Weatherford E-1600 mud pump Ceramic Liner, Weatherford E-2200 mud pump Zirconia Liner, W-2215 mud pump Hy-Chrome Liner
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Usage: | Oil,Water,drill Rig | Power: | Electric,diesel |
|---|---|---|---|
| Pressure: | High Pressure,Low Pressure | Application: | Mining,oil |
| Structure: | Piston Pump | Fuel: | Diesel,Gasoline |
| Standard Or Nonstandard: | Standard | Type: | Mud Pump |
| Color: | Red And So On,Green Or Per Customer Design | Material: | Cast Iron/stainless Steel Mud Suction Pump,Chrome Alloy |
| Warranty: | 12 Months | Feature: | Compact Size |
| Product Name: | Mud Pump | Oem: | Can Be Accept |
| Condition: | New |
Website: www.premiumrigparts.com
Weatherford is one of the world's largest multinational oil and natural gas service companies. The company provides products and services for drilling, evaluation, completion, production and intervention of oil and natural gas wells, along with pipeline construction and commissioning. Headquartered in Switzerland, Weatherford operates in more than 100 countries across the globe and employs more than 35,000 people (2016).
Weatherford offers a full line of premium-quality mud pumps based on proven and
simple-to-maintain designs that are accepted around the world. Each pump comes with
exceptional service and support that only a true global provider like Weatherford can
promise. When you factor in our competitive pricing and off-the-shelf availability of pumps
and parts, it’s clear that Weatherford has raised the bar for mud pumps.
| Weatherford | |||||||
| 4” | 4-1/2” | 5” | 5-1/2” | 6” | 6-1/2” | 7” | |
| E-800 | 1317096 | 1317156 | 1317211 | 1317262 | 1317311 | 1317357 | 1317393 |
| E-447 | 1244387 | 1244388 | 1244389 | 1244390 | 1244391 | / | / |
| E-2200 | 1806118 |
1806120/ 1244331 |
1806122/ 1292705 |
1806122/ 1292705 |
1806124/ 1280615 |
1806126/ 1280614 |
1806128/ 1244330 |
| MP-8/10 | 1317095 | 1317155 | 1279784 | 1279787 | 1279819 | 117356 | 1317375 |
| MP-13/16 | 1317099 | 1317159 | 1317213 | 1317264 | 1317313 | 1317359 | 1317396 |
| MP-5 | 1317093 | 1317153 | 1317209 | 1317260 | 1317309 | 1317355 | / |
| MP-16 2-Piece 5000 psi | 1317099 | 1317159 | 1317213 | 1317264 | 1317313 | 1317359 | 1317396 |
| MP-16 2-Piece 7500 psi | 1280517 | 1280519 | 1280521 | 1280523 | 1280529 | 1280531 | 1280538 |
| W165/340 | 1788209 | 1788210 | 1315942 | 1788208 | |||
| Emsco F-800 / 1000 | 1317095 | 1279781 | 1279784 | 1279787 | 1279819 | 1317356/1279820 | / |
| Emsco FB-1300 / 1600 | / | 1317190 | 1279899 |
1317264/ 1279902 |
1317313 | 1317359 |
1279970/ 1317396 |
| Gardner Denver PZ-8/9 | / | 1317167 |
1280679/ 1317211 |
1280681/ 1317272 |
1280684/ 1317311 |
1280686/ 1317357 |
1317393/ 1317400 |
| Gardner Denver PZ-10/11 | 1280702 | 1280704 | 1280706 | 1280709 | 1280711 | 1280715 | 1317394 |
| Ideco T-800 / 1000 | 1280753 | 1280755 | 1280757 | 1280759 | 1280761 | 1280765 | 1280767 |
| Ideco T-1300 / 1600 | 1317097 | 1317157 | 1317212 | 1317263 | 1317312 | 1317358 | 1317395 |
| National 9-P-100 / 10-P-130 | / | / | / | 1317259 | 1317308 | 1317354 | / |
| National 12-P-160 | 1280517 | 1280519 | 1280521 | 1280523 | 1280529 | 1280531 | 1280533 |
| National 14-P-220 | / | / | 1280378 | 1280386 | 1280390 | 1280410 | 1280412 |
| National JWS-165/340 | 1788209 | 1788210 | 1315942 | 1788208 | / | / | / |
| Oilwell A-1400-PT / A-1700-PT | 1280105 | 1280108 | 1280109 | 1280112 | 1280114 | 1280117 | 1280119 |
| Ellis Williams E-1600 | / | / | 1320730-01 | 1320730-02 | 1320730-03 | 1320730-04 | 1320730-05 |
All our fluid end parts are manufactured to API 7K quality standards.
