MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS

China MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier
MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS supplier

Large Image :  MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS

Product Details:

Place of Origin: USD, CHINA
Brand Name: NATIONAL OILWELL, SOUTHWEST
Certification: API
Model Number: NATIONAL 12P-160 7500 PSI

Payment & Shipping Terms:

Minimum Order Quantity: 1 PIECE
Price: 1 TO 500 USD
Packaging Details: Suitable to shipment by sea and air
Delivery Time: IN STOCK
Payment Terms: L/C, T/T
Supply Ability: 2000 PIECES PER MONTH
Contact Now
Detailed Product Description
Usage: Oil,Water,drill Rig Power: Electric,Hydraulic,Pneumatic,diesel
Pressure: High Pressure,Low Pressure,low Pressure Submersible Mud Pump Sand Dredging Slurry Pump Application: Mining,oil
Structure: Piston Pump,Single-stage Pump Fuel: Diesel,Electric
Standard Or Nonstandard: Standard Theory: Centrifugal Pump
Type: Mud Pump Weight: 100-3700kg
Color: Red And So On,Green Or Per Customer Design Material: Cast Iron/stainless Steel Mud Suction Pump,Chrome Alloy,Stainless Steel Aluminum Plastic Etc
Warranty: 12 Months Product Name: Mud Pump
Oem: Can Be Accept,Applicable Inlet Pipe (mm)/(in): DN200 / 8
Condition: New

SOUTHWEST 7500 P.S.I. BOMCO F-1600 7 ½” X 12”



ITEM NO.



PART NO.



DESCRIPTION

 QTY. REQ’D
  8404-25A FLUID END ASSEMBLY: (CONSISTS OF ITEMS: 3,4,17,18,19,20,21,22,23,24,25,26,27,28,29,30,31,34,35,36,38,39,41,42)
1 1376YXX LINER REFER TO GUIDE FOR ORDERING CHART ON PG. 6 FOR TYPE (G); (Y); AND FOR BORE SIZE (XX) 3
2 2930-XX LINER SEAL (ALSO AVAILABLE IN URETHANE PART# 2930-XXU) 3
3 8490-28 LINER WEARPLATE (WITH 568-443 O-RING) 3
4 2988 WEARPLATE AND MODULE SEAL (ALSO AVAILABLE IN URETHANE PART# 2988U) 6
5 XX-BYY PISTON REFER TO GUIDE FOR ORDERING CHART ON PG. 6 FOR SIZE (XX) AND FOR TYPE (YY) 3
6 568-225 PISTON SEAL 3
7 6278-25 PISTON ROD (WITH ELASTIC STOP NUT) 3
8 API-4ESN PISTON ROD NUT 3
9 1290-2 PISTON ROD CONNECTING STUD 3
10 6284-1 SUB ROD 3
11 6274CWY ROD CLAMP (WITH WATER JACKET) 3
11A 1200H30 HOSE (1/2” X 30” WITH 1/2” MALE X 3/8” MALE CONNECTIONS) 3
11B 1286CWYFP ROD CLAMP WATER SPRAY MANIFOLD WITH PIPE 3
11C 4020-29 BOLT (7/8-9 GRADE 8 BOLT WITH LOCK NUT AND WASHER) 6
12 1200G74 PONY ROD 3
13 SEE PAGE VALVE 6
14 SEE PAGE VALVE INSERT 6
15 SEE PAGE VALVE SPRING 6
16 SEE PAGE VALVE SEAT 6
  SWTM1700 HYDRAULIC SEAT PULLER KIT COMPLETE (REFER TO TOOLS SECTION IN CATALOG) 1
17 4488-25 VALVE COVER FLANGE 6
18 4588-25 SCREW GLAND 6
19 4690-25A PLUG (COMPLETE WITH VALVE GUIDE; BUSHING; AND SCREWS) INCLUDES ITEMS 20, 21, 22, &23 6
20 P115 HP VALVE COVER PLUG NITRILE SEAL (ALSO AVAILABLE IN URETHANE PART # P115U) 6
21 4788-25R VALVE GUIDE (COMPLETE WITH BUSHING #4700I) 6
22 4700I VALVE GUIDE INSERT (ALSO AVAILABLE IN URETHANE PART # 4700IU) 6
23 4018-18 VALVE GUIDE SCREW 12
24 4015-2 VALVE COVER STUD (WITH SW PART# HHN1250-7 1 1/4"-7 HEAVY HEX NUT) 72

FLUID END TYPE MODEL OF PUMP SIZE OF PUMP
SOUTHWEST 7500 P.S.I. BOMCO F-1600 7 ½” X 12”



ITEM NO.



