EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP

China EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier
EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP supplier

Large Image :  EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP

Product Details:

Place of Origin: CHINA
Brand Name: ELLIS WILLIAMS (EWCO & LEWCO)
Certification: API
Model Number: WH-1612 MUD PUMP, E-1600

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: 1 to 500 usd
Packaging Details: Suitable to shipment by air and sea
Delivery Time: In stock
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 3000 pieces per month
Contact Now
Detailed Product Description
Usage: Oil,Water,drill Rig Power: Electric,Hydraulic,diesel
Pressure: High Pressure,Low Pressure,low Pressure Submersible Mud Pump Sand Dredging Slurry Pump Application: Mining,oil
Structure: Piston Pump Fuel: Diesel,diesel Engine And Hydraulic Motor For Option
Standard Or Nonstandard: Standard Type: Mud Pump
Weight: 100-3700kg Color: Blue,red And So On,Green Or Per Customer Design
Material: Cast Iron/stainless Steel Mud Suction Pump,Chrome Alloy,Stainless Steel Aluminum Plastic Etc Warranty: 12 Months
Product Name: Mud Pump Oem: Can Be Accept,Applicable
Condition: New

EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP



Premium can produce the spare parts of ELLIS WILLIAMS (EWCO & LEWCO) W-440 MUD PUMP , W-446 MUD PUMP, WH-1312 MUD PUMP, WH-1612 MUD PUMP, WH-2214 MUD PUMP, WH-2215 MUD PUMP, W-1100 MUD PUMP.



EWCO     WH-1612       7-1/2 x 12
  LINERS LINER GASKETS PISTONS PISTON REPLACEMENT RUBBERS
SIZE CERAMIC SUPREME RUBBER URETHANE BLUE LIGHTNING GREEN DUO Slip Seal Bonded SUPREME   SUPREME
4"
4 1/4"
4 1/2"     1540120   MB44-15 1502054 1502054SS 12180196   15180144
4 3/4"     1504121
5" 7466500 05466500* 7923264   MB50-15 1502056 1502056SS 12180253   15180185
5 1/4"
5 1/2" 7466550 05466550* 7923263 7211005 MB54-15 1502058 1502058SS 12180337   15180227
5 3/4"
6" 7466600 05466600* 7923261 7211004 MB60-15 1502060 1502060SS 12180394   15180268
6 1/4"   05466625* 7923283     1502061 1502061SS 12180493   15180284
6 1/2" 7466650 05466650* 7923284 7211003 MB64-15 1502062 1502062SS 12180535   15180300
6 3/4"
7" 7466700 05466700* 7923285 7211002 MB70-15 1502064 1502064SS 12180618   15180342
7 1/4"
7 1/2"               12180683   15180367
7 3/4"
8"
* For HP style liner, add "HP" to end of part no.   For Bonded White Lightning Pistons add "XT" to Green Duo Part #
VALVES, SEATS, SPRINGS & INSERTS   GASKETS
  ROUGHNECK ROUGHNECK HP SUPREME     OEM URETHANE L STYLE URETHANE
VALVE-White Lightning Insert 9700368 9700356 60155042   Valve Cover 6307762
VALVE-Urethane Insert 9700250 9700354 60155041   Cylinder Head 6307710
VALVE-Rubber Insert 9700293 N/A 60155033   Plug Seal
SEAT 9702539 9702539 61102505   Blak-JAK OEM MISSION L
SPRING 8201684 8201684 55413421   LOK-CEL 80501100 80501100
SPRING-Stainless 55413372 55413372 55402952   Hydra-Cell 80502100 80502100
INSERT-Urethane 9705228 PFO7I 62400338   MODULES OEM MISSION L
INSERT-Rubber 9705244 N/A 62400239   Complete Assembly
SEAT PULLER ASSEMBLIES Discharge Module Studded
Puller Assembly 1 M 1060 M 1060 M 1060   Suction Module Studded
Puller Head 8401985 8401985 181235300   One Piece OEM Style Studded

