

MM-550F | MM-700 | MM-700F | T-500

Ideco Mud Pumps

T-800 | T-1000 | T-1300 | T-1600

National Mud Pumps

C-150 | C-250 | C-350 | E-500 | E-700 | G-700 | G-1000



National Mud Pumps

K-280 | K-380 | K-500 | K-500A | K-700A



National Mud Pumps

7P-50 | 8P-80 | 9P-100 | 10P-130 | 12P-160



Oilwell Mud Pumps

6P-HD | 610-P | 212-P | 214-P | 218-P



Oilwell Mud Pumps

350-PT | 560-PT | A-560-PT | 850-PT | A-850-PT | 1100-PT



Oilwell Mud Pumps

A-1100-PT | 1400-PT | A-1400-PT | 1700-PT | A-1700-PT



OPI Mud Pumps

350-D | 700-HDL | 1000-HDL



Wheatley Mud Pumps

1036 | 6070 | 7024 | 7036



Wilson Mud Pumps

600 | 900



MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP



MISSION "L" MODULE FOR EMSCO FB-1300, FB-1600
FLUID END MODULE & ACCESSORIES
ITEM # OEM PART # MISSION PART #
    FEMFB13ASSYSW FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS: 1 - 27)
1 8490-1D FEMFB13DISSW MODULE, DISCHARGE STUDDED (INCLUDES ITEMS:1, 3-11)
2 8490-2S FEMFB13SUCSW MODULE, SUCTION STUDDED (INCLUDES ITEMS: 2, 5, 6, & 27)
3 4016-97 OWA17DSUCSSW STUD, DISCHARGE TO SUCTION MODULE
4   EMSF1000PFSN NUT, DISCHARGE TO SUCTION STUD
5 4015-2 OWA17TRSSW STUD, THREADED RING
6   PZ789GPFSN NUT, THREADED RING STUD
7 4016-9 EMSFB13PFSSW STUD, POWER FRAME
8   EMSF1000PFSN NUT, POWER FRAME STUD
9 4017-36 PEP80 CAPSCREW, LINER RETAINER FLANGE (SOCKET HEAD)
10 4017-46 FB1300DMSSW STUD, DISCHARGE MANIFOLD
11   IDT800TRSN NUT, DISCHARGE MANIFOLD STUD
12 8488-5 PEP70 PIN, DOWELL
13 2988 1290344 SEAL, SUC TO DISCH MOD & WEAR PLATE - RUBBER (SEE DATASHEET FOR ALT MATLS)
14 8422-3 EMSF1000ARSW RING, LINER RETAINER PILOT
15 8490-3 EMSFB13WPSW PLATE, LINER WEAR
16 6490-3 EMSFB13LRPSW FLANGE, LINER RETAINER
17 6590-1 EMSFB13LLSW NUT, LINER LOCK
18 P-129 07207129 GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS)
19 4016-99 PEP73 CAPSCREW, VALVE GUIDE
20 4700-I PZ789VGI BUSHING, VALVE GUIDE
21 4775-2R EMSFB13VGASW GUIDE, VALVE (INCLUDES ITEMS 20, 21)
22 4675-2A EMSFB13VCASW PLUG, VALVE COVER (INCLUDES ITEMS 19-22)
23 4475 OWA17FLGSW RING, THREADED
24 4575 OWA17CAPSW CAP, THREADED
25 568-343 99609343 GASKET, DISCHARGE MANIFOLD
26 568-442 99609442 GASKET, SUCTION MANIFOLD
27 4018-19 700048511 CAPSCREW, SUCTION MANIFOLD
  6278-25 HT204A ROD, PISTON (INCLUDES 10305203 STUD) NOT SHOWN
  6284-1 2145B ROD, SUB (NOT SHOWN)
  1290-2 10305203 STUD, CONNECTING (NOT SHOWN)





ITEM NO.



PART NO.



