EWCO W-446 mud pump fluid end module, liners, pistons, valevs, W-440 mud pump fluid end liner, E-1600 mud pump liner
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Usage: | Oil,Water,drill Rig | Power: | Electric,Hydraulic |
|---|---|---|---|
| Pressure: | High Pressure,Low Pressure,low Pressure Submersible Mud Pump Sand Dredging Slurry Pump | Application: | Mining,oil |
| Structure: | Piston Pump | Fuel: | Diesel,Electric |
| Standard Or Nonstandard: | Standard | Theory: | Diaphragm Pump |
| Type: | Mud Pump | Weight: | 100-3700kg |
| Color: | Blue,red And So On,Green Or Per Customer Design | Material: | Cast Iron/stainless Steel Mud Suction Pump,Chrome Alloy,Stainless Steel Aluminum Plastic Etc |
| Warranty: | 12 Months | Product Name: | Mud Pump |
| Head: | 10m Mud Suction Pump | Oem: | Can Be Accept,Applicable |
| Condition: | New |
Premium can produce the spare parts of ELLIS WILLIAMS (EWCO & LEWCO) W-440 MUD PUMP , W-446 MUD PUMP, WH-1312 MUD PUMP, WH-1612 MUD PUMP, WH-2214 MUD PUMP, WH-2215 MUD PUMP, W-1100 MUD PUMP.
| Item | Part number | Description | Qty | Item | Part number | Description | Qty |
| 1 | B-440343-Re | Valve Cover | 2 | 17 | B-440321-Re | Valve Guide, Suction | 1 |
| 2 | B-440323-Re | Plug, Valve Cover | 1 | 18 | GB/T 3452.1-Re | O- Ring φ150x5.3 | 1 |
| 3 | W-446.01.010-Re | Seal, Valve Cover | 1 | 19 | W0101 | Stud 3/4-10UNCX1 11/16 | 4 |
| 4 | W-446.01.004-Re | Spring, Valve | 2 | 20 | W-446.01.008-Re | Seal, Liner | 1 |
| 5 | W-446.01.03.00-Re | Valve Assy(API #4) | 2 | 21 | W-446307-Re | Liner | 1 |
| 6 | W-446.01.002-Re | Seat, Valve | 2 | 22 | B-440322-Re | Liner Clamp | 1 |
| 7 | GB/T 3452.1-Re | O- Ringφ100x3.55 | 2 | 23 | W-446.01.007-Re | Self-Lock Nut | 1 |
| 8 | D-440342-Re | Valve Cover Flange | 2 | 24 | Piston | 1 | |
| 9 | D-440003-Re | Fluid End Module | 1 | 25 | GB/T 3452.1 | O- Ring φ25x3.55 | 1 |
| 10 | W-446.01.013-Re | Stud 3/4-10UNCX6 | 2 | 26 | B-440308-Re | Piston Rod | 1 |
| 11 | NF2-3/4 | Nut 3/4-10UNC-2B | 2 | 27 | W0105 | Nut 9/16-12UNC | 2 |
| 12 | GB/T 3452.1 | O-Ring φ47.5x5.3 | 1 | 28 | GB/T93 | Washer 14 | 2 |
| 13 | W-446.01.011-Re | Stud 7/8-9UNCX4 1/2 | 12 | 29 | B-440227.01 | Washer Ring | 1 |
| 14 | NF2-7/8 | Nut 7/8-9UNC | 12 | 30 | W0104 | Stud 9/16-12UNCX4 | 2 |
| 15 | B-440309-Re | Plug, Cylinder Cover | 1 | 31 | W-446.01.006 | Nut 1 1/8-8UN | 4 |
| 16 | W-446.01.001-Re | Seal, Cylinder Cover | 1 | 32 | W-446.01.005 | Stud 1 1/8-8UNX7 1/4 | 4 |
| EWCO | W-446 | 6 x 6 | ||||||||
| LINERS | LINER GASKETS | PISTONS | PISTON REPLACEMENT RUBBERS | |||||||
| SIZE | CERAMIC | SUPREME | RUBBER | URETHANE | BLUE LIGHTNING | GREEN DUO | WHITE LIGHTNING | SUPREME | WHITE LIGHTNING | SUPREME |
| 4" | 7562400 | 5562400 | 7916537 | MB40-15 | 1502052 | 12180170 | 15180102 | |||
| 4 1/4" | ||||||||||
| 4 1/2" | 7562450 | 5562450 | 7916537 | MB44-15 | 1502054 | 12180197 | 12180196 | 15180145 | 15180144 | |
| 4 3/4" | ||||||||||
| 5" | 7562500 | 5562500 | 7916537 | MB50-15 | 1502056 | 12180254 | 12180253 | 15180186 | 15180185 | |
| 5 1/4" | ||||||||||
| 5 1/2" | 7562550 | 5562550 | 7916537 | MB54-15 | 1502058 | 12180338 | 12180337 | 15180228 | 15180227 | |