Crosshead Extension Rods, Quick Connect Rods, Self Aligning Rod Assemblies & Piston Rods
Crosshead Rod Quick Connect Self Aligning Rod Assembly Pony Rod Baffle Piston Rod Sub Rod Stud Rod Nut Clamp Covered Rod Nut Pony Rod Seal
              5402052   CRN-1




EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP



Suitable for land and offshore drilling applications, the premium Ellis-Williams™ EQ-2200 pump offers the smoothest, quietest operation of any mud pump in the industry. The EQ-2200 quintuplex pump features a smaller footprint and higher maximum flow rates than traditional triplex pump designs in the same horsepower class.

With a five-piston system, the pump reduces mud-telemetry noise and pulsation by 25 to 70%, which gives you fast downhole communication for precise geosteering. The pump also improves flow rates by 40%, which reduces the number of pumps and total power draw at the wellsite.







All our fluid end parts are manufactured to API 7K quality standards.



Parts are available for these popular pump models:



BOMCO/Emsco Mud Pumps:F2200HL, F1600HL, F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,

LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600


Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,


National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,


Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,

Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT



Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200



Russian Mud Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32



WEATHERFORD/Ellis Williams: E-447, E-2200



Drillmec Mud Pump: 9T1000, 12T1600, 7TS600, 7TS500, 9T800



Romania Mud Pump: 3PN-1000, 3PN-1600, 3PN-2000



And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.



EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP



Item Part Number Description Qty. Unit
1 ES331 LINER WASH PUMP PACKING 18 Ea
2 EG199 API ring gasket (BX-169SS) 27 Ea
3 EG197 API ring gasket (BX-152SS) 3 Ea
4 EG163 suction manifold gasket 15 Ea
5 B105281 suction dampener/desurger 3 Ea
6 108-0609 stroke counter 12 Ea
7 108-1054 heat exchanger-liner wash 3 Ea
8 108-1055 heat exchanger-lube oil 3 Ea
9 108-0764 low presure switch 3 Ea
10 ES452 low presure switch 3 Ea
11 108-1324 low presure switch 3 Ea
12 108-1225 v-belt 6 Ea
13 EG195 mud pressure gauge 3 Ea
14 EG170 crank case cover gasket 888 inch
15 A162209 inspection cover gasket 3 Ea
16 A164103 main bearing cover gasket 6 Ea
17 C164404 cross head cover gasket 6 Ea
18 A164185 inspection cover gasket (large) 3 Ea
19 108-1095 breather cap 3 Ea
20 A164191 stroke counter bracket gasket 3 Ea
21 B164202 eccentric bearing 9 Ea
22 EB119 main (spherical roller) bearing 6 Ea
23 B164206 main bearing shim set 6 Ea
24 A167244 eccentric bearing shims 6 Ea
25 EB120 pinion (cylinderical roller) bearing 6 Ea
26 ES194 oil seal 6 Ea
27 A164505 pinion bearing carrier gasket 6 Ea
28 B164402 wrist pin bearing 6 Ea
29 C164323 piston rod clamp 18 Ea
30 B164407 baffle disc 9 Ea
31 A164453 crosshead shim set 9 Ea
32 B164425 diaphragm plate gasket 9 Ea
33 ES211 stuffing box seal 36 Ea
34 A164415 stuffing box gasket 9 Ea
35 E0175 o-ring ( 2/343) 9 Ea
36 E0301 o-ring ( 2/442) 9 Ea
37 A164705 valve cover seal 18 Ea
38 A167708 valve guide bushing 36 Ea
39 A167702 wear plate seal 18 Ea
40 816406 wear plate seal 9 Ea
41 EV116 valve spring 36 Ea
42 EV190 valve seat 36 Ea
43 EV178 valve 36 Ea
44 EL238 liner (5") 36 Ea
45 EL220 liner (5 1/2") 36 Ea
46 EL221 liner (6") 36 Ea
47 EL222 liner (6 1/2") 36 Ea
48 EL223 liner (7") 36 Ea
49 EL224 liner (7 1/2") 36 Ea
50 EL240 liner (8") 36 Ea
51 EP159 piston (5") 36 Ea
52 EP160 piston (5 1/2") 36 Ea
53 EP117 piston (6") 36 Ea
54 EP118 piston (6 1/2") 36 Ea
55 EP150 piston (7") 36 Ea
56 EP151 piston (7 1/2") 36 Ea
57 EP152 piston (8") 36 Ea
58 EP165 piston (5") 36 Ea
59 EP114 piston rubber(5 1/2") 36 Ea
60 EP115 piston rubber (6") 36 Ea
61 EP116 piston rubber (6 1/2") 36 Ea
62 EP147 piston rubber (7") 36 Ea
63 EP148 piston rubber(7 1/2") 36 Ea
64 EP149 piston rubber (8") 12 Ea
65 EG132 liner gasket (5") 36 Ea
66 EG138 liner gasket (5 1/2") 12 Ea
67 EG139 liner gasket(6") 36 Ea
68 EG140 liner gasket(6 1/2") 36 Ea
69 EG136 liner gasket(7") 36 Ea
70 EG142 liner gasket (7 1/2") 36 Ea
71 EG144 liner gasket (8") 12 Ea
72 EP194 lube oil pump 3 Ea
73 108-0054 relief valve, 15 psi 3 Ea
74 108-1088 relief valve, 65 psi 3 Ea
75 108-0135 check valve 3 Ea
76 108-1257 flow switch 6 Ea
77 EG105 pressure gauge, 0-60 psi 6 Ea
78 EG145 pressure gauge 6 Ea
79 EV215 charging valve 6 Ea
80 ES175 stud 2.25 8UN 8.50 B7 36 Ea
81 EM132 heavy hex nut 8UN A194-2H 36 Ea
82 002-1666 hex bolt 1.000 8NC 2.00 G8 3 Ea
83 002-1544 lock washer 1.000" 3 Ea
84 108-0620 stabilizer plate L-2010 3 Ea
85 108-0619 stabilizer L-20 3 Ea
86 EN137 havy hex nut 1.125 7NC A194-2H 24 Ea
87 EC181 bottom flange cap screw 24 Ea
88 108-0656 seal 429 BUNA 70 3 Ea
89 ES174 stud 1.125 7NC 6.5 B7 24 Ea
90 EO190 charging valve o-ring 6 Ea
91 108-0065 ring gasket BX-155S 3 Ea
92 B310066 charging valve hose assembly 3 Ea
93 108-0618 buna-N bladder ( standard) 6 Ea
94 108-1194 hydrogenated nitrile bladder
(high temperature mud)		 6 Ea
95 108-1195 Urthane bladder ( oil based mud) 6 Ea



EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP



MISSION "L" MODULE FOR LEWCO W2215 7500 PSI W/ SWOP FE FLUID END MODULE & ACCESSORIES
ITEM # OEM PART # MISSION PART # DESCRIPTION QTY PER PUMP
  8482-25LEWA   FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS 1-22)
1 8482-27 80732001 MODULE, SUCTION STUDDED (INCLUDES ITEMS 1, 7-8) 3
2 8482-26 80732000 MODULE, DISCHARGE STUDDED (INCLUDES ITEMS 2-9) 3
3 /4020-6 80732002 STUD, DISCHARGE TO SUCTION MODULE 18
4 2"-8 HH 7402422 NUT, DISCHARGE TO SUCTION STUD 18
5 4020-26 80732004 STUD, POWER END 30
6 1-1/2-6 HH 6300240 NUT, POWER END STUD 30
7 4015-54 12PTRSSW STUD, THREADED RING 72
8 1-1/2-6 HH 6300240 NUT, THREADED RING STUD 72
9 /8488-5 6511416 PIN, DOWELL 6
10 4015-52 80732005 STUD, LINER RETAINER FLANGE 18
11 1-1/4-7 HH   NUT, LINER RETAINER FLANGE STUD 3
12 May-82 80732007 PLATE, LINER WEAR 3
13 2988 1290344 GASKET, WEAR PLATE AND MODULE - RUBBER (SEE DATASHEET FOR ALT MATLS) 6
14 6482   FLANGE, LINER RETAINER (LINER BUSHING) 3
15 6582   NUT, LINER RETAINER 3
16 4609-25A   ASSY, VALVE COVER PLUG (INCLUDES ITEMS 15,16, 20-22) 6
17     PLUG, VALVE COVER 6
18 4476 12PFLGSW RING, THREADED (THREADED FLANGE) 6
19 4597 12PCAPSW CAP, THREADED (SCREW GLAND) 6
20 P-119 7207119 SEAL, VALVE COVER PLUG - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
21 4776R 12PVGASWNS ASSEMBLY, VALVE GUIDE (INCLUDES ITEMS 20 & 21) 6
22 4700I PZ789VGI* BUSHING, VALVE GUIDE 6
23 4016-98 50C125KFCYB SCREW, VALVE GUIDE 12
24     CAPSCREW, SUCTION MANIFOLD
25     GASKET, SUCTION MANIFOLD 3
26 4019-60   STUD, DISCHARGE MANIFOLD 18
27 1-1/4-7 HH   NUT, DISCHARGE MANIFOLD 18
28 8382-25   MANIFOLD, DISCHARGE 1
29 2988 1290344 SEAL, DISCHARGE MANIFOLD 3





EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP

SOUTHWEST “NEW STYLE” 8476-4A FLUID END

FOR NATIONAL 12-P-160



FLUID END TYPE MODEL OF PUMP SIZE OF PUMP
SOUTHWEST 5000 P.S.I. NATIONAL 12-P-160 7-1/2” X 12”