Parts are available for these popular pump models:
BOMCO/Emsco Mud Pumps:F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,
LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600
Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,
National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,
Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,
Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT
Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200
Russian Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32
WEATHERFORD/Ellis Williams: E-447, E-2200
Drillmec: 9T1000, 12T1600, 7TS600, 7TS500, 9T800
Romania: 3PN-1000, 3PN-1600, 3PN-2000
And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.
| "L" MODULE FOR EMSCO FB-1300, FB-1600 | QTY PER PUMP | |||
| FLUID END MODULE & ACCESSORIES | ||||
| ITEM # | OEM PART # | MISSION PART # | DESCRIPTION | |
| FEMFB13ASSYSW | FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS: 1 - 27) | 3 | ||
| 1 | 8490-1D | FEMFB13DISSW | MODULE, DISCHARGE STUDDED (INCLUDES ITEMS:1, 3-11) | 3 |
| 2 | 8490-2S | FEMFB13SUCSW | MODULE, SUCTION STUDDED (INCLUDES ITEMS: 2, 5, 6, & 27) | 3 |
| 3 | 4016-97 | OWA17DSUCSSW | STUD, DISCHARGE TO SUCTION MODULE | 18 |
| 4 | EMSF1000PFSN | NUT, DISCHARGE TO SUCTION STUD | 18 | |
| 5 | 4015-2 | OWA17TRSSW | STUD, THREADED RING | 72 |
| 6 | PZ789GPFSN | NUT, THREADED RING STUD | 72 | |
| 7 | 4016-9 | EMSFB13PFSSW | STUD, POWER FRAME | 18 |
| 8 | EMSF1000PFSN | NUT, POWER FRAME STUD | 18 | |
| 9 | 4017-36 | PEP80 | CAPSCREW, LINER RETAINER FLANGE (SOCKET HEAD) | 24 |
| 10 | 4017-46 | FB1300DMSSW | STUD, DISCHARGE MANIFOLD | 12 |
| 11 | IDT800TRSN | NUT, DISCHARGE MANIFOLD STUD | 12 | |
| 12 | 8488-5 | PEP70 | PIN, DOWELL | 6 |
| 13 | 2988 | 1290344 | SEAL, SUC TO DISCH MOD & WEAR PLATE - RUBBER (SEE DATASHEET FOR ALT MATLS) | 6 |
| 14 | 8422-3 | EMSF1000ARSW | RING, LINER RETAINER PILOT | 3 |
| 15 | 8490-3 | EMSFB13WPSW | PLATE, LINER WEAR | 3 |
| 16 | 6490-3 | EMSFB13LRPSW | FLANGE, LINER RETAINER | 3 |
| 17 | 6590-1 | EMSFB13LLSW | NUT, LINER LOCK | 3 |
| 18 | P-129 | 07207129 | GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 6 |
| 19 | 4016-99 | PEP73 | CAPSCREW, VALVE GUIDE | 12 |
| 20 | 4700-I | PZ789VGI | BUSHING, VALVE GUIDE | 6 |
| 21 | 4775-2R | EMSFB13VGASW | GUIDE, VALVE (INCLUDES ITEMS 20, 21) | 6 |
| 22 | 4675-2A | EMSFB13VCASW | PLUG, VALVE COVER (INCLUDES ITEMS 19-22) | 6 |
