SOUTHWEST 8477-A Gardner Denver PZ-11/PZ-10, National mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Usage: | Oil,Water,drill Rig | Power: | Electric,Hydraulic,diesel |
|---|---|---|---|
| Pressure: | High Pressure,Low Pressure | Application: | Mining,oil,Chemical |
| Structure: | Piston Pump,Single-stage Pump | Fuel: | Diesel,Electric |
| Standard Or Nonstandard: | Standard | Theory: | Centrifugal Pump,Reciprocating Pump,Diaphragm Pump |
| Type: | Mud Pump | Weight: | 100-3700kg |
| Color: | Blue,red And So On,Green Or Per Customer Design | Material: | Cast Iron/stainless Steel Mud Suction Pump,Chrome Alloy |
| Warranty: | 12 Months | Feature: | Compact Size |
| Product Name: | Mud Pump | Head: | 10m Mud Suction Pump |
| Oem: | Can Be Accept,Applicable | Inlet Pipe (mm)/(in): | DN200 / 8 |
| Condition: | New |
SOUTHWEST 8477-A
Gardner Denver PZ-11/PZ-10
| ITEM | P/N | DESCRIPTION | QTY |
| 8477A | FLUID END ASSEMBLY: (CONSISTS OF ITEMS 3,4,17,18,19,20, 21, 22, 23, 24, 25, 26, 27, 28, 29,31,32,33, 34, 35,38,39) | ||
| 1 | 1377YXX | LINER (REFER TO GUIDE TO ORDERING CHART FOR TYPE (Y) AND FOR SIZE (XX)) | 3 |
| 2 | 2975 | LINER SEAL | 3 |
| 3 | 8477-3 | WEARPLATE | 3 |
| 4 | 2930-08 | WEARPLATE GASKET | 3 |
| 5 | XX-BYY | PISTON (REFER TO GUIDE TO ORDERING CHART FOR SIZE (XX) AND FOR TYPE (YY)) | 3 |
| 5A | 2932 | PISTON BUSHING (FROM 1-5/8” TO 1-1/2” STRAIGHT BORE) | 3 |
| 6 | 568-225 | PISTON O-RING | 3 |
| 7 | 6278-25 | PISTON ROD (WITH ELASTIC STOP NUT) | 3 |
| 8 | API-4ESN | PISTON ROD ELASTIC STOP NUT | 3 |
| 9 | 1290-2 | PISTON ROD CONNECTING STUD | 3 |
| 10 | 6279-1 | SUB ROD (CLAMP TYPE) | 3 |
| 10A | 6280-1 | SUB ROD (SCREW TYPE) | 3 |
| 11 | 1277CW | ROD CLAMP (CONSIST OF 11A, 11B, 11C) | 3 |
| 11A | 1200H30 | HOSE (1/2” X 30” WITH 1/2” MALE X 3/8” MALE CONNECTIONS) | 3 |
| 11B | 1200120 | DUAL SPRAY PIPE | 3 |
| 11C | 4018-96 | ROD CLAMP BOLT (5/8” X 5-1/2” GRADE 8 BOLT W/ LOCK NUT AND WASHER) | 6 |
| 12 | 1200G77 | PONY ROD (CLAMP TYPE) | 3 |
| 12A | 1200G88 | PONY ROD (SCREW TYPE) | 3 |
| 13 | VALVE | 6 | |
| 14 | VALVE INSERT (IF REQUIRED) | 6 | |
| 15 | VALVE SPRING | 6 | |
| 16 | VALVE SEAT | 6 | |
| SWTM1700 | HYDRAULIC SEAT PULLER KIT COMPLETE (REFER TO TOOLS SECTION OF CATALOG FOR DETAILS) | ||
| 4475-1A | SOUTHWEST HP QUICK-CHANGE VALVE COVER ASSEMBLY: (CONSISTS OF ITEMS 17-24) | ||
| 17 | 4475 | THREADED FLANGE | 6 |
| 18 | 4575 | SCREW GLAND | 6 |
| 19 | 4675-1A | PLUG (COMPLETE WITH VALVE GUIDE, SCREWS, AND BUSHING) | 6 |
| 20 | P129 | HP VALVE COVER PLUG SEAL (P129U URETHANE AVAILABLE) | 6 |
| 21 | 4775R | VALVE GUIDE (COMPLETE WITH BUSHING #4700I) | 6 |
| 22 | 4700I | VALVE GUIDE BUSHING (4700IU URETHANE AVAILABLE) | 6 |
| 23 | 4018-88 | VALVE GUIDE SCREW | 12 |
| 24 | 4015-2 | VALVE COVER STUD (WITH SW PART# HHN1250-7 1-1/4”-7” HEAVY HEX NUT) | 72 |