ITEM P/N DESCRIPTION QTY. REQ’D
  8476-4A FLUID END ASSEMBLY: (CONSISTS OF ITEMS 3,4,16,17,18,19, 20, 21,22,23,24,25,26,27,28,29,31,32,33,34,&47)
1 1376YXX LINER (REFER TO GUIDE TO ORDERING CHART FOR TYPE (Y) AND FOR SIZE (XX)) 3
2 2930-XX LINER SEAL (REFER TO GUIDE TO ORDERING CHART FOR TYPE AND SIZE (XX)) 3
3 8476-3 WEARPLATE 3
4 2988 WEARPLATE AND MODULE SEAL (2988U URETHANE AVAILABLE) 6
5 XX-BYY PISTON (REFER TO GUIDE TO ORDERING CHART FOR SIZE (XX) AND FOR TYPE (YY)) 3
6 568-225 PISTON O-RING 3
7 1286-32 PISTON ROD (WITH ELASTIC STOP NUT) 3
8 API-4ESN PISTON ROD ELASTIC STOP NUT 3
9 1286-1 SUB ROD 3
10 1286CWY ROD CLAMP (CONSIST OF 10A, 10B, 10C) (FOR CLAMP ONLY, USE 1286C) 6
10A 1200H30 HOSE (1/2” X 30” WITH 1/2” MALE X 3/8” MALE CONNECTIONS) 3
10B 1286CWYFP14 DUAL SPRAY PIPE 3
10C 4020-29 ROD CLAMP BOLT (7/8 X 5” GRADE 8 BOLT WITH LOCK NUT AND WASHER) 12
11 1200G86 PONY ROD 3
12 SEE PAGE VALVE 6
13 SEE PAGE VALVE INSERT (IF REQUIRED) 6
14 SEE PAGE VALVE SPRING 6
15 SEE PAGE VALVE SEAT 6
  SWTM1700 HYDRAULIC SEAT PULLER KIT COMPLETE (REFER TO TOOLS PAGE OF CATALOG FOR DETAILS)
  4476-6A SOUTHWEST HP QUICK-CHANGE VALVE COVER ASSEMBLY (CONSISTS OF ITEMS 16-23) 6
16 4476 THREADED FLANGE 6
17 4597 SCREW GLAND 6
18 4676-6A PLUG (COMPLETE WITH VALVE GUIDE, SCREWS, AND BUSHING) 6
19 P119 HP VALVE COVER PLUG SEAL 6
20 4776R VALVE GUIDE (COMPLETE WITH BUSHING #4700I) 6
21 4700I VALVE GUIDE BUSHING (4700I URETHANE AVAILABLE) 6
22 4016-98 VALVE GUIDE SCREW 12
23 4015-54 VALVE COVER STUD (WITH SW PART# HHN1500-6 1-1/2-6” HEAVY HEX NUT) 72
24 4015-95 POWER END STUD (WITH SW PART# HHN1375-6 1-3/8”6 HEAVY HEX NUT) 30
25 4017-65 LINER RETAINER FERRY HEAD CAP SCREW 18
26 6476 LINER RETAINER FLANGE 3
27 6576 LINER RETAINER NUT 3
28 4018-17 SUCTION MODULE STUD (WITH SW PART# HHN1750-6 1-3/4”-6 HEAVY HEX NUT) 18
29 4018-19 SUCTION MANIFOLD CAP SCREW (WITH LOCK WASHER) 24
30 8576-50 SUCTION MANIFOLD (FRONT OR SIDE INLET) 1
31 AJO419R SUCTION MANIFOLD GASKET 3
32 8476-6S SUCTION MODULE (STUDDED ONLY) 3
33 8476-5D DISCHARGE MODULE (STUDDED ONLY) 3
34 8488-5 DOWEL PIN 6
    ITEMS NUMBERS 35 THRU 46 ARE NOT SHOWN INTENTIONALLY
47 4018-18 DISCHARGE CONNECTOR CAP SCREW (WITH LOCK WASHER) 16
48 4018-39 DISCHARGE SPACER FLANGE SOCKET HEAD CAP SCREW 16
49 8376-1 DISCHARGE CONNECTOR 2
50 8376-2 DISCHARGE ADAPTER 2
51 8376-3 BACK-UP RING 4
52 8376-4 DISCHARGE SPACER FLANGE 2
53 2976-3 DISCHARGE SPACER FLANGE SEAL 2
54 2976-1 DISCHARGE CONNECTOR / ADAPTER PACKING 2
55 2976-2 DISCHARGE CONNECTOR / ADAPTER PACKING 4
56 R44D RING JOINT GASKET 2
57 4017-22 DISCHARGE SPACER FLANGE STUD (WITH SW PART# HHN1500-6 1-1/2”-6 HEAVY HEX NUT) 16
58 5000-5BFLANGE BLIND FLANGE 5" 1
59 9070012 PONY ROD SEAL 12
60 80491292 SPLASH GUARD 3
61 8376-50A COMPLETE STRAINER CROSS 1
62 8376-50 STUDDED STRAINER CROSS ONLY 1





EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP





SOUTHWEST “OLD STYLE” 8476-A FLUID END

FOR NATIONAL 12-P-160



FLUID END TYPE MODEL OF PUMP SIZE OF PUMP
SOUTHWEST (OLD STYLE) NATIONAL 12-P-160 7-1/2” X 12”