| 23 | 4475 | OWA17FLGSW | RING, THREADED | 6 |
| 24 | 4575 | OWA17CAPSW | CAP, THREADED | 6 |
| 25 | 568-343 | 99609343 | GASKET, DISCHARGE MANIFOLD | 3 |
| 26 | 568-442 | 99609442 | GASKET, SUCTION MANIFOLD | 3 |
| 27 | 4018-19 | 700048511 | CAPSCREW, SUCTION MANIFOLD | 18 |
Southwest
A1400/1700PT Mud Pump
| "L" MODULE FOR A-1400-PT, A-1700PT | QTY PER PUMP | |||
| FLUID END MODULE & ACCESSORIES | ||||
| ITEM # | OEM PART # | MISSION PART # | DESCRIPTION | |
| 8488-1A | FEMA17ASSYSW | FLUID END MODULE COMPLETE ASSY. (INCLUDES ITEMS: 1-28) | 3 | |
| 1 | 8488-1D | FEMA17DISSW | MODULE, DISCHARGE - (INCLUDES ITEMS 1, 4,5,6,7,8,9,10,11,12,&13) | 3 |
| 2 | 8488-2S | FEMA17SUCSW | MODULE, SUCTION (INCLUDES ITEMS 2,11,12,& 27) | 3 |
| 3 | 6488-1 | OWA17LRPLATESW | PLATE, LINER RETAINER | 3 |
| 4 | 4017-4 | PEP68 | CAPSCREW, ALLEN HEAD | 24 |
| 5 | 4016-3 | OWA17DMSSW | STUD, DISCHARGE MANIFOLD | 12 |
| 6 | EMSF1000TRSN | NUT, DISCHARGE MANIFOLD STUD | 12 | |
| 7 | 4016-96 | OWA17PFSSW | STUD, POWER FRAME | 12 |
| 8 | PEP55 | NUT, POWER FRAME STUD | 12 | |
| 9 | 4016-97 | OWA17DSUCSSW | STUD, DISCHARGE TO SUCTION MODULE | 18 |
| 10 | EMSF1000PFSN | NUT, FOR ABOVE STUD | 18 | |
| 11 | 4015-2 | OWA17TRSSW | STUD, THREADED RING | 72 |
| 12 | PZ789LCSN | NUT, THREADED RING STUD | 72 | |
| 13 | 8488-5 | PEP70 | PIN, DOWELL | 6 |
| 14 | 2988 | 1290344 | SEAL, DISCHARGE TO SUCTION MODULE | 3 |
| 15 | 2974-1 | 20100008 | SEAL, WEAR PLATE - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 3 |
| 16 | 8488-4 | PP602850 | PLATE, WEAR | 3 |
| 17 | 6588-1 | OWA17LLNSW | NUT, LINER LOCK | 3 |
| 18 | P-129 | 07207129 | SEAL, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 6 |
| 19 | 4018-88 | PEP73 | SCREW, VALVE COVER RETAINER | 12 |
| 20 | 4775R | OWA17VGSW | GUIDE, VALVE (INCLUDES ITEMS 20,& 22) | 6 |
| 21 | 4675-1A | OWA17VCASSYSW | PLUG, VALVE COVER (INCLUDES ITEMS 19,20,21,&22) | 6 |
| 22 | 4700-I | PZ789VGI | BUSHING, VALVE GUIDE | 6 |
| 23 | 4475 | OWA17FLGSW | RING, THREADED | 6 |
| 24 | 4575 | OWA17CAPSW | CAP, THREADED | 6 |
| 25 | 80102003 | 10300201 | GASKET, SUCTION MANIFOLD | 3 |
| 26 | 568-345 | 99609345 | GASKET, DISCHARGE MANIFOLD | 3 |
| 27 | 4018-70 | 75634382 | CAPSCREW,SUCTION MANIFOLD | 24 |
| 28 | 8488-7 | PEP90 | SETSCREW, LINER RETAINER | 9 |
Southwest
National 12P-160 Mud Pump
| "L" NEW STYLE MODULE FOR NATIONAL 12-P-160 | QTY PER PUMP | |||
| FLUID END MODULE & ACCESSORIES | ||||