| 25 | 4018-35 | POWER END STUD (WITH SW PART# HHN1250-7 1-1/4” – 7 HEAVY HEX HUT) | 24 |
| 26 | 4018-34 | LINER RETAINER FERRY HEAD CAP SCREW (WITH SW PART# HHN1250-7 1-1/4” – 7 HEAVY HEX NUTS) | 24 |
| 27 | 6477 | LINER RETAINER FLANGE | 3 |
| 28 | 4016-97 | SUCTION MODULE STUD (WITH SW PART# HHN1500-8 1-1/2” – 8 HEAVY HEX NUT) | 18 |
| 29 | 4017-77 | SUCTION MANIFOLD CAP SCREW (WITH LOCK WASHER) | 24 |
| 30 | 8577 | SUCTION MANIFOLD (FRONT OR SIDE INLET) | 1 |
| 31 | AJO245 | SUCTION MANIFOLD SEAL | 3 |
| 32 | 8477-2S | SUCTION MODULE (STUDDED ONLY) | 3 |
| 33 | 8477-1D | DISCHARGE MODULE (STUDDED ONLY) | 3 |
| 34 | 8488-5 | DOWEL PIN | 6 |
| 35 | 2988 | MODULE SEAL | 3 |
Southwest
A1400/1700PT Mud Pump
| "L" MODULE FOR A-1400-PT, A-1700PT | QTY PER PUMP | |||
| FLUID END MODULE & ACCESSORIES | ||||
| ITEM # | OEM PART # | MISSION PART # | DESCRIPTION | |
| 8488-1A | FEMA17ASSYSW | FLUID END MODULE COMPLETE ASSY. (INCLUDES ITEMS: 1-28) | 3 | |
| 1 | 8488-1D | FEMA17DISSW | MODULE, DISCHARGE - (INCLUDES ITEMS 1, 4,5,6,7,8,9,10,11,12,&13) | 3 |
| 2 | 8488-2S | FEMA17SUCSW | MODULE, SUCTION (INCLUDES ITEMS 2,11,12,& 27) | 3 |
| 3 | 6488-1 | OWA17LRPLATESW | PLATE, LINER RETAINER | 3 |
| 4 | 4017-4 | PEP68 | CAPSCREW, ALLEN HEAD | 24 |
| 5 | 4016-3 | OWA17DMSSW | STUD, DISCHARGE MANIFOLD | 12 |
| 6 | EMSF1000TRSN | NUT, DISCHARGE MANIFOLD STUD | 12 | |
| 7 | 4016-96 | OWA17PFSSW | STUD, POWER FRAME | 12 |
| 8 | PEP55 | NUT, POWER FRAME STUD | 12 | |
| 9 | 4016-97 | OWA17DSUCSSW | STUD, DISCHARGE TO SUCTION MODULE | 18 |
| 10 | EMSF1000PFSN | NUT, FOR ABOVE STUD | 18 | |
| 11 | 4015-2 | OWA17TRSSW | STUD, THREADED RING | 72 |
| 12 | PZ789LCSN | NUT, THREADED RING STUD | 72 | |
| 13 | 8488-5 | PEP70 | PIN, DOWELL | 6 |
| 14 | 2988 | 1290344 | SEAL, DISCHARGE TO SUCTION MODULE | 3 |
| 15 | 2974-1 | 20100008 | SEAL, WEAR PLATE - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 3 |
| 16 | 8488-4 | PP602850 | PLATE, WEAR | 3 |
| 17 | 6588-1 | OWA17LLNSW | NUT, LINER LOCK | 3 |
| 18 | P-129 | 07207129 | SEAL, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 6 |
| 19 | 4018-88 | PEP73 | SCREW, VALVE COVER RETAINER | 12 |
| 20 | 4775R | OWA17VGSW | GUIDE, VALVE (INCLUDES ITEMS 20,& 22) | 6 |
| 21 | 4675-1A | OWA17VCASSYSW | PLUG, VALVE COVER (INCLUDES ITEMS 19,20,21,&22) | 6 |
| 22 | 4700-I | PZ789VGI | BUSHING, VALVE GUIDE | 6 |
| 23 | 4475 | OWA17FLGSW | RING, THREADED | 6 |
| 24 | 4575 | OWA17CAPSW | CAP, THREADED | 6 |
| 25 | 80102003 | 10300201 | GASKET, SUCTION MANIFOLD | 3 |
| 26 | 568-345 | 99609345 | GASKET, DISCHARGE MANIFOLD | 3 |
| 27 | 4018-70 | 75634382 | CAPSCREW,SUCTION MANIFOLD | 24 |
| 28 | 8488-7 | PEP90 | SETSCREW, LINER RETAINER | 9 |
All our fluid end parts are manufactured to API 7K quality standards.