PART NO.



DESCRIPTION

 QTY. REQ’D
25 4017-33 POWER END STUD (WITH SW PART# HHN1500-8 1 1/2"-8 HEAVY HEX NUT) 30
26 568-443 WEARPLATE 'O' RING 3
27 6490-25 LINER RETAINER FLANGE 3
28 4019-51 LINER RETAINER CAPSCREW 36
29 6590-25 LINER RETAINER NUT 3
30 4019-61 SUCTION MODULE STUD (WITH SW PART# HHN1750-8 1 3/4"-8 HEAVY HEX NUT) 18
31 4018-19 SUCTION MANIFOLD CAPSCREW 18
32 8590-6 SUCTION MANIFOLD 1
33 568-442 SUCTION MANIFOLD 'O' RING 3
34 8404-26 SUCTION MODULE 3
35 8404-27 DISCHARGE MODULE 3
36 8488-5 DOWEL PIN 6
37 8376-25MOD DISCHARGE MANIFOLD 1
38 4019-60 DISCHARGE MANIFOLD STUD (WITH SW PART# HHN1250-7 1 1/4"-7 HEAVY HEX NUT) 18
39 2988 DISCHARGE MANIFOLD SEAL 3
40 6490-25P LINER RETAINER PULLER 1
41 LW875 LOCKWASHER 7/8 18
42 LW500 LOCKWASHER ½ 12

  8590-6BFA

BLIND FLANGE IS AVAILABLE FOR CAPPING UNUSED FLANGES ON 8590-6 SUCTION MANIFOLD –

(8590-6BFA INCLUDES 8590-6BF BLIND FLANGE AND 568-456 O-RING) SEE SEPARATE PG. FOR DETAILS






SOUTHWEST 7500 P.S.I. BOMCO F-1600 GUIDE TO ORDERING
PISTONS LINERS LINER SEALS
SIZE FAIL-SAFE DUAL-DURO® BLACK CAT GRAYLOY® ZIRCONIA RUBBER URETHANE
4" 76BFS 76BDD 76BBC 1376G06   2930-06 2930-06U
4 1/4" 77BFS 77BDD 77BBC 1376G07   2930-07 2930-07U
4 1/2" 78BFS 78BDD 78BBC 1376G08 1376ZIR08 2930-08 2930-08U
4 3/4" 79BFS 79BDD 79BBC 1376G09 1376ZIR09 2930-09 2930-09U
5" 81BFS 81BDD 81BBC 1376G1 1376ZIR1 2930-1 2930-1U
5 1/4" 82BFS 82BDD 82BBC 1376G2   2930-2 2930-2U
5 1/2" 83BFS 83BDD 83BBC 1376G3 1376ZIR3 2930-3 2930-3U
5 3/4" 84BFS 84BDD 84BBC 1376G4 1376ZIR4 2930-4 2930-4U
6" 85BFS 85BDD 85BBC 1376G5 1376ZIR5 2930-5 2930-5U
6 1/4" 86BFS 86BDD 86BBC 1376G6 1376ZIR6 2930-6 2930-6U
6 1/2" 87BFS 87BDD 87BBC 1376G7 1376ZIR7 2930-7 2930-7U
6 3/4" 88BFS 88BDD 88BBC 1376G8   2930-8 2930-8U
7" 89BFS 89BDD 89BBC 1376G9 1376ZIR9 2930-9 2930-9U
7 1/4" 91BFS 91BDD 91BBC 1376G10 1376ZIR10 2974-11 2974-11U
7 1/2" 92BFS 92BDD 92BBC 1376G11   2974-11 2974-11U



NOTE: DUAL-DURO® AND GRAYLOY® ARE REGISTERED TRADEMARKS OF SOUTHWEST OILFIELD PRODUCTS, INC.