| 5 3/4" | ||||||||||
| 6" | 7562600 | 5562600 | 7916537 | MB60-15 | 1502060 | 12180395 | 12180394 | 15180269 | 15180268 | |
| 6 1/4" | ||||||||||
| 6 1/2" | ||||||||||
| 6 3/4" | ||||||||||
| 7" | ||||||||||
| 7 1/4" | ||||||||||
| 7 1/2" | ||||||||||
| 7 3/4" | ||||||||||
| 8" | ||||||||||
| For Bonded White Lightning Pistons add "XT" to Green Duo Part # | ||||||||||
| VALVES, SEATS, SPRINGS & INSERTS | GASKETS | |||||||||
| ROUGHNECK | ROUGHNECK HP | SUPREME | OEM | URETHANE | L STYLE | URETHANE | ||||
| VALVE-White Lightning Insert | N/A | Valve Cover | 7916826 | |||||||
| VALVE-Urethane Insert | 9700099 | 60152949 | Cylinder Head | 7916830 | ||||||
| VALVE-Rubber Insert | N/A | N/A | Plug Seal | |||||||
| SEAT | 80130248 | 61103008 | ||||||||
| SPRING | 55213417 | |||||||||
| SPRING-Stainless | 55403067 | |||||||||
| INSERT-Urethane | 9705058 | 62400114 | MODULES | OEM | MISSION L | |||||
| INSERT-Rubber | N/A | N/A | Complete Assembly | |||||||
| SEAT PULLER ASSEMBLIES | Discharge Module Studded | |||||||||
| Puller Assembly 1 | M 1100 | M 1100 | Suction Module Studded | |||||||
| Puller Head | 181235003 | 181240110 | One Piece OEM Style Studded | |||||||
| Crosshead Extension Rods, Quick Connect Rods, Self Aligning Rod Assemblies & Piston Rods | ||||||||||
| Crosshead Rod | Quick Connect | Self Aligning Rod Assembly | Pony Rod Baffle | Piston Rod | Sub Rod | Stud | Rod Nut | Clamp | Covered Rod Nut | Pony Rod Seal |
| 2404339 | 5402052 | CRN-1 | ||||||||
Weatherford is one of the world's largest multinational oil and natural gas service companies. The company provides products and services for drilling, evaluation, completion, production and intervention of oil and natural gas wells, along with pipeline construction and commissioning. Headquartered in Switzerland, Weatherford operates in more than 100 countries across the globe and employs more than 35,000 people (2016).
Weatherford offers a full line of premium-quality mud pumps based on proven and
simple-to-maintain designs that are accepted around the world. Each pump comes with
exceptional service and support that only a true global provider like Weatherford can
promise. When you factor in our competitive pricing and off-the-shelf availability of pumps
and parts, it’s clear that Weatherford has raised the bar for mud pumps.
All our fluid end parts are manufactured to API 7K quality standards.
Parts are available for these popular pump models:
BOMCO/Emsco Mud Pumps:F2200HL, F1600HL, F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,
LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600
Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,
National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,
Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,
Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT
Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200
Russian Mud Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32
WEATHERFORD/Ellis Williams: E-447, E-2200
Drillmec Mud Pump: 9T1000, 12T1600, 7TS600, 7TS500, 9T800
Romania Mud Pump: 3PN-1000, 3PN-1600, 3PN-2000
And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.