| ITEM # | OEM PART # | MISSION PART # | DESCRIPTION | |
| FLUID END MODULE COMPLETE ASSEMBLY | 3 | |||
| 1 | 8476-6S | FEM12PSUCSWNS | MODULE, SUCTION STUDDED | 3 |
| 2 | 8476-5D | FEM12PDISSWNS | MODULE, DISCHARGE STUDDED | 3 |
| 3 | 4018-17 | 12P160DSUCS | STUD, DISCHARGE TO SUCTION MODULE | 18 |
| 4 | PEP55 | NUT, DISCHARGE TO SUCTION STUD | 18 | |
| 5 | 4015-95 | NAT12P160PFS | STUD, POWER END | 30 |
| 6 | 8P80TRSN | NUT, POWER END STUD | 30 | |
| 7 | 8488-5 | PEP70 | PIN, DOWELL | 6 |
| 8 | 4017-65 | PEP75 | CAPSCREW,LINER RETAINER SOCKET HEAD | 18 |
| 9 | 8476-3 | PP6021260SW | PLATE, LINER WEAR | 3 |
| 10 | 2988 | 1290344 | GASKET, WEAR PLATE AND MODULE | 6 |
| 11 | 6476 | 12PLASW | FLANGE, LINER RETAINER (LINER BUSHING) | 3 |
| 12 | 6576 | 12PLANSW | NUT, LINER RETAINER | 3 |
| 13 | 4015-54 | 12PTRSSW | STUD, THREADED RING | 72 |
| 14 | 12P160TRSN | NUT, THREADED RING STUD | 72 | |
| 15 | 4676-6A | 12PVCASSYSWNS | PLUG, VALVE COVER (INCLUDES ITEMS 15,19,20,& 21) | 6 |
| 16 | 4476 | 12PFLGSW | RING, THREADED (THREADED FLANGE) | 6 |
| 17 | 4597 | 12PCAPSW | CAP, THREADED (SCREW GLAND) | 6 |
| 18 | P-119 | 07207119 | SEAL, VALVE COVER PLUG - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 6 |
| 19 | 4776R | 12PVGASWNS | ASSEMBLY, VALVE GUIDE(INCLUDES ITEMS 19,& 20) | 6 |
| 20 | 4700-I | PZ789VGI | BUSHING, VALVE GUIDE | 6 |
| 21 | 4016-98 | PEP73 | SCREW, VALVE GUIDE | 12 |
| 22 | 4018-19 | 700048511 | CAPSCREW, SUCTION MANIFOLD | 24 |
| 23 | AJO-419R | 1540851 | GASKET, SUCTION MANIFOLD | 3 |
| 24 | 8376-2 | NAT12PDSMA | ADAPTER, DISCHARGE | 2 |
| 25 | 2976-2 | 2410031437 | SEAL, DISCHARGE ADAPTER | 4 |
| 26 | 8376-1 | NAT12PDSMC | CONNECTOR, DISCHARGE | 2 |
| BOMCO F-1300/F-1600, LOADMASTER LSF-1600, TFI F-1600, Weatherford MP-13/MP-16 | ||||
| ITEM # | OEM PART # | MISSION PART # | DESCRIPTION | QTY PER PUMP |
| NA | ASSY, COMPLETE FLUID END (INCLUDES MANIFOLDS) | 1 | ||
| 1 | NA | ASSY, COMPLETE FLUID END MODULE | 3 | |
| 1A | 79101004 | MODULE, STUDDED FLUID END (ITEMS 1A-14) | 3 | |
| 2 | EMSFB13LCS | STUD, LINER THREADED RING | 36 | |
| 3 | PEP53 | NUT, LINER THREADED RING STUD | 36 | |
| 4 | EMSFB13PFS | STUD, POWER FRAME | 18 | |
| 5 | EMSF1000PFSN | NUT, POWER FRAME STUD | 18 | |
| 6 | EMSFB13PFS | STUD, TOP POWER FRAME | 12 | |
| 7 | EMSF1000PFSN | NUT, TOP POWER FRAME STUD | 12 | |
| 8 | 7602113 | WASHER, LOCK TOP POWER FRAME STUD 1-1/2" (NOT SHOWN) | 12 | |