VALVES & SEATS (BOMCO F-1600)



TYPE



VALVE



INSERT



SPRING



STAINLESS SPRING



SEAT



PULLER HEAD

PULLER HEAD

STYLE
SOUTHWEST (Full Open) 773-1B N/A SW5710-110L N/A 873-1 SWTM3750 SPLIT JAW

FULL OPEN-ROUGHNECK

(Cast N Place Insert)

 SWND-6V2 N/A SW5710-115 N/A SWND-6S4

SWTM27SXN

SWND-6PH

SPLIT JAW

PANCAKE

FULL OPEN-ROUGHNECK

(High Temp)

 SWND-6V2H N/A SW5710-115 N/A SWND-6S4

SWTM27SXN

SWND-6PH

SPLIT JAW

PANCAKE

FULL OPEN-ROUGHNECK

(w/Replaceable Urethane Insert)

 SWND-6V1 SWND-6I SW5710-115 N/A SWND-6S4

SWTM27SXN

SWND-6PH

SPLIT JAW

PANCAKE
3 WEB DOUBLE ANGLE O-RING SWR0500119 SWR0515845 SWR0513744 SWR0514790 SWR0512436 SWTM3-7D



3 J HOOK
3 WEB (High Temp) SWR0520586 SWR0520585 SWR0513744 SWR0514790 SWR0512436 SWTM3-7D
3 WEB STANDARD PLATE SWR0505038 SWR0504890 SWR0515575 SWR0514790 SWR0512436 SWTM3-7D
4 WEB SWU5B-EH SWUDD-6AB SW5710-115 N/A SW6ADD-B4 SWTM4-6 4 J HOOK



MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS





Southwest Oilfield Products 10340 Wallisville Road, Houston, TX 77013 Office 713-675-7541











NATIONAL     12-P-160HP       7-1/4 x 12
  LINERS LINER GASKETS PISTONS PISTON REPLACEMENT RUBBERS
SIZE CERAMIC SUPREME     BLUE LIGHTNING GREEN DUO WHITE LIGHTNING SUPREME WHITE LIGHTNING SUPREME
4"         MB40-15 1502052   012180170   015180102
4 1/4"
4 1/2"         MB44-15 1502054 012180197 012180196 015180145 015180144
4 3/4"
5" 07466500 05466500* 07923265 07211011 MB50-15 1502056 012180254 012180253 015180186 015180185
5 1/4"
5 1/2" 07466550 05466550* 07923263 07211005 MB54-15 1502058 012180338 012180337 015180228 015180227
5 3/4"
6" 07466600 05466600* 07923261 07211004 MB60-15 1502060 012180395 012180394 015180269 015180268
6 1/4"   05466625* 07923283     1502061   012180493 015180285 015180284
6 1/2" 07466650 05466650* 07923284 07211003 MB64-15 1502062 012180536 012180535 015180301 015180300
6 3/4"
7" 07466700 05466700* 07923285 07211002 MB70-15 1502064 012180619 012180618 015180343 015180342
7 1/4"
7 1/2"
7 3/4"
8"
* For HP style liner, add "HP" to end of part no.
VALVES, SEATS, SPRINGS & INSERTS   GASKETS
  ROUGHNECK ROUGHNECK HP SUPREME FKN   OEM OEM URETHANE L STYLE L STYLE URETHANE L STYLE W.L.
VALVE-White Lightning Insert 9700367 9700359 060152809 N/A Valve Cover 07916771 07916467
VALVE-Urethane Insert 9700285 9700353 060152808 1560995 Wear Plate
VALVE-Rubber Insert 9702601 N/A 060122702 1560994 Liner Retention Systems OEM MISSION L
SEAT 9702555 9702555 061102604 1561450 Liner Retention Systems 80501100 80501100
SPRING 8201684 8201684 055413421 1560701 Blak-JAK LOK-CEL 80502100 80502100
SPRING-Stainless     055402945   Blak-JAK Hydra-Cell 80500100 80500100
INSERT-Urethane 9705090 9700363 062400106 1560587 MODULES OEM MISSION L
INSERT-Rubber 9705155 N/A 062400056 1560588 Complete Assembly
SEAT PULLER ASSEMBLIES Discharge Module Studded 1292726
Puller Assembly 1 M 1060 M 1060 M 1060 M 1060 Suction Module Studded 1292727
Puller Head 8401977 8401977 181235052 M 1089 One Piece OEM Style Studded

Crosshead Extension Rods, Quick Connect Rods, Self Aligning Rod Assemblies & Piston Rods
Crosshead Rod Quick Connect Self Aligning Rod Assy Rod Nut Piston Rod Sub Rod Pony Rod Baffle Piston Rod Clamp Covered Rod Nut Pony Rod Seal
1602586   2095220 005402052 1292147 1292146 1292194 W/SPRAY 80701024 CRN-1
              WO/SPRAY 005417357





MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS



GARDNER DENVER PZ-10, PZ-11 MISSION MODULE SERIES 7 VALVE SEAT DECKS       QTY PER PUMP
FLUID END MODULE & ACCESSORIES
ITEM # OEM PART # MISSION PART #
    FEMPZ1011WPCA FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS 1-13, 15-22) 3
1 202PZL029B FEMPZ1011 FLUID END MODULE STUDDED (INCLUDES 1-8 & 24) 3
02 201PZL110 PZ1011LCS STUD, FRAME & LINER CLAMP LONG 24
03 205PZL110 PZ1011GPFS STUD, SHORT 24
04 50B36 PZ789LCSN NUT, FRAME & LINER CLAMP STUD 72
05 204PZL110 PZ1011TRS STUD 72
06 50B34 PZ789TRSN NUT (FOR ABOVE) 72
07 202PZL110 PZ789DMS STUD, DISCHARGE MANIFOLD 12
08 50B34 PZ789TRSN NUT (FOR ABOVE STUD) (SAME AS ITEM 6) 12
09     CAPSCREW, SUCTION MANIFOLD - NOT SHOWN 24
10 200PZL387 PZ1011FLG RING, VALVE COVER THREADED 6
11 204PZL715 07916780 GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
12 2007674 PZ789VGI BUSHING, VALVE GUIDE 6
13 200PZL147 PZ1011VC COVER, VALVE 6

15 200PZL587 PZ1011CAP CAP, VALVE COVER LOCK 6
16 2011701 PZ789PL PLATE, RETAINER 3
17 200PZL483 PZ1011LVG GUIDE, VALVE SUCTION 3
18 95W2 PZLVGAWASHER WASHER, LOCK 1/2" 316SS 6
19 655EE065 PZLVGABOLT SCREW 1/2" x 1 3/4" 316SS HX HD C/S 6
20 25AL35 07916747 GASKET, DISCHARGE MANIFOLD 3
21 25G41 07923283 GASKET, SUCTION MANIFOLD 3
22 200PZL455 PZ1011LC CLAMP, LINER 3
23 200PZL483A PZ1011LVGA ASSY., LOWER VALVE GUIDE ( INCLUDES ITEMS 12, 16-19.) 3



MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS



      National Oil well Varco (NOV) is an American multinational corporation based in Greater Sharps town, Houston, Texas. It is a leading worldwide provider of equipment and components used in oil and gas drilling and production operations, oilfield services, and supply chain integration services to the upstream oil and gas industry. The company conducts operations in more than 1,200 locations across six continents.


Products include all the heavy hardware for oil well drilling as well as drilling instrumentation and controls and drilling power generation and control. A partial list of heavy hardware includes top drives, rotary, draw works, derricks, BOPs (blowout preventers), mud pumps, riser equipment, and complete drilling rigs. Products also include instruments and controls required on the rig floor for the drilling operation. This includes sophisticated electronics for precise control, such as the control system Cyber base. NOV also produces control electronics for power generation and control of drilling motors and motor control centers for AC motor control.


NOV is the Houston area’s largest energy employer, with more than 14,500 workers in the region

MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS

MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160
FLUID END MODULE & ACCESSORIES
ITEM # OEM PART # MISSION PART #
    FEM12PASSYSWNS FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS: 1-23)
1 8476-6S FEM12PSUCSWNS MODULE, SUCTION STUDDED (INCLUDES ITEMS: 1,13,14,& 22)
2 8476-5D FEM12PDISSWNS MODULE, DISCHARGE STUDDED - (INCLUDES ITEMS: 2,3,4,5,6,7,8,13 & 14)
3 4018-17 12P160DSUCS STUD, DISCHARGE TO SUCTION MODULE
4   PEP55 NUT, DISCHARGE TO SUCTION STUD
5 4015-95 NAT12P160PFS STUD, POWER END
6   8P80TRSN NUT, POWER END STUD
7 8488-5 PEP70 PIN, DOWELL
8 4017-65 PEP75 CAPSCREW,LINER RETAINER SOCKET HEAD
9 8476-3 PP6021260SW PLATE, LINER WEAR
10 2988 1290344 GASKET, WEAR PLATE AND MODULE - RUBBER (SEE DATASHEET FOR ALT MATLS)
11 6476 12PLASW FLANGE, LINER RETAINER (LINER BUSHING)
12 6576 12PLANSW NUT, LINER RETAINER
13 4015-54 12PTRSSW STUD, THREADED RING
14   12P160TRSN NUT, THREADED RING STUD
15 4676-6A 12PVCASSYSWNS PLUG, VALVE COVER (INCLUDES ITEMS 15,19,20,& 21)
16 4476 12PFLGSW RING, THREADED (THREADED FLANGE)
17 4597 12PCAPSW CAP, THREADED (SCREW GLAND)
18 P-119 07207119 SEAL, VALVE COVER PLUG - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS)
19 4776R 12PVGASWNS ASSEMBLY, VALVE GUIDE(INCLUDES ITEMS 19,& 20)
20 4700-I PZ789VGI BUSHING, VALVE GUIDE
21 4016-98 PEP73 SCREW, VALVE GUIDE
22 4018-19 700048511 CAPSCREW, SUCTION MANIFOLD
23 AJO-419R 1540851 GASKET, SUCTION MANIFOLD
24 8376-2 NAT12PDSMA ADAPTER, DISCHARGE
25 2976-2 2410031437 SEAL, DISCHARGE ADAPTER
26 8376-1 NAT12PDSMC CONNECTOR, DISCHARGE
27 2976-1 2410031433 SEAL, DISCHARGE CONNECTOR TO DISCHARGE ADAPTER
28 4018-18 700030711 CAPSCREW, DISCHARGE CONNECTOR (W /LOCKWASHER)
29 8376-3 1292175 RING, BACKUP (DISCHARGE CONNECTOR)
30 4018-39 7006685 CAPSCREW, SOCKET HEAD 1 1/2" X 3"
    07924542 KIT, MODULE SEAL: (KIT INCLUDES SUCTION MANIFOLD GASKET, TWO VALVE COVER GASKETS, SUCTION TO DISCHARGE MODULE GASKET, TWO DISCHARGE ADAPTING GASKETS, TWO DISCHARGE CONNECTING GASKETS, WEAR PLATE GASKET)







MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS



SOUTHWEST 8490-2A FLUID END FOR

EMSCO FB1300/1600

FLUID END TYPE MODEL OF PUMP SIZE OF PUMP
SOUTHWEST 5000 PSI FB1300/1600 7-1/2” X 12”



ITEM P/ N DESCRIPTION QTY. REQ’D
  8490-2A FLUID END ASSEMBLY: (CONSISTS OF ITEMS: 3,4,17,18,19,20,21,22,23,24,25,26,27,28,29,30,31,33, 34,35,36,38,39) 3