| Item | Part number | Description | Qty | Item | Part number | Description | Qty |
| 1 | B-440343 | Valve Cover | 2 | 17 | B-440321 | Valve Guide, Suction | 1 |
| 2 | B-440323 | Plug, Valve Cover | 1 | 18 | GB/T 3452.1 | O- Ring φ150x5.3 | 1 |
| 3 | W-440.01.010 | Seal, Valve Cover | 1 | 19 | W0101 | Stud 3/4-10UNCX1 11/16 | 4 |
| 4 | W-440.01.004 | Spring, Valve | 2 | 20 | W-440.01.008 | Seal, Liner | 1 |
| 5 | W-440.01.03.00 | Valve Assy(API #4) | 2 | 21 | W-440307-Re | Liner | 1 |
| 6 | W-440.01.002 | Seat, Valve | 2 | 22 | B-440322 | Liner Clamp | 1 |
| 7 | GB/T 3452.1 | O- Ringφ100x3.55 | 2 | 23 | W-440.01.007 | Self-Lock Nut | 1 |
| 8 | D-440342 | Valve Cover Flange | 2 | 24 | Piston | 1 | |
| 9 | D-440003 | Fluid End Module | 1 | 25 | GB/T 3452.1 | O- Ring φ25x3.55 | 1 |
| 10 | W-440.01.013 | Stud 3/4-10UNCX6 | 2 | 26 | B-440308 | Piston Rod | 1 |
| 11 | NF2-3/4 | Nut 3/4-10UNC-2B | 2 | 27 | W0105 | Nut 9/16-12UNC | 2 |
| 12 | GB/T 3452.1 | O-Ring φ47.5x5.3 | 1 | 28 | GB/T93 | Washer 14 | 2 |
| 13 | W-440.01.011 | Stud 7/8-9UNCX4 1/2 | 12 | 29 | B-440227.01 | Washer Ring | 1 |
| 14 | NF2-7/8 | Nut 7/8-9UNC | 12 | 30 | W0104 | Stud 9/16-12UNCX4 | 2 |
| 15 | B-440309 | Plug, Cylinder Cover | 1 | 31 | W-440.01.006 | Nut 1 1/8-8UN | 4 |
| 16 | W-440.01.001 | Seal, Cylinder Cover | 1 | 32 | W-440.01.005 | Stud 1 1/8-8UNX7 1/4 | 4 |
| ITEM | PART NUMBER | DESCRIPTION | QTY/PUMP |
| TS-6316-0325-00 | FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEM 2-24, 26- 29) | 3 | |
| 1 | TS-6316-0357-00 | FLUID END MODULE STUDDED (INCLUDES ITEM 2-9) | 3 |
| 2 | TS-6316-0356-00 | FLUID END MODULE ONLY (UNSTUDED) | 3 |
| 3 | TS-7507-2013-00 | STUD, MODULE TO LINER CLAMP | 36 |
| 4 | TS-7601-0610-18 | LINER CLAMP STUD NUT | 36 |
| 5 | TS-7507-2201-00 | POWER FRAME STUD | 18 |
| 6 | TS-7507-2210-00 | STUD, MODULE TO CYLINDER | 18 |
| 7 | TS-7601-0630-17 | NUT (FOR ABOVE) | 48 |
| 8 | TS-7507-2108-00 | STUD, MODULE TO DISC. MANIFOLD | 12 |
| 9 | TS-7601-0630-24 | NUT (FOR ABOVE) | 12 |
| 10 | TS-6316-0354-00 | GUIDE, LOWER VALVE (WITH BUSHING) | 3 |
| 11 | TS-6316-0096-00 | BUSHING, LOWER VALVE GUIDE | 3 |
| 12 | TS-6316-0360-00 | LOCKBOLT, LOWER VALVE GUIDE | 3 |
| 13 | TS-6316-0363-00 | ALIGNMENT RING | 3 |
| 14 | TS-6316-0369-00 | GASKET, HEAD SEAL (G-801) | 3 |
| 15 | TS-6316-0364-00 | PLUG, CYLINDER HEAD | 3 |
| 16 | TS-6316-0361-00 | RING, THREADED CYLINDER HEAD | 3 |
| 17 | TS-6316-0362-00 | CAP, THREADED CYLINDER HEAD | 3 |
| 18 | TS-6316-0092-00 | GASKET, VALVE COVER (G-741) | 3 |
| 19 | TS-7501-0051-00 | SCREW, RETAINER (UPPER) | 12 |
| 20 | TS-6397-0603-00 | PLATE, RETAINER (UPPER) | 3 |
| 21 | TS-6397-0575-00 | GUIDE, UPPER VALVE | 3 |