Parts are available for these popular pump models:
BOMCO/Emsco Mud Pumps:F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,
LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600
Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,
National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,
Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,
Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT
Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200
Russian Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32
WEATHERFORD/Ellis Williams: E-447, E-2200
Drillmec: 9T1000, 12T1600, 7TS600, 7TS500, 9T800
Romania: 3PN-1000, 3PN-1600, 3PN-2000
And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.
| CONTINENTAL EMSCO FB-1300, FB-1600 | QTY PER PUMP | |||
| FLUID END MODULE & ACCESSORIES | ||||
| ITEM # | OEM PART # | MISSION PART # | ||
| 1 | 0-6316-0325-00 | EMSFEMFB1300CA | FLUID END MODULE COMPLETE ASSY. (ITEMS 1-22, 24- 28) | 3 |
| 1A | 0-6316-0357-00 | EMSFEMFB1300 | FLUID END MODULE STUDDED * (ITEMS 1, 2, 3, 4, 4A, 5, 6, 7, & 28) | 3 |
| 2 | EMSFB13LCS | STUD, MODULE TO LINER CLAMP | 36 | |
| 3 | 0-7601-0610-18 | PEP53 | LINER CLAMP STUD NUT | 36 |
| 4 | 0-7507-2201-00 | EMSFB13PFS | POWER FRAME STUD | 18 |
| 4A | 0-7507-2210-00 | EMSFB13TRS | STUD, MODULE TO CYLINDER | 18 |
| 5 | 0-7601-0630-17 | EMSF1000PFSN | NUT (FOR ABOVE) | 48 |
| 6 | 0-7507-2108-00 | EMSF1000DMS | STUD, MODULE TO DISC. MANIFOLD | 12 |
| 7 | 0-7601-0630-24 | IDT800TRSN | NUT (FOR ABOVE) | 12 |
| 8 | 0-6316-0354-00 | EMSFB13LVGA | GUIDE, LOWER VALVE (WITH BUSHING) | 3 |
| 9 | 0-6316-0096-00 | EMSF1000LVGB | BUSHING, LOWER VALVE GUIDE | 3 |
| 10 | 0-6316-0360-00 | EMSFB13BOLT | LOCKBOLT, LOWER VALVE GUIDE | 3 |
| 11 | 0-6316-0363-00 | EMSFB13AR | ALIGNMENT RING | 3 |
| 12 | 0-6316-0369-00 | 07916801 | GASKET, HEAD SEAL | 3 |
| 13 | 0-6316-0364-90 | EMSFB13CYHPLG | PLUG, CYLINDER HEAD | 3 |
| 14 | 0-6316-0361-00 | EMSFB13CYHFLG | RING, THREADED CYLINDER HEAD | 3 |
| 15 | 0-6316-0362-00 | EMSFB13CYHCAP | CAP, THREADED CYLINDER HEAD | 3 |
| 16 | 0-6316-0092-00 | 07916741 | GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 3 |
| 17 | 0-7501-0051-00 | PEP79 | SCREW, RETAINER UPPER) | 12 |
| 18 | 0-6397-0603-00 | EMSRETAINER | PLATE, RETAINER (UPPER) | 3 |
| 19 | 0-6397-0575-00 | EMSF1000UVGB | GUIDE, UPPER VALVE | 3 |
| 20 | 0-6316-0039-00 | EMSFB13CAP | COVER, VALVE POT | 3 |
| 21 | 0-6316-0373-00 | 07916800 | GASKET, WEAR PLATE - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 3 |
| 22 | 0-6316-0365-00 | EMSFB13WP | PLATE, WEAR | 3 |
| 23 | 0-6316-0373-00 | 07916800 | GASKET, LINER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 3 |
| 24 | 0-6316-0366-00 | EMSFB13LTR | RING, LINER THREADED | 3 |
| 25 | 0-6316-0367-20 | EMSFB13LL | LINER LOCK | 3 |
| 26 | 0-7602-1600-25 | 99609343 | GASKET, DISCHARGE MANIFOLD | 3 |
| 27 | 0-7602-1600-61 | 99609442 | GASKET, SUCTION MANIFOLD | 3 |
| 28 | 0-7601-0333-30 | SUCTION MANIFOLD CAPSCREW (NOT SHOWN) |
| CONTINENTAL EMSCO F-800, F-1000 | QTY PER PUMP | |||