1 6390YXX LINER (REFER TO GUIDE TO ORDERING CHART FOR TYPE (Y) AND FOR SIZE (XX) 3
2 AJO428S LINER SEAL (REFER TO GUIDE TO ORDERING CHART FOR TYPE AND SIZE (XX) (AJO428SU Also available in urethane) 3
3 8490-3 WEARPLATE 3
4 2988 WEARPLATE AND MODULE SEAL (2988U Also available in urethane) 6
5 XX-BYY PISTON (REFER TO GUIDE TO ORDERING CHART FOR SIZE (XX) AND FOR TYPE (YY) 3
5A 2932 PISTON BUSHING (FROM 1-5/8” TO 1-1/2” STRAIGHT BORE) 3
6 568-225 PISTON O-RING 3
7 6278-25 PISTON ROD (WITH ELASTIC STOP NUT) 3
8 API-4ESN PISTON ROD NUT 3
9 1290-2 PISTON ROD CONNECTING STUD 3
10 6284-1 SUB ROD 3
11 6274CWY ROD CLAMP (CONSIST OF 11A, 11B, 11C) (FOR CLAMP ONLY, USE 6274C) 3
11A 1200H30 HOSE (1/2” X 30” WITH 1/2” MALE X 3/8” MALE CONNECTIONS) 3
11B 1286-CWYFP14 PIPE (1/2” X 14” GALVANIZED AND THREADED ON ONE END) 3
11C 4020-29 BOLT (5/8” X 8” GRADE 8 BOLT WITH LOCK NUT AND WASHER) 6
12 1200G74 PONY ROD 3
13   VALVE 6
14   VALVE INSERT (IF REQUIRED) 6
15   VALVE SPRING 6
16   SEAT 6
  SWTM1700 HYDRAULIC SEAT PULLER KIT COMPLETE (REFER TO TOOLS SECTION OF CATALOG FOR DETAILS.)
  4475-2A SOUTHWEST HP QUICK-CHANGE VALVE COVER ASSEMBLY: (CONSIST OF ITEMS NO. 17-24) 6
17 4475 THREADED FLANGE 6
18 4575 SCREW GLAND 6
19 4675-2A PLUG (COMPLETE WITH VALVE GUIDE; SCREWS; AND BUSHING) 6
20 P129 HP VALVE COVER PLUG SEAL (P129U Also available in urethane) 6
21 4775-2R VALVE GUIDE (complete with bushing #4700I) 6
22 4700I VALVE GUIDE BUSHING 6
23 4016-99 VALVE GUIDE SCREW 12
24 4015-2 VALVE COVER STUD (WITH SW PART# HHNHHN1250-7 1-1/4:-7” HEAVY HEX NUT) 72
25 4016-9 POWER END STUD (WITH SW PART# HHN1500-8 1-1/2-”8 HEAVY HEX NUT) 18
27 6490-3 LINER RETAINER FLANGE 3
28 8422-3 LINER RETAINER PILOT RING 3
29 6590-1 LINER RETAINER NUT 3
30 4016-97 SUCTION MODULE STUD (WITH SW PART# HHN1500-8 1-1/2”-8 HEAVY HEX NUT) 18
31 4018-19 SUCTION MANIFOLD CAP SCREW (WITH LOCK WASHER) 18
32 8590-6 SUCTION MANIFOLD (FRONT OR SIDE INLET) 1
33 568-442 SUCTION MANIFOLD SEAL 3
34 8490-2S SUCTION MODULE (STUDDED ONLY) 3
35 8490-1D DISCHARGE MODULE (STUDDED ONLY) 3
36 8488-5 DOWEL PIN 6
37 8390-50 DISCHARGE MANIFOLD 1
38 568-343 DISCHARGE MANIFOLD SEAL 3
39 4017-46 DISCHARGE MANIFOLD STUD (WITH SW PART# HHN1250-8 1-1/4”-8 HEAVY HEX NUT) 12
40 ESN500 ELASTIC STOP NUT 12
41 LW875 LOCKWASHER 7/8 36
42 9070004 SINGLE LIP PONY ROD SEAL 3
43 9070005 DOUBLE LIP PONY ROD SEAL 3
44 9060012 SPLASH GUARD
  8590-6BFA