ITEM . P/N DESCRIPTION QTY. REQ’D
  8476-A FLUID END ASSEMBLY: (CONSISTS OF ITEMS 3,4,16,17,18,19, 20, 21,22,23,24,25,26,27,28,29,31,32,33,34,&47)
1 1376YXX LINER (REFER TO GUIDE TO ORDERING CHART FOR TYPE (Y) AND FOR SIZE (XX)) 3
2 2930-XX LINER SEAL (REFER TO GUIDE TO ORDERING CHART FOR TYPE AND SIZE (XX)) 3
3 8476-3 WEARPLATE 3
4 2988 WEARPLATE AND MODULE SEAL 6
5 XX-BYY PISTON (REFER TO GUIDE TO ORDERING CHART FOR SIZE (XX) AND FOR TYPE (YY)) 3
6 568-225 PISTON O-RING 3
7 1286-32 PISTON ROD (WITH ELASTIC STOP NUT) 3
8 API-4ESN PISTON ROD ELASTIC STOP NUT 3
9 1286-1 SUB ROD 3
10 1286CWY ROD CLAMP (CONSIST OF 10A, 10B, 10C) (FOR CLAMP ONLY, USE 1286C) 6
10A 1200H30 HOSE (1/2” X 30” WITH 1/2” MALE X 3/8” MALE CONNECTIONS) 3
10B 1200140 PIPE 3
10C 4018-92 ROD CLAMP BOLT (7/8 X 5” GRADE 8 BOLT WITH LOCK NUT AND WASHER) 12
11 1200G86 PONY ROD 3
12   VALVE 6
13   VALVE INSERT (IF REQUIRED) 6
14   VALVE SPRING 6
15   VALVE SEAT 6
  SWTM1700 HYDRAULIC SEAT PULLER KIT COMPLETE (REFER TO TOOLS PAGE OF CATALOG FOR DETAILS)
  4476-2A SOUTHWEST HP QUICK-CHANGE VALVE COVER ASSEMBLY (CONSISTS OF ITEMS 16-23) 6
16 4476 THREADED FLANGE 6
17 4597 SCREW GLAND 6
18 4676-2A PLUG (COMPLETE WITH VALVE GUIDE, SCREWS, AND BUSHING) 6
19 P107 HP VALVE COVER PLUG SEAL 6
20 4776R VALVE GUIDE (COMPLETE WITH BUSHING #4700I) 6
21 4700I VALVE GUIDE BUSHING 6
22 4016-98 VALVE GUIDE SCREW 12
23 4015-54 VALVE COVER STUD (WITH SW PART# HHN1500-6 1-1/2-6” HEAVY HEX NUT) 72
24 4015-95 POWER END STUD (WITH SW PART# HHN1375-6 1-3/8”6 HEAVY HEX NUT) 30
25 4017-65 LINER RETAINER FERRY HEAD CAP SCREW 18
26 6476 LINER RETAINER FLANGE 3
27 6576 LINER RETAINER NUT 3
28 4018-17 SUCTION MODULE STUD (WITH SW PART# HHN1750-6 1-3/4”-6 HEAVY HEX NUT) 18
29 4018-19 SUCTION MANIFOLD CAP SCREW (WITH LOCK WASHER) 24
30 8576-50 SUCTION MANIFOLD (FRONT OR SIDE INLET) 1
31 AJO419R SUCTION MANIFOLD GASKET 3
32 8476-2S SUCTION MODULE (STUDDED ONLY) 3
33 8476-1D DISCHARGE MODULE (STUDDED ONLY) 3
34 8488-5 DOWEL PIN 6
    ITEMS NUMBERS 35 THRU 46 ARE NOT SHOWN INTENTIONALLY
47 4018-18 DISCHARGE CONNECTOR CAP SCREW (WITH LOCK WASHER) 16
48 4018-39 DISCHARGE SPACER FLANGE SOCKET HEAD CAP SCREW 16
49 8376-1 DISCHARGE CONNECTOR 2
50 8376-2 DISCHARGE ADAPTER 2
51 8376-3 BACK-UP RING 4
52 8376-4 DISCHARGE SPACER FLANGE 2
53 2976-3 DISCHARGE SPACER FLANGE SEAL 2
54 2976-1 DISCHARGE CONNECTOR / ADAPTER PACKING 2
55 2976-2 DISCHARGE CONNECTOR / ADAPTER PACKING 4
56 R44D RING JOINT GASKET 2
57 4017-22 DISCHARGE SPACER FLANGE STUD (WITH SW PART# HHN1500-6 1-1/2”-6 HEAVY HEX NUT) 16





EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP





IDECO     T-1000       7 x 10
  LINERS LINER GASKETS PISTONS PISTON REPLACEMENT RUBBERS
SIZE CERAMIC SUPREME RUBBER URETHANE WHITE LIGHTNING SUPREME GREEN DUO FLEXLIP WHITE LIGHTNING SUPREME
4"           012180170 1502052 011102926   015180102
4 1/4"
4 1/2" 07502450 05502450 07916783 07916789 012180197 012180196 1502054 011102928 015180145 015180144
4 3/4"
5" 07502500 05502500 07916783 07916789 012180254 012180253 1502056 011103033 015180186 015180185
5 1/4"
5 1/2" 07502550 05502550 07916783 07916789 012180338 012180337 1502058 011103132 015180228 015180227
5 3/4"
6" 07502600 05502600 07916783 07916789 012180395 012180394 1502060 011103629 015180269 015180268
6 1/4"   05502625 07916783 07916789   012180493 1502061 011103322 015180285 015180284
6 1/2" 07502650 05502650 07916783 07916789 012180536 012180535 1502062 011103827 015180301 015180300
6 3/4"
7" 07502700 05502700 07916783 07916789 012180619 012180618 1502064 011103926 015180343 015180342
7 1/4"
7 1/2"
7 3/4"
8"

VALVES, SEATS, SPRINGS & INSERTS   GASKETS
  ROUGHNECK ROUGHNECK HP SUPREME     OEM URETHANE L STYLE URETHANE
VALVE-White Lightning Insert 9700367 9700359 060152809   Valve Cover 07916783 07916789
VALVE-Urethane Insert 9700285 9700353 060152808   Cylinder Head 07916783 07916789
VALVE-Rubber Insert 9702601 N/A 060122702   Plug Seal
SEAT 9702547 9702547 061102653   HYDRA-LOK OEM MISSION L
SPRING 8201684 8201684 055413421   Complete Assembly
SPRING-Stainless     055402945
INSERT-Urethane 9705090 9700363 062400106   MODULES OEM MISSION L
INSERT-Rubber 9705155 N/A 062400056   Complete Assembly FEMIDT1000CA
SEAT PULLER ASSEMBLIES Discharge Module Studded
Puller Assembly 1 M 1060 M 1060 M 1060   Suction Module Studded
Puller Head 8401977 8401977 181235052   One Piece OEM Style Studded FEMIDT1000

Crosshead Extension Rods, Quick Connect Rods, Self Aligning Rod Assemblies & Piston Rods
Crosshead Rod Quick Connect Self Aligning Rod Assembly Pony Rod Baffle Piston Rod Sub Rod Stud Rod Nut Clamp Covered Rod Nut Pony Rod Seal
1681540   1095311 07208501 1551717     005402052 PP604800 CRN-1 07931169





EWCO WH-1612 mud pump fluid end module, EWECO E-1600 mud pump Liner, Weatherford WH-2214 MUD PUMP, WH2215 MUD PUMP