| FLUID END MODULE & ACCESSORIES | ||||
| ITEM # | OEM PART # | MISSION PART # | ||
| 1 | EMSFEMF1000CA | FLUID END MODULE COMPLETE ASSEMBLY** (INCLUDES ITEMS 1-23) | 3 | |
| 1A | 0-6999-0086-02 | EMSFEMF1000 | FLUID END MODULE STUDDED * (INCLUDES ITEMS 1-7 & 23) | 3 |
| 2 | 0-7507-2205-00 | EMSF1000PFS | STUD FRAME | 18 |
| 3 | 0-7601-0630-17 | EMSF1000PFSN | NUT (FOR ABOVE) | 18 |
| 4 | 0-7507-2150-00 | EMSF1000TRS | STUD, THREADED RING | 30 |
| 5 | 0-7601-0630-28 | EMSF1000TRSN | NUT (FOR ABOVE) | 30 |
| 6 | 0-7507-2108-00 | EMSF1000DMS | STUD, DISCHARGE MANIFOLD | 12 |
| 7 | 0-7601-0630-24 | IDT800TRSN | NUT (FOR ABOVE) | 12 |
| 8 | 0-6319-0026-00 | EMSF1000LC | CAGE, LINER | 3 |
| 9 | 0-6319-0087-00 | EMSF1000LVG | GUIDE, LOWER VALVE (WITH BUSHING) | 3 |
| 10 | 0-6319-0089-00 | EMSF1000LVC | CLIP, LOCKING (FOR LOWER VALVE GUIDE) | 3 |
| 11 | 0-7602-2200-32 | 07918282 | GASKET, LINER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 6 |
| 12 | 0-6319-0031-00 | EMSF1000CYHPLG | PLUG, CYLINDER HEAD | 3 |
| 13 | 0-6999-0089-00 | EMSF1000CYHFLG | RING, THREADED CYLINDER HEAD | 3 |
| 14 | 0-6319-0090-00 | EMSF1000CYHCAP | CAP, THREADED CYLINDER HEAD | 3 |
| 15 | 0-6319-0076-00 | 07916740 | GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 3 |
| 16 | 0-7501-0051-00 | PEP79 | SCREW, RETAINER (UPPER) | 12 |
| 17 | 0-6397-0603-00 | EMSRETAINER | RETAINER PLATE (UPPER) | 3 |
| 18 | 0-6397-0575-00 | EMSF1000UVGB | GUIDE, UPPER VALVE | 3 |
| 19 | 0-6319-0027-00 | EMSF1000CAP | COVER, VALVE POT | 3 |
| 20 | 0-7602-1610-46 | 0-7602-1610-46 | GASKET, DISCHARGE MANIFOLD | 3 |
| 21 | 0-7602-1600-61 | 0-7602-1600-61 | GASKET, SUCTION MANIFOLD | 3 |
| 22 | 0-6316-0096-00 | EMSF1000LVGB | BUSHING, LOWER VALVE GUIDE | 3 |
| 23 | 0-7601-0336-00 | 0-7601-0336-00 | CAPSCREW, SUCTION MANIFOLD - NOT SHOWN | |
| 07924503 | MODULE SEAL KIT: (KIT INCLUDES SUCTION MANIFOLD O-RING, DISCHARGE MANIFOLD O-RING, CYLINDER HEAD GASKET, VALVE COVER GASKET) | 3 | ||
Southwest Oilfield Products is a premier oil and gas equipment manufacturer that provides Their global customer base with best-in-class mud and well servicing pump solutions. They manufacture rugged and reliable equipment for your specific needs including Mud Pump Fluid Ends, Frac Pump Fluid Ends, Liners, Pistons and other consumable items.
Their Mud Pump solutions team has been an industry leader since 1947 and is renowned for providing high quality mud pump fluid ends and consumable parts such as pistons, liners, valves and seats to drilling companies across the globe. With over 65 years of manufacturing experience, Their mission is to provide you with simply the best well servicing equipment and mud pump products.
Southwest Oilfield Products, Inc. is committed to delivering the highest quality products, on time, and creating positive significant impacts on their customers’ projects. They strive to maintain their innovative stance in the industry while partnering with our customers to share the focus on generating solutions.