| 9 | 79101005 | STUD, THROUGH MODULE POWER FRAME 1-1/2-? X ? | 12 | |
| 10 | EMSF1000PFSN | NUT, THROUGH MODULE POWER FRAME STUD | 12 | |
| 11 | EMSFB13TRS | STUD, CYLINDER HEAD THREADED RING | 30 | |
| 12 | EMSF1000PFSN | NUT, CYLINDER HEAD THREADED RING STUD | 30 | |
| 13 | EMSF1000DMS | STUD, DISCHARGE MANIFOLD | 12 | |
| 14 | IDT800TRSN | NUT, DISCHARGE MANIFOLD STUD | 12 | |
| 15** | EMSFB13LVGA | GUIDE, LOWER VALVE (WITH BUSHING) | 3 | |
| 16** | EMSF1000LVGB | BUSHING, LOWER VALVE GUIDE | 3 | |
| 17** | EMSFB13BOLT | LOCKBOLT, LOWER VALVE GUIDE | 3 | |
| 18** | EMSFB13AR | ALIGNMENT RING | 3 | |
| 19 | 7916801 | GASKET, HEAD SEAL | 3 | |
| 20** | EMSFB13CYHPLG | PLUG, CYLINDER HEAD | 3 | |
| 21 | EMSFB13CYHFLG | RING, THREADED CYLINDER HEAD | 3 | |
| 22 | EMSFB13CYHCAP | CAP, THREADED CYLINDER HEAD | 3 | |
| 23 | 7916741 | GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 3 | |
| 24 | PEP79 | SCREW, RETAINER UPPER) | 12 | |
| 25 | EMSRETAINER | PLATE, RETAINER (UPPER) | 3 | |
| 26 | EMSF1000UVGB | GUIDE, UPPER VALVE | 3 | |
| 27 | EMSFB13CAP | COVER, VALVE POT | 3 | |
| 28 | 7916800 | GASKET, WEAR PLATE - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 3 | |
| 29 | EMSFB13WP | PLATE, WEAR | 3 | |
| 30 | 7916800 | GASKET, LINER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 3 | |
| 31 | EMSFB13LTR | RING, LINER THREADED | 3 | |
| 32 | EMSFB13LL | LINER LOCK | 3 | |
| 33 | 99609343 | GASKET, DISCHARGE MANIFOLD | 3 | |
| 34 | 99609442 | GASKET, SUCTION MANIFOLD | 3 | |
| 35 | 0-7601-0333-30 | SUCTION MANIFOLD CAPSCREW (NOT SHOWN) | 18 | |
Contact Details
Qingdao National Premium Oilwell Machinery Co.,Ltd
Contact Person: Mr. Eric
Tel: 0086-15376875239
Other Products
-
Weatherford MP-16 mud pump pinionshaft and Bull gear, MP13 MUD PUMP, MP10 MUD PUMP, MP8 MUD PUMP, MP5 MUD PUMP LINER
-
Weatherford E-2200 mud pump fluid end module,E447 mud pump, MP16 mud pump, MP5 mud pump, WH1612 mud pump
-
Weatherford E-2200 mud pump, E-447 mud pump, MP-16 mud pump, MP-13 mud pump, MP-5 mud pump, MP10 mud pump, MP10 mud pump
-
SOUTHWEST 8404-25A FLUID END FOR BOMCO F-1600 MUD PUMP, SOUTHWEST 8404-25A FLUID END FOR HH F1600 MUD PUMP, 14P220
-
MP5 MUD PUMP, MP10 MUD PUMP, MP13 MUD PUMP, MUD PUMP FOR OILWELL DRILLING, WEATHERFORD MUD PUMP, MP16 MUD PUMP
-
MP5 MUD PUMP, MP10 MUD PUMP, MP13 MUD PUMP, MUD PUMP FOR OILWELL DRILLING, WEATHERFORD MUD PUMP, MP16 MUD PUMP
