Lugar de origen Porcelana
Nombre de la marca EWECO
Certificación API
Número de modelo EWS440, EWS446
Cantidad de orden mínima 1 juego
Precio 40000 USD
Detalles de empaquetado Adecuado para envío
Tiempo de entrega En stock
Condiciones de pago T/T, LC/C
Capacidad de la fuente 50 conjuntos por mes

Éntreme en contacto con gratis las muestras y los vales.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

Si usted tiene alguna preocupación, proporcionamos ayuda en línea de 24 horas.

x
Datos del producto
Uso Petróleo, plataforma de perforación Fuerza Eléctrico, diesel
Presión Bomba de lodo sumergible de alta presión y baja presión, bomba de lodo de dragado de arena Aplicación minería, petróleo
Estructura Bomba de pistón combustible Opción diésel, motor diésel y motor hidráulico
Estándar o no estándar Estándar Teoría Bomba centrífuga, bomba alternativa, bomba de diafragma
Tipo Bomba de barro Peso 100-3700kg
Color Verde o por diseño del cliente Material Arrabio/bomba de succión de acero inoxidable del fango, aleación de Chrome
Garantía 12 meses Característica bomba de succión de barro
Nombre del producto Bomba de barro Cabeza Bomba de aspiración de barro de 10 m
OEM puede ser aceptar, aplicable
Deja un mensaje
Descripción de producto
EWS-446 Triplex Mud Pumps (API-7K)
Specifications
Rated Horsepower: 440 HP
Rated Pump Speed: 320 SPM
Stroke Length: 6"
Suction Inlet: 150 flange 6"
Discharge Outlet: 900 flange 3"
Gear Ratio: 4.578:1
Valve Pot: API #4
Dimensions 98" x 48" x 44"
Approximate Weight: 9,840 lbs



 EWECO EWS440 MUD PUMP, EWS446 MUD PUMP, MUD PUMP FOR OILWELL DRILLING, F1600 MUD PUMP, 12P160 MUD PUMP, MP5 MUD PUMP 0




EWS-446 Performance
Liner Size, inches 6 5-1/2 5 4-1/2 4 3-1/2
Rated Pressure, psi 1,027 1,222 1,479 1,710 2,169 2,816
Pump Speed
SPM		 Input Power
HP		 Displacement, GPM
320 440 661 555 459 397 313 240
270 380 551 463 382 335 264 202
220 320 441 370 306 273 215 165
170 260 330 278 229 211 167 127
120 200 220 185 153 149 118 90
70 200 110 93 76 87 69 52
Volume/Stroke, gallons 2.203 1.851 1.530 1.239 0.979 0.750



Ratings are based on 90% mechanical efficiency and 100% volumetric efficiency.

EWECO EWS440 MUD PUMP, EWS446 MUD PUMP, MUD PUMP FOR OILWELL DRILLING, F1600 MUD PUMP, 12P160 MUD PUMP, MP5 MUD PUMP 1


Item Part number Description Qty Item Part number Description Qty
1 B-440343-Re Valve Cover 2 17 B-440321-Re Valve Guide, Suction 1
2 B-440323-Re Plug, Valve Cover 1 18 GB/T 3452.1-Re O- Ring φ150x5.3 1
3 W-446.01.010-Re Seal, Valve Cover 1 19 W0101 Stud 3/4-10UNCX1 11/16 4
4 W-446.01.004-Re Spring, Valve 2 20 W-446.01.008-Re Seal, Liner 1
5 W-446.01.03.00-Re Valve Assy(API #4) 2 21 W-446307-Re Liner 1
6 W-446.01.002-Re Seat, Valve 2 22 B-440322-Re Liner Clamp 1
7 GB/T 3452.1-Re O- Ringφ100x3.55 2 23 W-446.01.007-Re Self-Lock Nut 1
8 D-440342-Re Valve Cover Flange 2 24   Piston 1
9 D-440003-Re Fluid End Module 1 25 GB/T 3452.1 O- Ring φ25x3.55 1
10 W-446.01.013-Re Stud 3/4-10UNCX6 2 26 B-440308-Re Piston Rod 1
11 NF2-3/4 Nut 3/4-10UNC-2B 2 27 W0105 Nut 9/16-12UNC 2
12 GB/T 3452.1 O-Ring φ47.5x5.3 1 28 GB/T93 Washer 14 2
13 W-446.01.011-Re Stud 7/8-9UNCX4 1/2 12 29 B-440227.01 Washer Ring 1
14 NF2-7/8 Nut 7/8-9UNC 12 30 W0104 Stud 9/16-12UNCX4 2
15 B-440309-Re Plug, Cylinder Cover 1 31 W-446.01.006 Nut 1 1/8-8UN 4
16 W-446.01.001-Re Seal, Cylinder Cover 1 32 W-446.01.005 Stud 1 1/8-8UNX7 1/4 4



W-440/446 data SPM 320 270 220 170 120 70
Rated input power(Hp) 440 380 320 260 200 200
Liner(in) Pressurepsi)   Displacement, GPM
4-1/2 1710 1.239 397 335 273 211 149 87
4-1/4 1917 10105 354 299 243 188 133 77
4 2169 0.979 313 264 215 167 118 69
3-3/4 2468 0.861 275 232 189 146 103 60
3-1/2 2816 0.750 240 202 165 127 90 52
3 3327 0.551 204 149 121 94 66 39
Ratings are based on 90% mechanical efficiency and 100% volumetric efficiency.



W-446 Data SPM 260 220 180 140 100 60
Rated input power(Hp) 500 423 346 269 192 115
Liner(in) PRESSURE(MPa) L/S Displacement(L/S)
6 9.17 8.33 36.10 30.54 24.99 19.44 13.88 8.33
5 1/2 10.92 7.00 30.33 25.67 21.00 16.33 11.67 7.00
5 13.20 5.79 25.09 21.23 17.37 13.51 9.65 5.79
4 1/2 16.30 4.69 20.32 17.20 14.07 10.94 7.82 4.69
4 20.60 3.71 16.08 13.60 11.13 8.66 6.18 3.71
3 1/2 21.00 2.84 12.31 10.41 8.52 6.63 4.73 2.84
Ratings are based on 90% mechanical efficiency and 100% volumetric efficiency.
