Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP

China Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier
Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP supplier

Large Image :  Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP

Product Details:

Place of Origin: CHINA
Brand Name: Gardner Denver, National, Oilwell, Southwest
Certification: API
Model Number: PZ7

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: 1 to 500 usd
Packaging Details: Suitable to shipment by sea and air
Delivery Time: In stock
Payment Terms: T/T, L/C, D/A, D/P, T/T, Western Union
Supply Ability: 3000 per month
Contact Now
Detailed Product Description
Usage: Oil,Water,drill Rig Power: Hydraulic,Pneumatic,diesel
Pressure: High Pressure,Low Pressure,Medium Pressure Application: Conveying Mud And Flushing Fluids,mining,oil,Chemical
Structure: Piston Pump Fuel: Diesel,Gasoline,air Operated,diesel Engine And Hydraulic Motor For Option
Standard Or Nonstandard: Standard Type: Mud Pump
Color: Green Or Per Customer Design Material: Cast Iron/stainless Steel Mud Suction Pump,Chrome Alloy
Warranty: 12 Months Product Name: Mud Pump
Oem: Applicable Condition: New

Part List of PZ7 mud pump

Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP

GARDNER DENVER PZ-7 / PZG 201PZG001A FRAME ASM, INCLUDES REFERENCE NUMBERS 1 THRU 11
GARDNER DENVER PZ-7 / PZG 201PZG001 FRAME
GARDNER DENVER PZ-7 / PZG 64AA9 PLUG, CRADLE DRAIN
GARDNER DENVER PZ-7 / PZG 79A238 STUD, CROSSHEAD INSPECTION PLATE
GARDNER DENVER PZ-7 / PZG 50B5 NUT, CROSSHEAD INSPECTION PLATE
GARDNER DENVER PZ-7 / PZG 64A5 PLUG
GARDNER DENVER PZ-7 / PZG 66D13 PLUG-MAGNETIC, SUMP OIL DRAIN
GARDNER DENVER PZ-7 / PZG 200PZG144 SPACER
GARDNER DENVER PZ-7 / PZG 2012526 STUD, SPACER TO FRAME
GARDNER DENVER PZ-7 / PZG 35C19 KEY, SPACER TO FRAME
GARDNER DENVER PZ-7 / PZG 200PZG247 PLATE, SPACER TO FRAME
GARDNER DENVER PZ-7 / PZG 50B34 NUT, SPACER TO FRAME STUD
GARDNER DENVER PZ-7 / PZG PZ715 GASKET, CROSSHEAD INSPECTION PLATE
GARDNER DENVER PZ-7 / PZG 200PZG052 PLATE-INSPECTION, CROSSHEAD
GARDNER DENVER PZ-7 / PZG 655EE060 SCREW, CROSSHEAD INSPECTION PLATE
GARDNER DENVER PZ-7 / PZG 201PZG253 PLATE-RETAINER
GARDNER DENVER PZ-7 / PZG 655EG050 SCREW, BEARING RETAINER PLATE
GARDNER DENVER PZ-7 / PZG 200PZG006 HOUSING-BEARING, ECCENTRIC
GARDNER DENVER PZ-7 / PZG 201PZG715N GASKET, BEARING COVER PLATE
GARDNER DENVER PZ-7 / PZG 200PZG315 PLATE-BEARING COVER (RIGID SIDE)
GARDNER DENVER PZ-7 / PZG 655EG070 SCREW, BEARING COVER PLATE
GARDNER DENVER PZ-7 / PZG 25C1788N GASKET, INSPECTION PLATE
GARDNER DENVER PZ-7 / PZG 202FXT052 PLATE-INSPECTION
GARDNER DENVER PZ-7 / PZG 655EF050 SCREW, INSPECTION PLATE
GARDNER DENVER PZ-7 / PZG 40L17 GAUGE, OIL LEVEL SIGHT
GARDNER DENVER PZ-7 / PZG 27H11 GAUGE, OIL TEMPERATURE
GARDNER DENVER PZ-7 / PZG 64E2 BUSHING-PIPE
GARDNER DENVER PZ-7 / PZG 200PZG309 SLIDE-CROSSHEAD
GARDNER DENVER PZ-7 / PZG 75LM6 SCREW, CROSSHEAD SLIDE TO FRAME
GARDNER DENVER PZ-7 / PZG 60DD35 SEAL-FASTENER
GARDNER DENVER PZ-7 / PZG 50V44 LOCKNUT
GARDNER DENVER PZ-7 / PZG 201PZG315 PLATE-BEARING COVER (FLOATING SIDE)
GARDNER DENVER PZ-7 / PZG 200PZG053 HOOD, ECCENTRIC
GARDNER DENVER PZ-7 / PZG 655EE040 SCREW, HOOD TO FRAME
GARDNER DENVER PZ-7 / PZG 200PZG715 GASKET, HOOD
GARDNER DENVER PZ-7 / PZG 5C24 BREATHER
GARDNER DENVER PZ-7 / PZG KXG842 PLATE, INSPECTION
GARDNER DENVER PZ-7 / PZG 25C1818 GASKET, INSPECTION PLATE
GARDNER DENVER PZ-7 / PZG 655EF040 SCREW, INSPECTION PLATE
GARDNER DENVER PZ-7 / PZG 25F13 GASKET, INSPECTION PLATE SCREW
GARDNER DENVER PZ-7 / PZG 206PZL052 PLATE-INSPECTION
GARDNER DENVER PZ-7 / PZG 25C1839 GASKET, INSPECTION PLATE
GARDNER DENVER PZ-7 / PZG 655ED040 SCREW, INSPECTION PLATE
GARDNER DENVER PZ-7 / PZG 201PZG052 COVER, LEFT SIDE CRADLE AREA
GARDNER DENVER PZ-7 / PZG 202PZG052 COVER, MIDDLE CRADLE AREA
GARDNER DENVER PZ-7 / PZG 203PZG052 COVER, RIGHT SIDE CRADLE AREA
GARDNER DENVER PZ-7 / PZG 655EG070 SCREW, HOOD TO MAIN BEARING SPACER



Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP

All our fluid end parts are manufactured to API 7K quality standards.



Parts are available for these popular pump models:



BOMCO/Emsco Mud Pumps:F2200HL, F1600HL, F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,



LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600


Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,


National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,


Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,



Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT



Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200



Russian Mud Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32



WEATHERFORD/Ellis Williams: E-447, E-2200



Drillmec Mud Pump: 9T1000, 12T1600, 7TS600, 7TS500, 9T800



Romania Mud Pump: 3PN-1000, 3PN-1600, 3PN-2000



And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.



Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP



1,Plunger Size 3.38” - 4.00” Valve Part No. P107185 Seat Part No. P107802
Insert Part No. P107186 Spring
2,Plunger Size 4.50” Valve Part No. P107181 Seat Part No. P107180
Insert Part No. P107182 Spring
3,Plunger Size 5.00” - 6.00” Valve Part No. P107188 Seat Part No. P107187
Insert Part No. P107189 Spring4P102382
SPM2000压裂泵的型号及规格
1,Plunger Size 3.75" Plunge Part No 3P103887
2,Plunger Size 4.00" Plunge Part No 3P100339
3,Plunger Size 4.50" Plunge Part No 3P100654
4,Plunger Size" 5.00" Plunge Part No 3P100233
5,Plunger Size" 5.50 Plunge Part No 3P107060
6,Plunger Size" 5.75" Plunge Part No 3P107061
7,Plunger Size 6.00 Plunge Part No 3P107062
SPM压裂泵的型号
TWS 250 Plunger Size 1.75"-3" 3.25"-4"
TWS 400 Plunger Size 2 .50"-3" 3 .50"-4 .50”
TWS 500LW-600 Plunger Size 2 .75" 3"-4 .75"
TWS 600S Plunger Size 2 .50"-3" 3.50"-4 .50"
TWS 900 Plunger Size 3.50"-4"
TWS 1250LW Plunger Size 4"
OPI880 Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0”
TWS1000LW,TWS1300
Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0” 6.5 “ 6.75”
TWS1600 Plunger Size 3.5” 3.75” 4.0” 4.50” 5.0” 5.5” 5.75 “6.0”
TWS1800 Plunger Size 3.5” 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0”
TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
5.50” 5.75” 6.0”
TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5



Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP



Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300
Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600
Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652
Gardner Denver ® Mud Pumps
PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL
Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225
Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T
Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550
Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500
Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600
National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400
National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A
National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160
Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT
Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT
Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B
OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL
Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036
Fluid End Modules

Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP



Description PZ-7 mud pump PZ-8 mud pump PZ-9 mud pump

PZ-10 and PZ-11

mud pump
Liner of Crosshead Upper 200PZG309 2012509 PZ222 200PZL309
Liner of Crosshead Lower 200PZG309 2012509 PZ222 200PZL309
Pin of Crosshead 200PZG189 200PZH189 PZ189 200PZL706
Extension Rod 200PZH839 1PO183 PZ183 200PZL839
Sub Rod
Crosshead 200PZG005 200PZH005 PZ175 200PZL005
Pinion Shaft 200PZG371 2012507 1PZ371 200PZK371
Connecting Rod 200PZG003 2012506 PZ417 200PZL003
Bull Gear 200PZG280 2012508 1PZ180 200PZK280
Bearing, Crosshead 97A29 12BA44 12AM3 12BA5
Bearing, Pinion Shanft 12W75 12W58 12W60 12W73
Bearing, Eccentric 12BA18 12W85 12W84 12BA6
Bearing, Main 12BA20 12GF38 12GF36 12BA4



Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP





NATIONAL 14-P-220 (7500 PSI) W/ FAST CHANGE VALVE COVERS FLUID END MODULE & ACCESSORIES
ITEM # OEM PART # DESCRIPTION QTY PER PUMP
  80718020 ASSY, COMPLETE FLUID END W/ VALVE SERVICE & SUCTION MANIFOLD 1
1 1295601 MODULE, STUDDED FLUID END DISCHARGE (INCLUDES ITEMS 1, 3-10) 3
2 1295604 MODULE, STUDDED FLUID END SUCTION (INCLUDES ITEMS 2, 3-4) 3
3 2408049 STUD, VALVE COVER 84
4 6300240 NUT, VALVE COVER STUD 84
5 2408027 STUD, POWER FRAME 30
6 6300240 NUT, POWER FRAME STUD 30
7 2408047 STUD, LINER BUSHING 18
8 6300200 NUT, LINER BUSHING STUD 18
9 2408048 STUD, SUCTION TO DISCHARGE MODULE 18
10 6300320 NUT, SUCTION TO DISCHARGE MODULE STUD 18
11 2408014 STUD, DISCHARGE FLANGE 12
12 6300180 NUT, DISCHARGE FLANGE STUD 12
13 1295262 SPACER, STUDDED DISCHARGE (NOT SHOWN) INCLUDED ITEM# 11 AND 12 2
14 1295258 SEAL, DISCHARGE SPACER (NOT SHOWN) 2
15 7006609 CAPSCREW, DISCHARGE SPACER FLANGE 24
16 1295176 RING, THREADED F/C 6
17 1295172 CAP, VALVE COVER (THREADED) F/C 6
18 1292353 PULLER, SEAL RETAINER 6
19 1295174 RETAINER, SEAL 6
20 1540163 SEAL, VALVE COVER 6
21 1292140 HOLDER, VALVE GUIDE INSERT 6
22 1292141 INSERT, VALVE GUIDE 6
23 1540021 SEAL, SUCTION MANIFOLD 3
24 700048511 CAPSCREW, SUCTION MANIFOLD 24
25 2410031440 SEAL, DISCHARGE CONNECTOR & DISCHARGE ADAPTER 4
26 1295253 ADAPTER, DISCHARGE CONNECTOR 2
27 2410031438 SEAL, DISCHARGE CONNECTOR TO DISCHARGE ADAPTER 2
28 1295252 CONNECTOR, DISCHARGE 2
28A 1295175 RING, DISCHARGE CONNECTOR BACK UP 4
29 7619050 WASHER, DISCHARGE CONNECTOR CAPSCREW (NOT SHOWN) 16
30 700030711 CAPSCREW, DISCHARGE CONNECTOR 16
31 6511416 PIN, DOWELL 6
32 1295266 PLATE, WEAR 3
33 1295165 BUSHING, LINER 3
34 1295166 CLAMP COMPLETE, LINER (INCLUDES ITEMS 34A, 34B, 34C, 34D, 34E, 34F) 3
34A 1295167 CLAMP, LINER 3
34B 700049110 CAPSCREW, LINER CLAMP 6
34C 6309140 NUT, LINER CAPSCREW 6
34D 1292169 PIN, LINER CLAMP 6
34E G1292168P CONNECTOR, LINER CLAMP 6
34F 6571620 PIN, SPRING 12




Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP



NATIONAL 12-P-160 W/ TAPR-LOK VALVE COVERS FLUID END MODULE & ACCESSORIES
ITEM # OEM PART # MISSION PART # DESCRIPTION QTY PER PUMP
    FEMNAT12PCA FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS: 1, 2, 3-10, 29-35) 3
1 1292240 FEMNATDIS12P MODULE, STUDDED FLUID END DISCHARGE (INCLUDES ITEMS 1, 3-10) 3
1A 1292601 FEMNATDIS12PA MODULE, STUDDED FLUID END DISCHARGE W/ AUTOFRETTAGE (INCLUDES ITEMS 1A, 3-10) 3
2 1292243 FEMNATSUC12P MODULE, STUDDED FLUID END SUCTION (INCLUDES ITEMS 2, 3-4) 3
2A 1292604 FEMNATSUC12PA MODULE, STUDDED FLUID END SUCTION W/ AUTOFRETTAGE (INCLUDES ITEMS 2A, 3-4) 3
3 2408027 12P160TRS STUD, THREADED RING 72
4 6300240 12P160TRSN NUT, THREADED RING STUD 72
5 2408029 12P160PFS STUD, POWER FRAME 30
6 6300220 8P80TRSN NUT, POWER FRAME STUD 30
7 2408028 12P160LCS STUD, LINER BUSHING 18
8 6300180 12P160LCSN NUT, LINER BUSHING STUD 18
9 2408033 12P160DSUCS STUD, DISCHARGE MODULE TO SUCTION MODULE 18
10 6300281 PEP55 NUT, DISCHARGE TO SUCTION MODULE STUD 18
11 2408015 12P160DMS STUD, SPACER FLANGE 16
12 6300240 12P160TRSN NUT, SPACER FLANGE STUD 16
13 6511416 PEP70 PIN, DOWELL 6
14 1292141 NATVGB BUSHING,VALVE GUIDE 6
15 1292140 12PVGBR RETAINER, VALVE GUIDE BUSHING 6
16 1540127 1540127 GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
17 1292174 NAT12PRETSEAL RETAINER, VALVE & SEAL 6
18 1292178 NAT12PAWS SCREW, ADJUSTING WEDGE 6
19 6300182 12P160AWSN NUT, WEDGE ADJUSTING SCREW 6
20 1292171 12P160AWSW WASHER, WEDGE ADJUSTING SCREW 6
21 G1292268 12P160LW ASSEMBLY, WEDGE (INCLUDES ITEM # 20 WEDGE SPRING) 6
22 1292181 12P160WS SPRING, WEDGE 6
23 1292176 NAT12PFLG RING, THREADED 6
24 1292172 NAT12PCAP CAP, VALVE COVER (THREADED) 6
25 2410031437 2410031437 SEAL, DISCHARGE CONNECTOR & DISCHARGE ADAPTER 4
26 1292253 NAT12PDSMA ADAPTER, DISCHARGE CONNECTOR 2
27 2410031433 2410031433 SEAL, DISCHARGE CONNECTOR TO DISCHARGE ADAPTER 2
28 1292252 NAT12PDSMC CONNECTOR, DISCHARGE 2
28A 1292717 1292717 BACK UP RING, DISCHARGE CONNECTOR 2
29 7006685 7006685 CAPSCREW, DISCHARGE SPACER FLANGE 16
30 700030711 700030711 CAPSCREW, DISCHARGE CONNECTOR 16



Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP





MISSION "L" MODULE FOR LEWCO W2215 7500 PSI W/ SWOP FE FLUID END MODULE & ACCESSORIES
ITEM # OEM PART # MISSION PART # DESCRIPTION QTY PER PUMP
  8482-25LEWA   FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS 1-22)
1 8482-27 80732001 MODULE, SUCTION STUDDED (INCLUDES ITEMS 1, 7-8) 3
2 8482-26 80732000 MODULE, DISCHARGE STUDDED (INCLUDES ITEMS 2-9) 3
3 /4020-6 80732002 STUD, DISCHARGE TO SUCTION MODULE 18
4 2"-8 HH 7402422 NUT, DISCHARGE TO SUCTION STUD 18
5 4020-26 80732004 STUD, POWER END 30
6 1-1/2-6 HH 6300240 NUT, POWER END STUD 30
7 4015-54 12PTRSSW STUD, THREADED RING 72
8 1-1/2-6 HH 6300240 NUT, THREADED RING STUD 72
9 /8488-5 6511416 PIN, DOWELL 6
10 4015-52 80732005 STUD, LINER RETAINER FLANGE 18
11 1-1/4-7 HH   NUT, LINER RETAINER FLANGE STUD 3
12 May-82 80732007 PLATE, LINER WEAR 3
13 2988 1290344 GASKET, WEAR PLATE AND MODULE - RUBBER (SEE DATASHEET FOR ALT MATLS) 6
14 6482   FLANGE, LINER RETAINER (LINER BUSHING) 3
15 6582   NUT, LINER RETAINER 3
16 4609-25A   ASSY, VALVE COVER PLUG (INCLUDES ITEMS 15,16, 20-22) 6
17     PLUG, VALVE COVER 6
18 4476 12PFLGSW RING, THREADED (THREADED FLANGE) 6
19 4597 12PCAPSW CAP, THREADED (SCREW GLAND) 6
20 P-119 7207119 SEAL, VALVE COVER PLUG - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
21 4776R 12PVGASWNS ASSEMBLY, VALVE GUIDE (INCLUDES ITEMS 20 & 21) 6
22 4700I PZ789VGI* BUSHING, VALVE GUIDE 6
23 4016-98 50C125KFCYB SCREW, VALVE GUIDE 12
24     CAPSCREW, SUCTION MANIFOLD
25     GASKET, SUCTION MANIFOLD 3
26 4019-60   STUD, DISCHARGE MANIFOLD 18
27 1-1/4-7 HH   NUT, DISCHARGE MANIFOLD 18
28 8382-25   MANIFOLD, DISCHARGE 1
29 2988 1290344 SEAL, DISCHARGE MANIFOLD 3



Gardner Denver PZ7 mud pump parts, PZ8 MUD PUMP, PZ9 MUD PUMP, PZ10 MUD PUMP, PZ11 MUD PUMP, PAH275 MUD PUMP















Contact Details
Qingdao National Premium Oilwell Machinery Co.,Ltd

Contact Person: Mr. Eric

Tel: 0086-15376875239

Send your inquiry directly to us (0 / 3000)

About Us
Weatherford Mud Pumps
National Mud Pumps
Mud Pump Chrome Liner
Contact Us
Mobile Site
Privacy Policy | China Gardner Denver Mud Pumps Supplier. Copyright © 2019 - 2024 premiummudpump.com. All Rights Reserved. Developed by ECER