NATIONAL 10-P-130
FLUID END MODULE & ACCESSORIES
ITEM OEM PART MISSION PART DESCRIPTION QTY
# # # RETURN TO: NATIONAL INDEX
    FEMNAT10PCA FLUID END MODULE COMPLETE ASSEMBLY
01   FEMNATDIS10P FLUID END MODULE DISCHARGE (STUDDED) - (INCLUDES ITEMS 1, 3-6, 9. 10, 31, 31A) 3
02 1290338 FEMNATSUC8P9P FLUID END MODULE SUCTION (STUDDED) - (INCLUDES ITEMS 2-4, 35) 3
03 2408019 8P80TRS STUD, THREADED RING 72
04 6300220 8P80TRSN NUT (FOR ABOVE) 1 3/8 HVY HX 72
05 2408020 10P130PFS STUD, FRAME 1 1/2X 6 7/8 LG TOP TAPER LK 24
06 6300240 12P160TRSN NUT 1 1/2-6 HVY HX 24
07 2402560 8P80DMS STUD, 1/4 X 61/4 TOP TAPER LOCK 16
08 6300220 PZ789LCSN NUT 1/4 HEAVY HEX 16
09 2408034 8P80DSUCS STUD, DISCHARGE TO SUCTION 1/2X19 1/8 18
10 6300241   NUT, 1 1/2 8 UN-3A HEAVY HEX NUT 18
11 6511416 PEP70 PIN, DOWELL 7/8 X 2 (STANDARD DOWELL) 6
12 1292141 NATVGB BUSHING, VALVE GUIDE 6
13 1292140 NATVGBR RETAINER, VALVE GUIDE BUSHING 6
14 1540126 077970076800 GASKET, VALVE COVER
15 1290174 NAT8PRETSEAL SEAL, RETAINER 6
16 1290178 NATAWS SCREW, ADJUSTING WEDGE 7P THRU 10P 6
17 G-1290376 8P80LW WEDGE ASSEMBLY IND. WEDGES G-1290179-P 6
18 1290181 8P80WS SPRING, WEDGE 6
19 1290308 NAT8PFLG RING, THREADED 6
20 1290307 NAT8PCAP CAP, VALVE COVER (THREADED0 6
21 1290315 8PAWSW WASHER 6
22 6300160 8PAWSN NUT- 1 -8 UNC HEAVY HEX 6
23 2410031427 2410031427 SEAL, DISHARGE CONNECTOR & ADAPTER 4
24 1290343 NAT8PDSMA ADAPTER, DISCHARGE CONNECTOR 2
25 2410031348 2410031348 DISCHARGE CONNECTOR SEAL 3
26 1290342 NATPDSMC CONNECTOR, DISCHARGE 2
27 2410031348 2410031348 SEAL, DISCHARGE CONNECTOR 2
28 700030510   CAPSCREW, 1/2 X 1/2 LG GR5 HX HD 16
29 1290357 PP602000 PLATE, WEAR 3
30 1290165 10PLCA LINER BUSHING 3
31 2408018   STUD, LINER BUSHING 1X 5 7/8 LG TOP TPR LK 18
31A 6300160   NUT, 1" HEAVY HEX FOR ABOVE 18
32 1290166 10P130LC LINER CLAMP 6
32A 700044811   3/4 X 4 LG HX HD CAPSCREW 2
32B **   LOCK WASHER,**(OPTIONAL) 3/4 6
32C 6309120   NUT, 3/4 TWO WAY LOCK NUT 6
32D 1290169   PIN 6
32E G-1290168   LINER CLAMP CONNECTOR 6
32F 6571420   7/32X 1 1/4 LG SPRING SLOT PIN 12
33 1290344   SEAL, MODULE 6
34 1590051   SEAL, SUCTION MANIFOLD 3









Contact Details
Qingdao National Premium Oilwell Machinery Co.,Ltd

Contact Person: Mr. Eric

Tel: 0086-15376875239

Send your inquiry directly to us (0 / 3000)

About Us
Weatherford Mud Pumps
National Mud Pumps
Mud Pump Chrome Liner
Contact Us
Mobile Site
Privacy Policy | China Mud Pump Chrome Liner Supplier. Copyright © 2019 - 2024 premiummudpump.com. All Rights Reserved. Developed by ECER