| 22 | TS-6316-0039-00 | COVER, VALVE POT | 3 |
| 23 | TS-6316-0373-00 | GASKET, WEAR PLATE (G-800) | 3 |
| 24 | TS-6316-0365-00 | PLATE, WEAR | 3 |
| 25 | TS-6316-0373-00 | GASKET, LINER (G-800) | 3 |
| 26 | TS-6316-0366-00 | RING, LINER THREADED | 3 |
| 27 | TS-6316-0367-00 | LINER LOCK | 3 |
| 28 | TS-7602-1600-25 | GASKET, DISCHARGE MANIFOLD | 3 |
| 29 | TS-7602-1600-61 | GASKET, SUCTION MANIFOLD | 3 |
| 30 | TMFB6-STUDSSET | FB-1300/1600 STUDS AND NUTS SET (INCLUDES 12 PCS TS-7507-2013-00, 12 PCS TS-7601-0610-18, 6 PCS TS-7507-2201-00, 6 PCS TS-7507-2210-00, 16 PCS TS-7601-0630-17, 4 PCS TS-7507-2108-00, 4 PCS TS-7601-0630-24) | 3 |
| 31 | TMFB6-SEALKIT | FB-1300/1600 MODULE SEAL KIT (INCLUDES ONE G-800, ONE G-741, ONE G-801, ONE TS-7602-1600-25, ONE TS-7602-1600-61) | 3 |
| MISSION "L" MODULE FOR GARDNER DENVER PZ-10/PZ-11 FLUID END MODULE & ACCESSORIES | ||||
| ITEM # | SW PART # | MISSION PART # | DESCRIPTION | QTY PER PUMP |
| FEMPZ1011ASSYSW | FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS: 1-26) | 3 | ||
| 1 | 8477-1D | FEMPZ1011DISSW | MODULE, DISCHARGE STUDDED (INCLUDES ITEMS 1, 3-13) | 3 |
| 2 | 8477-2S | FEMPZ1011SUCSW | MODULE, SUCTION STUDDED - (INCLUDES ITEMS 2, 5-6) | 3 |
| 3 | 4016-97 | OWA17DSUCSSW | STUD, DISCHARGE TO SUCTION MODULE | 18 |
| 4 | 0-7601-0630-17 | NUT, DISCHARGE TO SUCTION STUD | 18 | |
| 5 | Feb-15 | OWA17TRSSW | STUD, THREADED RING | 72 |
| 6 | 6300200 | NUT, THREADED RING STUD | 72 | |
| 7 | 4018-35 | PZ1011GPFSSW | STUD, POWER FRAME (SHORT) | 24 |
| 8 | 6300200 | NUT, POWER FRAME STUD AND LINER RETAINER STUD | 24 | |
| 9 | 4018-34 | PZ1011LCSSW | STUD, LINER RETAINER (LONG) | 24 |
| 10 | /4017-5 | PZ1011DMSSW | STUD, DISCHARGE MANIFOLD | 12 |
| 11 | PZ789TRSN | NUT, DISCHARGE MANIFOLD STUD | 12 | |
| 12 | /8488-5 | 6511416 | PIN, DOWELL | 6 |
| 13 | 2988 | 1290344 | SEAL, SUCTION TO DISCHARGE MODULE | 3 |
| 14 | /2930-08 | 7932009 | SEAL, WEAR PLATE - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 3 |
| 15 | Mar-77 | PZ1011WPSW | PLATE, WEAR | 3 |
| 16 | 6477 | PZ1011LC | FLANGE, LINER RETAINER | 3 |
| 17 | P-129 | 7207129 | SEAL, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 6 |
| 18 | 4018-88 | PEP73 | SCREW, VALVE GUIDE | 12 |
| 19 | 4775R | OWA17VGASW | GUIDE, VALVE (INCLUDES ITEMS 20, & 24) | 6 |
| 20 | 4675-1A | OWA17VCASSYSW | PLUG, VALVE COVER (INCLUDES ITEM 19, 20, 21, & 24) | 6 |
| 21 | 4475 | OWA17FLGSW | FLANGE, THREADED | 6 |
| 22 | 4575 | OWA17CAPSW | CAP, THREADED | 6 |
| 23 | 4700-I | PZ789VGI* | BUSHING, VALVE GUIDE | 6 |
| 24 | 4017-77 | 700044111 | CAPSCREW, SUCTION MANIFOLD | 24 |
| 25 | AJO-449R | 7916747 | GASKET, DISCHARGE MANIFOLD | 3 |
