Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump

China Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier
Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump supplier

Large Image :  Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump

Product Details:

Place of Origin: China
Brand Name: Gardner Denver, National, Oilwell, Southwest
Certification: API
Model Number: Gardner Denver PZ8/9 mud pump

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: 50 to 100 USD
Packaging Details: Long term shipment by sea and air
Delivery Time: Some in stock
Payment Terms: T/T, L/C, D/A, D/P, T/T, Western Union
Supply Ability: 3000 pieces
Contact Now
Detailed Product Description
Usage: Oil,Water,drill Rig Power: Electric
Pressure: High Pressure Application: Conveying Mud And Flushing Fluids,mining,oil
Structure: Piston Pump,Single-stage Pump Fuel: Diesel
Standard Or Nonstandard: Standard Theory: Centrifugal Pump
Type: Mud Pump Color: Red And So On,Green Or Per Customer Design
Material: Cast Iron/stainless Steel Mud Suction Pump,Chrome Alloy Warranty: 12 Months
Feature: Compact Size,mud Suction Pump Product Name: Mud Pump
Head: 10m Mud Suction Pump,85mm Oem: Can Be Accept,Applicable
Condition: New

Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump

Premium can make all model mud pump liners of Gardner Denver for PAH, PJ-8, PZ-7, PZ-8, PZ-9, PZ-10, PZ-11, PX11, PZL models.



Part number of  Gardner Denver PZ8/9 mud pump mud pump liner:



Gardner Denver PZ-8/9

206PZJ456

05493400 PREM

205PZJ456

05493450 PREM

204PZJ456

05493500 PREM

203PZJ456

05493550 PREM

202PZJ456

05493600 PREM

200PZJ456

05493650 PREM

207PZJ456

05493700 PREM



Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump

Since creating the first drilling mud pump more than 100 years ago, Gardner Denver Pumps has had a reputation for setting new industry standards for high-performance mud pumps for drilling rigs. Our customers prefer our drilling pumps because of the field-tested durability and ease of maintenance.



All Gardner Denver triplex pumps are machined for extreme applications and built for resilience. Our sub-assemblies, including our power ends and long-lasting fluid ends, maximize the efficiency and productivity of each Gardner Denver mud pump.



PZ11 MUD PUMP

PZ10 MUD PUMP

PZ9 MUD PUMP

PZ8 MUD PUMP

PZ7 MUD PUMP

PAH275 MUD PUMP



Mud Pump Models 4” 4-1/2” 5” 5-1/2” 6” 6-1/2” 7” 7-1/2”
Continental Emsco F-800 / 1000   05495450 05495500 05495550 05495600 05495650 05495700
Continental Emsco FB-1300 / 1600 05499400 05499450 05499500 05499550 05499600 05499650 05499700
Gardner Denver PZ-7 PY13940 PY13945 PY13950 PY13955 PY13960 PY13965 PY13970
Gardner Denver PZ-8/9 05493400 05493450 05493500 05493550 05493600 05493650 05493700
Gardner Denver PZ-10/11 05496400 05496450 05496500 05496550 05496600 05496650 05496700
Ideco T-800 / 1000 05502400 05502450 05502500 05502550 05502600 05502650 05502700
Ideco T-1300 / 1600   05507450 05507500 05507550 05507600 05507650 05507700
National 8-P-80 05464400 05464450 05464500 05464550 05464600 05464650
National 9-P-100 / 10-P-130 05465400 05465450 05465500 05465550 05465600 05465650
National 12-P-160 05466400 05466450 05466500 05466550 05466600 05466650 05466700
National 14-P-220 05545400 05545450 05545500 05545550 05545600 05545650 05545700
Oilwell A-850-PT / A-1100-PT 05330400 05330450 05330500 05330550 05330600 05330650 05330700 05330750
Oilwell A-1400-PT / A-1700-PT 05326400 05326450 05326500 05326550 05326600 05326650 05326700 05326750





Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump



MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE) QTY PER PUMP
FLUID END MODULE & ACCESSORIES (INCLUDING DISCHARGE MANIFOLD)
ITEM # MISSION PART # DESCRIPTION
  80704032 FLUID END ASSEMBLY COMPLETE INCLUDES ITEMS (1-27) ENOUGH FOR 1 PUMP 1
1 80704000 MODULE, DISCHARGE STUDDED (INCLUDES ITEMS 1,9,10,13,14,18,19,20,& 27) 3
2 80704001 MODULE, SUCTION STUDDED (INCLUDES ITEMS 2,3,4,18,&19) 3
3 80704002 STUD, (DISCHARGE TO SUCTION MODULE) 24
4 PEP55 NUT, HEAVY HEX 24
5 80704003 THREADED RING 6
6 80704004 THREADED CAP 6
7 80704005 VALVE COVER (INCLUDES 11,12,& 17) 6
8 80704006 DISCHARGE MANIFOLD (7500 PSI WORKING PRESSURE) 1
9 80702011 STUD, DISCHARGE MANIFOLD 12
10 IDT800TRSN NUT,HEX HEAVY 12
11 PZ789VGI BUSHING, VALVE GUIDE 6
12 12PVGASW GUIDE, VALVE 6
13 8P80TRSN NUT, POWER FRAME STUD 30
14 PEP75 CAPSCREW, LINER RETAINER 18
15 12PLASW RETAINER, LINER FLANGE 3
16 12PLANSW NUT, LINER RETAINER 3
17 7007303 SCREW, VALVE GUIDE 12
18 6300240 NUT, HEAVY HEX FOR THREADED RING 72
19 80700014 STUD, THREADED RING 72
20 PEP70 PIN, DOWELL 6
21 1290344 SEAL, DISCH TO SUC & WEARPLATE - RUBBER (SEE DATASHEET FOR ALT MATLS) 6
22 07207129 SEAL, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 3
23 99609235 SEAL, DISCHARGE MANIFOLD 3
24 1540851 SEAL, SUCTION MANIFOLD 3
25 700048511 CAPSCREW, SUCTION MANIFOLD 3
26 PP6021260SW WEARPLATE 3
27 NAT12P160PFS STUD, POWER FRAME 30



Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump



MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160       QTY PER PUMP
FLUID END MODULE & ACCESSORIES
ITEM # OEM PART # MISSION PART #
    FEM12PASSYSWNS FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS: 1-23) 3
1 8476-6S FEM12PSUCSWNS MODULE, SUCTION STUDDED (INCLUDES ITEMS: 1,13,14,& 22) 3
2 8476-5D FEM12PDISSWNS MODULE, DISCHARGE STUDDED - (INCLUDES ITEMS: 2,3,4,5,6,7,8,13 & 14) 3
3 4018-17 12P160DSUCS STUD, DISCHARGE TO SUCTION MODULE 18
4   PEP55 NUT, DISCHARGE TO SUCTION STUD 18
5 4015-95 NAT12P160PFS STUD, POWER END 30
6   8P80TRSN NUT, POWER END STUD 30
7 8488-5 PEP70 PIN, DOWELL 6
8 4017-65 PEP75 CAPSCREW,LINER RETAINER SOCKET HEAD 18
9 8476-3 PP6021260SW PLATE, LINER WEAR 3
10 2988 1290344 GASKET, WEAR PLATE AND MODULE - RUBBER (SEE DATASHEET FOR ALT MATLS) 6
11 6476 12PLASW FLANGE, LINER RETAINER (LINER BUSHING) 3
12 6576 12PLANSW NUT, LINER RETAINER 3
13 4015-54 12PTRSSW STUD, THREADED RING 72
14   12P160TRSN NUT, THREADED RING STUD 72
15 4676-6A 12PVCASSYSWNS PLUG, VALVE COVER (INCLUDES ITEMS 15,19,20,& 21) 6
16 4476 12PFLGSW RING, THREADED (THREADED FLANGE) 6
17 4597 12PCAPSW CAP, THREADED (SCREW GLAND) 6
18 P-119 07207119 SEAL, VALVE COVER PLUG - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
19 4776R 12PVGASWNS ASSEMBLY, VALVE GUIDE(INCLUDES ITEMS 19,& 20) 6
20 4700-I PZ789VGI BUSHING, VALVE GUIDE 6
21 4016-98 PEP73 SCREW, VALVE GUIDE 12
22 4018-19 700048511 CAPSCREW, SUCTION MANIFOLD 24
23 AJO-419R 1540851 GASKET, SUCTION MANIFOLD 3
24 8376-2 NAT12PDSMA ADAPTER, DISCHARGE 2
25 2976-2 2410031437 SEAL, DISCHARGE ADAPTER 4
26 8376-1 NAT12PDSMC CONNECTOR, DISCHARGE 2
27 2976-1 2410031433 SEAL, DISCHARGE CONNECTOR TO DISCHARGE ADAPTER 2
28 4018-18 700030711 CAPSCREW, DISCHARGE CONNECTOR (W /LOCKWASHER) 16
29 8376-3 1292175 RING, BACKUP (DISCHARGE CONNECTOR) 4



Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump





MISSION "L" MODULE FOR NATIONAL12-P-160       QTY PER PUMP
FLUID END MODULE & ACCESSORIES
ITEM # OEM PART # MISSION PART #
  8476-A FEM12PASSYSW FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS: 1-23) 3
1 8476-2S FEM12PSUCSW MODULE, SUCTION STUDDED (INCLUDES ITEMS: 1,13,14,& 22) 3
2 8476-1D FEM12PDISSW MODULE, DISCHARGE STUDDED - (INCLUDES ITEMS: 2,3,4,5,6,7,8,13 & 14) 3
3 4018-17 12P160DSUCS STUD, DISCHARGE TO SUCTION MODULE 18
4   PEP55 NUT, DISCHARGE TO SUCTION STUD 18
5 4015-95 NAT12P160PFS STUD, POWER END 30
6   8P80TRSN NUT, POWER END STUD 30
7 8488-5 PEP70 PIN, DOWELL 6
8 4017-65 PEP75 CAPSCREW,LINER RETAINER SOCKET HEAD 18
9 8476-3 PP6021260SW PLATE, LINER WEAR 3
10 2988 1290344 GASKET, WEAR PLATE AND MODULE - RUBBER (SEE DATASHEET FOR ALT MATLS) 6
11 6476 12PLASW FLANGE, LINER RETAINER (LINER BUSHING) 3
12 6576 12PLANSW NUT, LINER RETAINER 3
13 4015-54 12PTRSSW STUD, THREADED RING 72
14   12P160TRSN NUT, THREADED RING STUD 72
15 4676-2A 12PVCSW PLUG, VALVE COVER (INCLUDES ITEMS 15,19,20,& 21) 6
16 4476 12PFLGSW RING, THREADED (THREADED FLANGE) 6
17 4597 12PCAPSW CAP, THREADED (SCREW GLAND) 6
18 P-107 07207107 SEAL, VALVE COVER PLUG - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
19 4776R 12PVGSWNS GUIDE, VALVE (INCLUDES ITEMS 19,& 20) 6
20 4700-I PZ789VGI BUSHING, VALVE GUIDE 6
21 4016-98 PEP73 SCREW, VALVE GUIDE 12
22 4018-19 700048511 CAPSCREW, SUCTION MANIFOLD 24
23 AJO-419R 1540851 GASKET, SUCTION MANIFOLD 3
24 8376-2 NAT12PDSMA ADAPTER, DISCHARGE 2
25 2976-2 2410031437 SEAL, DISCHARGE ADAPTER 4
26 8376-1 NAT12PDSMC CONNECTOR, DISCHARGE 2
27 2976-1 2410031433 SEAL, DISCHARGE CONNECTOR TO DISCHARGE ADAPTER 2
28 4018-18 700030711 CAPSCREW, DISCHARGE CONNECTOR (W /LOCKWASHER) 16
29 8376-3 1292175 RING, BACKUP (DISCHARGE CONNECTOR) 4
30 4018-39 7006685 CAPSCREW, SOCKET HEAD 16





Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump







Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300

Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600

Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652

Gardner Denver ® Mud Pumps

PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL

Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225

Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T

Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550

Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500

Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600

National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400

National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A

National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160

Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT

Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT

Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B

OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL

Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036

Fluid End Modules

National® - Oilwell® - Continental Emsco® - Gardner Denver® - Ideco® - Skytop Brewster®

Pulsation Dampener

Hydril Type "K" Pulsation Dampener

Popular Mud Pump Spare Parts



Gardner Denver PZ8/9 mud pump liner, GD mud pump, pump mud, Continental Emsco, Southwest, Texma, Weatherford mud pump

Mud Pump Manufactures and Models include:

Brewster Mud Pumps

B-550 | B-750 | B-1000 | 1100T | B-1300

Continental Emsco Mud Pumps

FF-FXF | FG-FXG (A thrugh L) | FD-FXX | FC-FXX | FD-FXD | FC-FXD | FY-FXD

Continental Emsco Mud Pumps

GP-GXP | GR-GXP | GP-GXR | GR-GXR |PA-8 | PAH

Continental Emsco Mud Pumps

PJ8 | PZ-7 | PZ-8 | PZ-9 | PZ-10 | PZ-11 | PXL

Ellis Williams (Luko) Mud Pumps

WW-440 | 14W-400 | 15W-600 | 9W-1000

Gaso Mud Pump

1563 | 1740-55 | 1844-60 | 2010-50 | 2200-49 | 2651 | 2652

Gardner Denver Mud Pumps

FF-FXF;FG-FXG;A thru L FD-FXX FC-FXX FD-FXD FC-FXD FY-FXD GP-GXP GR-GXP GP-GXR GR-GXR PA-8 PJ8 PZ-7 PZ-8 PZ-9 PZ-10 PZ-11 PXL



Ideco Mud Pumps

MM-200 | MM-300 | MM-500 | MM-500F | MM-550

Ideco Mud Pumps

MM-550F | MM-700 | MM-700F | T-500

Ideco Mud Pumps

T-800 | T-1000 | T-1300 | T-1600

National Mud Pumps

C-150 | C-250 | C-350 | E-500 | E-700 | G-700 | G-1000



National Mud Pumps

K-280 | K-380 | K-500 | K-500A | K-700A



National Mud Pumps

7P-50 | 8P-80 | 9P-100 | 10P-130 | 12P-160



Oilwell Mud Pumps

6P-HD | 610-P | 212-P | 214-P | 218-P



Oilwell Mud Pumps

350-PT | 560-PT | A-560-PT | 850-PT | A-850-PT | 1100-PT



Oilwell Mud Pumps

A-1100-PT | 1400-PT | A-1400-PT | 1700-PT | A-1700-PT



OPI Mud Pumps

350-D | 700-HDL | 1000-HDL



Wheatley Mud Pumps

1036 | 6070 | 7024 | 7036



Wilson Mud Pumps

600 | 900















Contact Details
Qingdao National Premium Oilwell Machinery Co.,Ltd

Contact Person: Mr. Eric

Tel: 0086-15376875239

Send your inquiry directly to us (0 / 3000)

About Us
Weatherford Mud Pumps
National Mud Pumps
Mud Pump Chrome Liner
Contact Us
Mobile Site
Privacy Policy | China Mud Pump Chrome Liner Supplier. Copyright © 2019 - 2024 premiummudpump.com. All Rights Reserved. Developed by ECER