BLIND FLANGE IS AVAILABLE FOR CAPPING UNUSED FLANGES ON 8590-6 SUCTION MANIFOLD –

(8590-6BFA INCLUDES 8590-6BF BLIND FLANGE AND 568-456 O-RING) SEE SEPARATE PG. FOR DETAILS


  6278-74 PISTON ROD PULLER FOR 6278-25 ROD & 1200G74 PONY
    THE FOLLOWING PARTS ARE USED WITH THE SOUTHWEST FB-1600 / FB-1300 HYDRAULIC LINER RETAINER
45 1388XX LINER 3
46 2974XX LINER SEAL 3
47 8490-20 LINER WEARPLATE / USE 2988 WEARPLATE GASKET SAME AS ORIGINAL 3
48 8488-7 SET SCREW 12
49 6588-22-2 LINER NUT 3







MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS



SOUTHWEST 8494-25A FLUID END FOR

EMSCO FC-2200

FLUID END TYPE MODEL OF PUMP SIZE OF PUMP
SOUTHWEST 7500 PSI FC-2200 9” X 15”



ITEM P/ N DESCRIPTION QTY. REQ’D
  8494-25A FLUID END ASSEMBLY: (CONSISTS OF ITEMS:2,3,4,5,18,19,20,21,22,23,24,25,26,27,28,29,30,31,33,34,35,36,37,38,40)
1 6394GXX LINER (REFER TO GUIDE FOR ORDERING CHART FOR TYPE (G); (Y); AND FOR BORE SIZE (XX) 3
2 AJO524S LINER & WEARPLATE SEAL (ALSO AVAILABLE IN URETHANE) 6
3 8494-54-1 LINER WEARPLATE BASE 3
4 8494-54-2 LINER WEARPLATE 3
5 4020-36 LINER WEARPLATE CAPSCREW 18
6 XX-BYY PISTON (REFER TO GUIDE FOR ORDERING CHART FOR SIZE (XX) AND FOR TYPE (YY) 3
7 568-225 PISTON SEAL 3
8 6293-33 PISTON ROD (WITH ELASTIC STOP NUT) 3
9 API-4ESN PISTON ROD NUT 3
10 6293-3 SUB ROD 3
11 6293-4 PISTON ROD CONNECTING STUD 3
12 6293CW ROD CLAMP 3
12A 1200H30 HOSE 3
12B 1200160 PIPE 3
12C 4019-92 ROD CLAMP CAPSCREW WITH HI-COLLAR LOCK WASHERS 6
13 6200G93 PONY ROD 3
14 SEE PAGE VALVE COMPLETE 6
15 SEE PAGE VALVE INSERT 6
16 SEE PAGE VALVE SPRING 6
17 SEE PAGE VALVE SEAT 6
  SWTM1700 HYDRAULIC SEAT PULLER KIT COMPLETE (REFER TO TOOLS SECTION IN CATALOG) 1
18 4476 VALVE COVER FLANGE 6
19 4597 SCREW GLAND 6
20 4609-25A PLUG (COMPLETE WITH VALVE GUIDE; BUSHING; AND SCREWS) INCLUDES ITEMS 21, 22, 23, & 24 6
21 P119 HP VALVE COVER PLUG NITRILE SEAL 6
22 4776R VALVE GUIDE (COMPLETE WITH BUSHING #4700I) 6
23 4700I VALVE GUIDE BUSHING 6
24 4016-98 VALVE GUIDE SCREW 12
25 4015-54 VALVE COVER STUD (WITH SW PART# HHN1500-6 1 ½-6 HEAVY HEX NUT) 72
26 4020-42 POWER END STUD (WITH SW PART# HHN1750-8 1 ¾-8 HEAVY HEX NUT) 24
27 6494-25 LINER RETAINER FLANGE 3
28 4020-43 LINER RETAINER STUD (WITH SW PART# HHN1125-8 1 1/8-8 HEAVY HEX NUT) 48
29 6594-25 LINER RETAINER NUT 3
30 4020-6 SUCTION MODULE STUD (WITH SW PART# HHN2000-8 2-8 HEAVY HEX NUT) 18
31 4020-27 SUCTION MANIFOLD CAPSCREW 18
32   SUCTION MANIFOLD 1
33 568-442 SUCTION MANIFOLD O-RING 3
34 8494-26S SUCTION MODULE 3
35 8494-27D DISCHARGE MODULE 3
36 8488-5 DOWEL PIN 6
37 2988 MODULE SEAL 3
38 4020-44 DISCHARGE MANIFOLD STUD (WITH SW PART# HHN1500-8 1 ½-8 HEAVY HEX NUT) 12
39   DISCHARGE MANIFOLD 1
40 568-349 DISCHARGE MANIFOLD O-RING 3












MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERSMISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS



NATIONAL 10-P-130
FLUID END MODULE & ACCESSORIES
ITEM # TSC PART # DESCRIPTION
01 TS-1290335 MODULE, STUDDED FLUID END DISCHARGE ( INCLUDES ITEMS 1,3-6, 9-11, 30,&31)
02 TS-1290338 MODULE, STUDDED FLUID END SUCTION (INCLUDES ITEMS 2,3,4 )
03 TS-2408019 STUD, THREADED RING
04 TS-6300220 NUT, THREADED RING STUD
05 TS-2408020 STUD, POWER FRAME
06 TS-6300240 NUT, POWER FRAME STUD
07 TS-2402560 STUD,TOP TAPER LOCK (FOR BLIND RING AND WELD NECK FLANGES)
08 TS-6300220 NUT, STUD (BLIND RING AND WELD NECK FLANGES)
09 TS-2408034 STUD, DISCHARGE MODULE TO SUCTION MODULE
10 TS-6300241 NUT, DISCHARGE TO SUCTION MODULE STUD
11 TS-6511416 PIN, DOWELL
12 TS-1292141 BUSHING,VALVE GUIDE
13 TS-1292140 RETAINER, VALVE GUIDE BUSHING
14 TS-1540126 GASKET, VALVE COVER
15 TS-1290174 RETAINER, SEAL
16 TS-1290178 SCREW, ADJUSTING WEDGE
17 TS-G1290376 ASSEMBLY, WEDGE (INCLUDES ITEM #18 WEDGE SPRING)
18 TS-1290181 SPRING, WEDGE
19 TS-1290308 RING, THREADED
20 TS-1290307 CAP, VALVE COVER (THREADED)
21 TS-1290315 WASHER, WEDGE ADJUSTING SCREW
22 TS-6300160 NUT, WEDGE ADJUSTING SCREW
23 TS-1290343 ADAPTER, DISCHARGE CONNECTOR
24 TS-2410031427 SEAL,DISCHARGE CONNECTOR TO DISCHARGE ADAPTER
25 TS-1290342 CONNECTOR, DISCHARGE
26 TS-2410031348 SEAL,SUCTION CONNECTOR TO DISCHARGE ADAPTER
27 TS-700030511 CAPSCREW, DISCHARGE CONNECTOR (WASHER INCLUDED)
28 TS-1290357 PLATE, WEAR
29 TS-1290165 BUSHING, LINER
30 TS-2408018 STUD, LINER BUSHING
31 TS-6300160 NUT, LINER BUSHING STUD
32 TS-1290166 ASSEMBLY, LINER CLAMP (INCLUDES ITEMS 32,33,34,35,36,37)
33 TS-700044811 CAPSCREW, LINER CLAMP
34 TS-6309120 NUT, LINER CAPSCREW
35 TS-1290169 PIN, CONNECTOR
36 TS-1290168 CONNECTOR, LINER CLAMP
37 TS-6571420 PIN, SPRING
38 TS-1290344 SEAL, MODULE & WEARPLATE
39 TS-1590051 SEAL, SUCTION MANIFOLD





MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS





MISSION "L" MODULE FOR A-1400-PT-A-1700PT
FLUID END MODULE & ACCESSORIES
ITEM OEM PART MISSION PART DESCRIPTION QTY
# # # Return To: Oilwell Index
  8488-1A FEMA17ASSYSW FLUID END MODULE COMPLETE ASSY. (INCLUDES ITEMS 1-27)
1 8488-1D FEMA17DISSW DISCHARGE MODULE - (INCLUDES ITEMS 1, 4-11, 12, 13) 3
2 8488-2S FEMA17SUCSW SUCTION MODULE, (INCLUDES ITEMS 2, 11, 12, 13, 27) 3
3 6488-1 OWA17LRPLATESW LINER RETAINER PLATE 3
4 4017-4 PEP68 ALLEN HEAD CAPSCREW 1 1/4"-7X 3 1/2" 24
5 4016-3 OWA17DMSSW DISCHARGE MANIFOLD STUD 12
6   EMSF1000TRSN NUT, DISCHARGE MANIFOLD STUD 12
7 4016-96 OWA17PFSSW STUD, POWER FRAME 12
8   PEP55 NUT, POWER FRAME STUD 12
9 4016-97 OWA17DSUCSSW STUD, DISCHARGE TO SUCTION MODULE 6
10   EMSF1000PFSN NUT, FOR ABOVE STUD 6
11 4015-2 OWA17TRSSW STUD, THREADED RING 24
12   PZ789LCSN NUT, THREADED RING STUD 24
13 8488-5 PEP70 DOWELL PIN 6
14 2988 1290344 SEAL, DISCHARGE TO SUCTION MODULE 3
15 2974-1 077170074203 SEAL, WEAR PLATE 3
16 8488-4 PP602850 WEAR PLATE 3
17 6588-1 OWA17LLNSW LINER LOCK NUT 3
18 P-129 07207129 VALVE COVER SEAL 6
19 4018-88 PEP73 RETAINER SCREW, VALVE COVER 12
20 4775R OWA17VGSW VALVE GUIDE 6
21 4675-1A OWA17VCASSYSW VALVE COVER PLUG - (INCLUDES ITEMS 19-22) 6
22 4700-I PZ789VGI VALVE GUIDE BUSHING 6
23 4475 OWA17FLGSW THREADED FLANGE 6
24 4575 OWA17CAPSW THREADED CAP 6
25 80102003 10300201 SUCTION MANIFOLD GASKET 3
26 568-345 99609345 DISCHARGE MANIFOLD GASKET 3
27 4018-70 75634382 SUCTION MANIFOLD CAPSCREW 24
28 8488-7 PEP90 LINER RETAINER SETSCREW 9





MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160, NATIONAL 12P-160 7500 PSI MUD PUMP FLUID END MODULE LINERS







All our fluid end parts are manufactured to API 7K quality standards.

Parts are available for these popular pump models:

BOMCO/Emsco Mud Pumps:F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,

LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600
Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,
National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,
Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,

Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT



Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200

Russian Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32



WEATHERFORD/Ellis Williams: E-447, E-2200



Drillmec: 9T1000, 12T1600, 7TS600, 7TS500, 9T800



Romania: 3PN-1000, 3PN-1600, 3PN-2000



And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.



Contact Details
Qingdao National Premium Oilwell Machinery Co.,Ltd

Contact Person: Mr. Eric

Tel: 0086-15376875239

Send your inquiry directly to us (0 / 3000)

About Us
Weatherford Mud Pumps
National Mud Pumps
Mud Pump Chrome Liner
Contact Us
Mobile Site
Privacy Policy | China OILWELL Mud Pumps Supplier. Copyright © 2019 - 2024 premiummudpump.com. All Rights Reserved. Developed by ECER