| 26 | 8014G520 | 7923283 | GASKET, SUCTION MANIFOLD | 3 |
| MISSION "L" MODULE FOR IDECO T-1300/T-1600 FLUID END MODULE & ACCESSORIES | ||||
| ITEM # | OEM PART # | MISSION PART # | DESCRIPTION | QTY PER PUMP |
| 8407-7A | FEMT1316ASSYSW | ASSY, FLUID END MODULE COMPLETE (INCLUDES ITEMS: 1 - 22) | 3 | |
| 1 | 8407-7D | FEMT1316DISSW | MODULE, DISCHARGE STUDDED (INCLUDES ITEMS 1, 3-11) | 3 |
| 2 | 8407-11S | FEMT1316SUCSW | MODULE, SUCTION STUDDED (INCLUDES ITEMS 2, 5, 6) | 3 |
| 3 | 4016-97 | OWA17DSUCSSW | STUD, DISCHARGE TO SUCTION MODULE | 18 |
| 4 | 0-7601-0630-17 | NUT, DISCHARGE TO SUCTION MODULE STUD AND POWER FRAME STUD | 18 | |
| 5 | /4015-2 | OWA17TRSSW | STUD, THREADED RING | 72 |
| 6 | 6300200 | NUT, THREADED RING STUD | 72 | |
| 7 | 4018-68 | 80711011 | STUD, POWER FRAME | 24 |
| 8 | 4017-50 | T1316DMSSW | STUD, DISCHARGE MANIFOLD | 12 |
| 9 | 0-7601-0630-24 | NUT, DISCHARGE MANIFOLD STUD | 12 | |
| 10 | /8488-5 | 6511416 | PIN, DOWELL | 6 |
| 11 | 2988 | 1290344 | SEAL, SUC TO DISCH MOD & WEAR PLATE - RUBBER (SEE DATASHEET FOR ALT MATLS) | 6 |
| 12 | /8407-10 | T1316WPSW | PLATE, LINER WEAR | 3 |
| 13 | 6407 | T1316LRFLGSW | FLANGE, LINER RETAINER | 3 |
| 14 | 6507 | T1316LLNSW | NUT, LINER LOCK | 3 |
| 15 | P-129 | 7207129 | GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 6 |
| 16 | 4016-99 | PEP73 | CAPSCREW, VALVE GUIDE | 12 |
| 17 | 4700-I | PZ789VGI* | BUSHING, VALVE GUIDE | 6 |
| 18 | 4775-2R | EMSF1000VGASW | GUIDE, VALVE (INCLUDES ITEM 18) | 6 |
| 19 | 4675-2A | EMSF1000VCASSYSW | PLUG, VALVE (INCLUDES ITEMS 17-19) | 6 |
| 20 | 4475 | OWA17FLGSW | RING, THREADED | 6 |
| 21 | 4575 | OWA17CAPSW | CAP, THREADED | 6 |
| 22 | 568-339 | 99609339 | GASKET, DISCHARGE MANIFOLD | 3 |
| 23 | 568-447 | 99609447 | GASKET, SUCTION MANIFOLD | 3 |
| 24 | 4017-59 | PEP84 | CAPSCREW, SUCTION MANIFOLD | 24 |
All our fluid end parts are manufactured to API 7K quality standards.
Parts are available for these popular pump models:
BOMCO/Emsco Mud Pumps:F2200HL, F1600HL, F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,
LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600
Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,
National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,
Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,
Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT
Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200
Russian Mud Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32
WEATHERFORD/Ellis Williams: E-447, E-2200
Drillmec Mud Pump: 9T1000, 12T1600, 7TS600, 7TS500, 9T800
Romania Mud Pump: 3PN-1000, 3PN-1600, 3PN-2000
And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.