DESCRIPTION

 QTY. REQ’D
  8404-25A FLUID END ASSEMBLY: (CONSISTS OF ITEMS: 3,4,17,18,19,20,21,22,23,24,25,26,27,28,29,30,31,34,35,36,38,39,41,42)
1 1376YXX LINER REFER TO GUIDE FOR ORDERING CHART ON PG. 6 FOR TYPE (G); (Y); AND FOR BORE SIZE (XX) 3
2 2930-XX LINER SEAL (ALSO AVAILABLE IN URETHANE PART# 2930-XXU) 3
3 8490-28 LINER WEARPLATE (WITH 568-443 O-RING) 3
4 2988 WEARPLATE AND MODULE SEAL (ALSO AVAILABLE IN URETHANE PART# 2988U) 6
5 XX-BYY PISTON REFER TO GUIDE FOR ORDERING CHART ON PG. 6 FOR SIZE (XX) AND FOR TYPE (YY) 3
6 568-225 PISTON SEAL 3
7 6278-25 PISTON ROD (WITH ELASTIC STOP NUT) 3
8 API-4ESN PISTON ROD NUT 3
9 1290-2 PISTON ROD CONNECTING STUD 3
10 6284-1 SUB ROD 3
11 6274CWY ROD CLAMP (WITH WATER JACKET) 3
11A 1200H30 HOSE (1/2” X 30” WITH 1/2” MALE X 3/8” MALE CONNECTIONS) 3
11B 1286CWYFP ROD CLAMP WATER SPRAY MANIFOLD WITH PIPE 3
11C 4020-29 BOLT (7/8-9 GRADE 8 BOLT WITH LOCK NUT AND WASHER) 6
12 1200G74 PONY ROD 3
13 SEE PAGE VALVE 6
14 SEE PAGE VALVE INSERT 6
15 SEE PAGE VALVE SPRING 6
16 SEE PAGE VALVE SEAT 6
  SWTM1700 HYDRAULIC SEAT PULLER KIT COMPLETE (REFER TO TOOLS SECTION IN CATALOG) 1
17 4488-25 VALVE COVER FLANGE 6
18 4588-25 SCREW GLAND 6
19 4690-25A PLUG (COMPLETE WITH VALVE GUIDE; BUSHING; AND SCREWS) INCLUDES ITEMS 20, 21, 22, &23 6
20 P115 HP VALVE COVER PLUG NITRILE SEAL (ALSO AVAILABLE IN URETHANE PART # P115U) 6
21 4788-25R VALVE GUIDE (COMPLETE WITH BUSHING #4700I) 6
22 4700I VALVE GUIDE INSERT (ALSO AVAILABLE IN URETHANE PART # 4700IU) 6
23 4018-18 VALVE GUIDE SCREW 12
24 4015-2 VALVE COVER STUD (WITH SW PART# HHN1250-7 1 1/4"-7 HEAVY HEX NUT) 72




FLUID END TYPE MODEL OF PUMP SIZE OF PUMP
SOUTHWEST 7500 P.S.I. BOMCO F-1600 7 ½” X 12”

MP5 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, PZ9 MUD PUMP, MP10 MUD PUMP, PZ11 MUD PUMP, MP16 MUD PUMP

ITEM NO.



PART NO.



DESCRIPTION

 QTY. REQ’D
25 4017-33 POWER END STUD (WITH SW PART# HHN1500-8 1 1/2"-8 HEAVY HEX NUT) 30
26 568-443 WEARPLATE 'O' RING 3
27 6490-25 LINER RETAINER FLANGE 3
28 4019-51 LINER RETAINER CAPSCREW 36
29 6590-25 LINER RETAINER NUT 3
30 4019-61 SUCTION MODULE STUD (WITH SW PART# HHN1750-8 1 3/4"-8 HEAVY HEX NUT) 18
31 4018-19 SUCTION MANIFOLD CAPSCREW 18
32 8590-6 SUCTION MANIFOLD 1
33 568-442 SUCTION MANIFOLD 'O' RING 3
34 8404-26 SUCTION MODULE 3
35 8404-27 DISCHARGE MODULE 3
36 8488-5 DOWEL PIN 6
37 8376-25MOD DISCHARGE MANIFOLD 1
38 4019-60 DISCHARGE MANIFOLD STUD (WITH SW PART# HHN1250-7 1 1/4"-7 HEAVY HEX NUT) 18
39 2988 DISCHARGE MANIFOLD SEAL 3
40 6490-25P LINER RETAINER PULLER 1
41 LW875 LOCKWASHER 7/8 18
42 LW500 LOCKWASHER ½ 12







Contact Details
Qingdao National Premium Oilwell Machinery Co.,Ltd

Contact Person: Mr. Eric

Tel: 0086-15376875239

Send your inquiry directly to us (0 / 3000)

About Us
Weatherford Mud Pumps
National Mud Pumps
Mud Pump Chrome Liner
Contact Us
Mobile Site
Privacy Policy | China Weatherford Mud Pumps Supplier. Copyright © 2019 - 2024 premiummudpump.com. All Rights Reserved. Developed by ECER