1,Plunger Size 3.38” - 4.00” Valve Part No. P107185 Seat Part No. P107802
Insert Part No. P107186 Spring
2,Plunger Size 4.50” Valve Part No. P107181 Seat Part No. P107180
Insert Part No. P107182 Spring
3,Plunger Size 5.00” - 6.00” Valve Part No. P107188 Seat Part No. P107187
Insert Part No. P107189 Spring4P102382
SPM2000压裂泵的型号及规格
1,Plunger Size 3.75" Plunge Part No 3P103887
2,Plunger Size 4.00" Plunge Part No 3P100339
3,Plunger Size 4.50" Plunge Part No 3P100654
4,Plunger Size" 5.00" Plunge Part No 3P100233
5,Plunger Size" 5.50 Plunge Part No 3P107060
6,Plunger Size" 5.75" Plunge Part No 3P107061
7,Plunger Size 6.00 Plunge Part No 3P107062
SPM压裂泵的型号
TWS 250 Plunger Size 1.75"-3" 3.25"-4"
TWS 400 Plunger Size 2 .50"-3" 3 .50"-4 .50”
TWS 500LW-600 Plunger Size 2 .75" 3"-4 .75"
TWS 600S Plunger Size 2 .50"-3" 3.50"-4 .50"
TWS 900 Plunger Size 3.50"-4"
TWS 1250LW Plunger Size 4"
OPI880 Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0”
TWS1000LW,TWS1300
Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0” 6.5 “ 6.75”
TWS1600 Plunger Size 3.5” 3.75” 4.0” 4.50” 5.0” 5.5” 5.75 “6.0”
TWS1800 Plunger Size 3.5” 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0”
TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
5.50” 5.75” 6.0”
TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5
Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300
Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600
Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652
Gardner Denver ® Mud Pumps
PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL
Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225
Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T
Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550
Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500
Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600
National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400
National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A
National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160
Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT
Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT
Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B
OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL
Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036
Fluid End Modules
National® - Oilwell® - Continental Emsco® - Gardner Denver® - Ideco® - Skytop Brewster®
Pulsation Dampener
Hydril Type "K" Pulsation Dampener
Popular Mud Pump Spare Parts
Mud Pump Manufactures and Models include:
Brewster Mud Pumps
B-550 | B-750 | B-1000 | 1100T | B-1300
Continental Emsco Mud Pumps
FF-FXF | FG-FXG (A thrugh L) | FD-FXX | FC-FXX | FD-FXD | FC-FXD | FY-FXD
Continental Emsco Mud Pumps
GP-GXP | GR-GXP | GP-GXR | GR-GXR |PA-8 | PAH
Continental Emsco Mud Pumps
PJ8 | PZ-7 | PZ-8 | PZ-9 | PZ-10 | PZ-11 | PXL
Ellis Williams (Luko) Mud Pumps
WW-440 | 14W-400 | 15W-600 | 9W-1000
Gaso Mud Pump
1563 | 1740-55 | 1844-60 | 2010-50 | 2200-49 | 2651 | 2652
Gardner Denver Mud Pumps
FF-FXF;FG-FXG;A thru L FD-FXX FC-FXX FD-FXD FC-FXD FY-FXD GP-GXP GR-GXP GP-GXR GR-GXR PA-8 PJ8 PZ-7 PZ-8 PZ-9 PZ-10 PZ-11 PXL
Ideco Mud Pumps
MM-200 | MM-300 | MM-500 | MM-500F | MM-550
Ideco Mud Pumps
MM-550F | MM-700 | MM-700F | T-500
Ideco Mud Pumps
T-800 | T-1000 | T-1300 | T-1600
National Mud Pumps
C-150 | C-250 | C-350 | E-500 | E-700 | G-700 | G-1000
National Mud Pumps
K-280 | K-380 | K-500 | K-500A | K-700A
National Mud Pumps
7P-50 | 8P-80 | 9P-100 | 10P-130 | 12P-160
Oilwell Mud Pumps
6P-HD | 610-P | 212-P | 214-P | 218-P
Oilwell Mud Pumps
350-PT | 560-PT | A-560-PT | 850-PT | A-850-PT | 1100-PT
Oilwell Mud Pumps
A-1100-PT | 1400-PT | A-1400-PT | 1700-PT | A-1700-PT
OPI Mud Pumps
350-D | 700-HDL | 1000-HDL
Wheatley Mud Pumps
1036 | 6070 | 7024 | 7036
Wilson Mud Pumps
600 | 900
Contact Details
Qingdao National Premium Oilwell Machinery Co.,Ltd
Contact Person: Mr. Eric
Tel: 0086-15376875239
Other Products
-
Southwest T1300/1600 mud pump liner, SW 14P220 mud pump, SW10P130 mud pump, SW F1000 mud pump fluid end module, liner
-
White Star WS1300 1600 mud pump, Southwest, Gardner Denver, Oilwell, National, Ideco, Honghua, RG mud pump parts
-
WH-1312 mud pump fluid end module, Cameron CMP2200 Mud Pump Schlumberger, WH-1612 mud pump, W2214 mud pump
-
Weatherford Emsco F-800 / 1000 mud pump liner, Bomco mud pump, Emsco mud pump, National mud pump, Southwest mud pump
-
National JWS-400 Mud Pump Liners, National JWS340 mud pump, National 12P160 mud pump, National 14P220 mud pump
-
mud pumps for drilling rigs, Weatherford E2200 mud pump zirconia liner, Weatherford E447 mud pump , Bomco F1600 mud pump
